Frigidaire FFC13G7AW Factory Parts Catalog page 5

134a series
Hide thumbs

Advertisement

A = FFC13G7A (FFC13G7AW2)
B = FFC15G7A (FFC15G7AW2)
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC13/15G7AW2
POS. NO
PART NO
1
5303208488
1A
216818900
3
216502600
4
216073905
6
216110900
6
216111000
7
216111500
7
216111600
11
216110800
18
216707200
21 #
216714701
27
216629600
28
216039600
28
216035200
30
216110700
59
216080300
59*
216080700
71
5303302714
75
216034301
93
5303161215
100
216081500
100
216654400
*
5303305324
*
216269500
CABINET
DESCRIPTION
A B
Latch,lid catch
A B
Support,lock catch clip
A B
Plug,drain ,interior
A B
Plug-drain,exterior
A -
Breaker
- B
Breaker,hinge side
A -
Breaker,lock side
- B
Breaker,lock side
A B
Breaker,chest end ,(2)
A B
Knob,temp control
A B
Control,temperature
A B
Screw,hex washer head ,10-16 x 0.500 ,tapping
A -
Hinge
- B
Hinge
A B
Breaker,corners
A B
Basket
A B
Basket,lower ,(2)
A B
Screw,8-18x3/4 ,(2)
A B
Panel,access ,white
A B
Screw,ph truss head ,8-18AB x 0.500
A -
Track,basket
- B
Track-basket
A B
Paint,touch-up ,white
A B
Adapter,drain hose
5
Publication No.
5995378741
09/02
