Frigidaire FFC13K3CW Factory Parts Catalog

134a series
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FFC13K3CW1
FFC13K3CW
MARKET
North America
WIRING DIAGRAM - # 216908200
OWNER'S GUIDE - # 216802800 ENERGY GUIDE - # 216794106
SERVICE DATA SHEET - # 216908200
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995387114
030307
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
CHEST FREEZER
Model number:
FFC13K3CW
©2003 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

  Summary of Contents for Frigidaire FFC13K3CW

  • Page 1 PRODUCT NO. BASE MODEL NO. FFC13K3CW1 FFC13K3CW MARKET North America WIRING DIAGRAM - # 216908200 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794106 SERVICE DATA SHEET - # 216908200 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
  • Page 2 Publication No FFC13K3CW1 5995387114 DOOR 03/03...
  • Page 3 POS. NO 47 # # = Fast-moving Parts * = Non-Illustrated Parts FFC13K3CW1 DOOR PART NO DESCRIPTION 216481101 Gasket-door,white 216828906 Panel-lid 216141101 Plug button,white 216129819 Panel-lid 216822900 Switch,light/lamp ,ramp 216846400 Light Bulb/Lamp 216817600 Socket,light/lamp ,25 W 216140200 Handle,recessed ,white 5303212828 Clip,panel mtg 08009392 Gasket,white...
  • Page 4 Publication No FFC13K3CW1 5995387114 CABINET 03/03...
  • Page 5 POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFC13K3CW1 CABINET PART NO DESCRIPTION 216269500 Adapter,drain hose 216502600 Plug,drain ,interior 216073900 Plug,drain ,exterior 216110900 Breaker 216110800 Breaker,chest end ,(2) 216892800 Nameplate 216707200 Knob,temp control 216714601 Control temperature 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping 216039600...
  • Page 6 Publication No FFC13K3CW1 5995387114 SYSTEM 03/03...
  • Page 7 POS. NO 29 # 31 # # = Fast-moving Parts * = Non-Illustrated Parts FFC13K3CW1 SYSTEM PART NO DESCRIPTION 5303925238 Condenser 216634500 Drier-filter 216906200 Harness-main 216056400 Clip,compressor mtg ,SPRING 5308002681 Grommet,compressor 5303212615 Support,compressor 216888100 Compressor,w/o electricals 216596800 Starter,relay 216100106 Overload Protector 216232700 Washer,flat ,1"OD x 0.531"ID 5303212614...
