System - Frigidaire FFC25C8CW0 Factory Parts Catalog

Frigidaire ffc25c8cw0: supplementary guide
Table of Contents

Advertisement

POS. NO
1 #
4
5 #
5 *
22
27
28
29 #
30
32
42
43A
47
55 #
78
86
*
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC25C8CW0

SYSTEM

PART NO
DESCRIPTION
5303925320
Condenser
216634500
Drier-filter
216890300
Harness-main
216890200
Harness,low voltage- ,w/thermistor
216056400
Clip,compressor mtg ,SPRING
5308002681
Grommet,compressor
5303212615
Support,compressor
216784700
Compressor,w/o electricals
216649300
Controller-regulator LP
216649100
Clamp,elec cont mtg ,compressor
216232700
Washer,flat ,1"OD x 0.531"ID
5303212614
Clip,harness mount
216629600
Screw,hex washer head ,10-16 x 0.500 ,tapping
218909901
Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
216893100
Assy-High Voltage
216036600
Screw,ph washer head ,8-32CA x 0.500 ,thread forming
5303298960
Spacer-tube,0.237" ID
7
Publication No.
5995390290
05/03
