Frigidaire FFC20C8CW0 Factory Parts Catalog

Frigidaire ffc20c8cw0: supplementary guide
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FFC20C8CW0
FFC20C8CW
MARKET
North America
WIRING DIAGRAM - # 216901200, SERVICE DATA - # 216901200
OWNER'S GUIDE - # 216802800
ENERGY GUIDE - # 216794404
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995391041
030521
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
CHEST FREEZER
Model number:
FFC20C8CW0
©2003 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

  Also See for Frigidaire FFC20C8CW0

  Related Manuals for Frigidaire FFC20C8CW0

  Summary of Contents for Frigidaire FFC20C8CW0

  • Page 1 PRODUCT NO. BASE MODEL NO. FFC20C8CW0 FFC20C8CW MARKET North America WIRING DIAGRAM - # 216901200, SERVICE DATA - # 216901200 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794404 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
