Manual de Instalación y uso
Installation & user`s Manual
AFT A320
v1.0
April 2021
7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFT A320 and is the answer not in the manual?

Questions and answers

Summary of Contents for Opencockpits AFT A320

  • Page 1 Manual de Instalación y uso Installation & user`s Manual AFT A320 v1.0 April 2021...
  • Page 2 Índice / Index Datos Técnicos Technical Introducción Data Puesta en Marcha Introduction Start Up Precaución/Mantenimiento Links de interés Caution/Maintenance Links...
  • Page 3: Datos Técnicos

    Introducción / Introduction AFT de A320 desarrollado a imagen del original para dar al usuario la excelencia en la simulación, proporcionando una simulación fidedigna tanto en funcionalidad como en estética. A320 AFT developed in the image of the original to give the user excellence in simulation, providing a reliable simulation both in functionality and aesthetics.
  • Page 4: Puesta En Marcha

    Connect the interface to the computer through the cable and connect the power supply (5V: electronics. 12V: spotlights. 3.3V: backlight). 3. Abrir el software SIOC. Automáticamente SIOC debe reconocer la interfaz del AFT A320, en este caso USB-Expansion V3.
  • Page 5 Procedemos: The next thing we must do is load our configuration file. You can find an example of this file to manage the AFT A320 through ProSim: 320 in the download section. We proceed: 4.1 Hacemos clic en Open Scrp. Dir. y en la nueva ventana pegamos el código de configuración.
  • Page 6 4.2 A continuación, seleccionamos la opción Multiple Scripts y cargamos el fichero de configuración haciendo doble clic sobre el mismo cargado en la lista de Available Scripts. Salimos guardando los cambios efectuados. Next, we select the Multiple Scripts option and load the configuration file by double clicking on it loaded in the Available Scripts list.
  • Page 7 Do click on Config Devices 4.3.2 Hacemos clic sobre la USB-Expansion en la lista de Devices Connected. Do click on IOCardSteeper in the list of Connected Devices. 4.3.3 Hacemos clic sobre el IDX correspondiente Do click on the corresponding IDX 4.3.4 Hacemos clic sobre Link Do click on Link 4.3.5 Escribimos 3 en #cards Hacemos clic en OK...
  • Page 8 Links de interés Zona de soporte para clientes / Customer Support Area https://www.opencockpits.com/catalog/soporte.php https://www.opencockpits.com/catalog/a320-pedales-gama- profesional-p-658.html...
  • Page 9 Para cualquier reparación, contacte con el Centro de servicio al cliente de Opencockpits. To reduce the risk of electric shock, do not remove the cover (or the back) of the electronic components. For any repairs, contact the Opencockpits Customer Service Center.
  • Page 10 o Electricidad y seguridad / Electricity and security Advertencia / Warning  No utilice un cable de alimentación o un enchufe que estén dañados, como tampoco una toma de corriente suelta. Do not use a damaged power cord or plug, or a loose electrical outlet.
  • Page 11: Installation

     Utilice únicamente el cable de alimentación proporcionado con su producto. No utilice el cable de alimentación con otros productos. Use only the power cord provided with your product. Do not use the power cord with other products.  Mantenga la toma de corriente a la que esté enchufado el cable de alimentación libre de obstáculos.
  • Page 12 Do not install the product on an unstable surface. The product may fall and be damaged or cause personal injury.  No instale el producto en un lugar expuesto al polvo, la humedad, aceite o humo. Do not install the product in a place exposed to dust, moisture, oil, or smoke.
  • Page 13  Existe alta tensión dentro del producto. No desmonte, repare ni modifique nunca el producto por su cuenta. Póngase en contacto con el Centro de servicio al cliente de Opencockpits para las reparaciones. There is high voltage inside the product. Never disassemble, repair or modify the product yourself.
  • Page 14 A continuación, póngase en contacto con el Centro de servicio al cliente de Opencockpits. Do not insert metallic objects (toothpicks, hairpins, etc.) or highly flammable objects (paper, matches, etc.) into the product (through slots, inlet / outlet ports, etc.).
  • Page 15 A continuación, póngase en contacto con el Centro de servicio al cliente de Opencockpits. Do not place objects that contain liquids (vases, flowerpots, bottles, etc.) or metallic objects on the product. Be sure to turn off the product and disconnect the power cord if water or other foreign substances get into the product.
  • Page 16  No coloque el adaptador de alimentación CA/CC cerca de aparatos de calefacción. Do not place the AC / DC power adapter near heating appliances.  Mantenga el adaptador de alimentación CA/CC en un área bien ventilada. Keep the AC / DC power adapter in a well-ventilated area. ...
  • Page 17 2. Desconecte el cable de alimentación del producto. 2. Disconnect the power cord from the product. 3. Limpie el producto con un paño limpio, suave y seco. 3. Clean the product with a clean, soft and dry cloth. ―No utilice limpiadores que contengan alcohol, disolventes ni agentes tensioactivos en el producto.
  • Page 18: Mantenimiento

    Soporte técnico: support@opencockpits.com Opencockpits. admin@opencockpits.com Muchas gracias por confiar en nosotros !!! __________________________________________________________ We come to the end of this manual !!! We invite you to read the manuals for the other Opencockpits elements. Thank you very much for trusting us !!!
  • Page 19 DAFDALJAOÑ J   www.opencockpits.com    Ventas / Sales: +34 629 826 213 (Lunes a Viernes, 10 a 14 horas pm / Monday to Friday Spanish time (10 – 14 hours)   sales@opencockpits.com  Soporte Técnico / Technical Support: support@opencockpits.com...
