Panasonic SA-AK110P Service Manual

Hide thumbs Also See for SA-AK110P:
Table of Contents

Advertisement

Quick Links

Download this manual
Specifications
AMPLIFIER SECTION
Power output
10% Total harmonic distortion
60Hz-16kHz, both channels driven
Power output
10% Total harmonic distortion
1kHz, both channels driven
Input sensitivity
AUX
Input impedance
AUX
FM TUNER SECTION
Frequency range
Sensitivity
S/N 26 dB
Antenna terminal(s)
AM TUNER SECTION
Frequency range
Sensitivity
S/N 20 dB (at 1000 kHz)
CASSETTE DECK SECTION
Track system
Heads
All manuals and user guides at all-guides.com
60 W per channel (6 Ω)
80W per channel (6Ω)
250 mV
13.3kΩ
87.9 - 107.9 MHz (200 kHz steps)
87.5 - 108.0 MHz (100 kHz steps)
2.5µV (IHF)
2.2 µV
75 Ω (unbalanced)
520 - 1710 kHz (10 kHz steps)
560 µV/m
4 track, 2 channel
CD Stereo System
SA-AK110P
Colour
(K)... Black Type
TAPE SECTION :
SG-2W MECHANISM SERIES
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Overall frequency response (+3 dB, -6 dB at DECK OUT)
NORMAL (TYPE I)
S/N
Wow and flutter
Fast forward and rewind time
CD SECTION
Sampling frequency
Decoding
Beam source/wave length
Number of channels
Frequency response
Wow and flutter
Digital filter
D/A converter
GENERAL
Power supply
Power consumption
Power Consumption in standby
mode
© 2002 Matsushita Electronics (S) Pte. Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ORDER NO. MD0211231C1
A6
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
4.8 cm/s (1 7/8 ips)
35 Hz - 14 kHz
50 dB (A weighted)
0.18 % (WRMS)
Approx. 120 seconds with
C-60 cassette tape
44.1 kHz
16 bit linear
Semiconductor laser/780 nm
Stereo
20 Hz - 20 kHz (+1, -2 dB)
Below measurable limit
8 fs
MASH (1 bit DAC)
AC 120 V, 60Hz
165 W
0.34 W
