Frigidaire FFC20D7HW0 Factory Parts Catalog

Frigidaire ffc20d7hw0: supplementary guide
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FFC20D7HW0
FFC20D7H
MARKET
North America
WIRING DIAGRAM - # 216651500
OWNER'S GUIDE - # 21665700
MINI MANUAL - # 216651500
101 Masters Blvd.
Anderson,SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995321089
990415
-EN/SERVICE /GS
365
FREEZER
VOLTS
115
FREEZER
Model No.
FFC20D7HW0
©1999 White Consolidated Industries, Inc.
All rights reserved
