Frigidaire FFC20C3AW Factory Parts Catalog

Frigidaire ffc20c3aw: supplementary guide
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FFC20C3AW0
FFC20C3AW
FFC25C3AW0
FFC25C3AW
MARKET
North America
WIRING DIAGRAM - # 216487000 / 216804000
OWNER'S GUIDE - # 216802800
SERVICE DATA SHEET - #216487000 / 216804000
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
134A
white
Publication No.
5995355434
010629
-EN/SERVICE /GS
365
FREEZER
VOLTS
115
115
FREEZER
Model No.
FFC20C3AW
FFC25C3AW
©2001 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading

  Related Manuals for Frigidaire FFC20C3AW

  Summary of Contents for Frigidaire FFC20C3AW

  • Page 1 PRODUCT NO. BASE MODEL NO. FFC20C3AW0 FFC20C3AW FFC25C3AW0 FFC25C3AW MARKET North America WIRING DIAGRAM - # 216487000 / 216804000 OWNER’S GUIDE - # 216802800 SERVICE DATA SHEET - #216487000 / 216804000 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O BOX 212378, AUGUSTA , GA 30917...
  • Page 2 Publication No. FFC20/25C3AW0 5995355434 DOOR 07/01...
  • Page 3 A = FFC20C3A (FFC20C3AW0) B = FFC25C3A (FFC25C3AW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFC20/25C3AW0 DOOR PART NO DESCRIPTION 216481401 Gasket-door,white 216469301 Gasket-door,white 5303925107 Lock Assy 216702900 Key,lock 216059604 Panel-inner lid,white 216072604 Panel-inner lid,white 216141101 Plug button,white 216130100 Panel-outer door/lid,white 216032402...
  • Page 4 Publication No. FFC20/25C3AW0 5995355434 CABINET 07/01...
  • Page 5 A = FFC20C3A (FFC20C3AW0) B = FFC25C3A (FFC25C3AW0) POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFC20/25C3AW0 CABINET PART NO DESCRIPTION 5303208488 Latch-door 216080800 Support,lock 216502600 Plug-drain,interior ,interior 216073905 Plug-drain,exterior 216111200 Breaker,hinge side 216111400 Breaker-hinge side,white 216111800 Breaker,lock side 216112000...
  • Page 6 Publication No. FFC20/25C3AW0 5995355434 SYSTEM 07/01...
  • Page 7 A = FFC20C3A (FFC20C3AW0) B = FFC25C3A (FFC25C3AW0) POS. NO 29 # 29 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FFC20/25C3AW0 SYSTEM PART NO DESCRIPTION 5303280307 Condenser 5303925320 Condenser 216634500 Drier-filter 216551800 Harness,electrical 216056400 Clip-spring mtg 5308002681 Grommet,compressor 5303212615...
