  • Page 1 TSM MANUAL TANK SURVAILLANCE MODULE 53430 English Manual for TSM-module 53430, R10, 181008...

  • Page 2: Table Of Contents

    LUBE-MASTER R10 Table of Contents INTRODUCTION MECHANICAL INSTALLATION ELECTRIC INSTALLATION 3.1. HE MAIN MODULE 3.2. (203 03 17) ONNECTION ADAPTER 3.3. (203 03 03) ID INDICATOR BOARD CONFIGURATION 4.1. HECK BEFORE CONFIGURATION 4.2. DDRESSING THE 4.3. P MODE 4.4. [TCM//A HANGE ADDRESS DDRESS 4.5.

  • Page 3: Introduction

    A TSM can be used both for fresh and waste oil tanks. The TSM (53430) is based on a TCM 53408 but has a lid (p/n 203 03 11) with a led indicator board (p/n 203 03 03) and a connector adapter (p/n 203 03 17) added to the main board 203 02 91.
  • Page 4 LUBE-MASTER R10 The other three connectors are used to connect external devices without a power source such as a Printer Module (PM), a LED Module (LED) and/or a KeyPad (KP). These connectors can only supply power to a single device. For more detailed information see the LUBE-Master Manual NOTE! If the communication loop begin in one of these modules it must be connected to either MPDM IN or MPDM OUT or +24V must not be connected.

  • Page 5: Connection Adapter (203 03 17)

    NC/NO of the sensor and pump control used. The SIL-Switch stock default for TSM 53430 is all ON. This is shown by the text to the left of the switch block in the right picture above.

  • Page 6: Configuration

    LUBE-MASTER R10 Configuration An LUBE-Master configuration sheet should always be filled or altered during the configuration. NOTE! To obtain technical support a copy of the configuration sheet for the complete installation must be sent to Alentec & Orion AB at E-mail: lubemaster@alentec.se Post:...

  • Page 7: Recommendation For Setting Addresses

    EXAMPLE: Port 1 measures the level of a waste oil tank and Invert A controls the air to a waste oil pump using an Eurolube 2-levels sensor 53132. This is up done by calculating the value of the Mask 1+4+8=13. The TCM: ‡...

  • Page 8: Analogue Sensor Settings

    LUBE-MASTER R10 5.3. Analogue sensor settings 5.3.1. Set the input signal filter time constant TCM: ‡ This time constant (Tau) is used to filter the sensor signal to create an accurate tank level. “0” means no filter and a higher value gives slower TCM MainMenu response but a more accurate value.

  • Page 9: Set Sensor Full Scale

    LUBE-MASTER R10 5.3.4. Set sensor full scale The sensor full scale value is the pressure corresponding to 20 mA. If a TCM: ‡ pressure sensor is used the value should be in [bar]. For sensor part number TCM MainMenu 53417 the value should be as default “0.400” PortX: ‡...

  • Page 10: Set The Fluid Density

    LUBE-MASTER R10 5.4.3. Set the fluid density If a pressure sensor is used it is essential to set the true density of the fluid TCM: ‡ because the pressure at the bottom of the tank depends on fluid level and TCM MainMenu fluid density.

  • Page 11: Set The Tank Stop Volume Level

    LUBE-MASTER R10 5.5.1. Set the tank stop volume level TCM: ‡ The tank stop volume set in the TSM is used to create a true graphic TCM MainMenu representation of the analogue sensor status and start auto warning if that is enabled.

  • Page 12: Displaying Tank Content On Aled Display

    LUBE-MASTER R10 5.6. Displaying tank content on a LED display 5.6.1. Set LED address By specifying a LED address (4XXX) it is possible to show the content of TCM: ‡ the tank in real time on a remote or local LED display. Observe that the TCM MainMenu addressed LED will not be available for dispensing information.

  • Page 13: Set The Type Of Tank (Pc System)

    LUBE-MASTER R10 5.7. Set the type of tank (PC system). To make it possible for the PC software to handle tank information, volumes, sensor inputs and valve output it is necessary to define which TSM port to use, if it is a fresh oil tank or a waste oil tank, if there are any level sensors connected and of which type if there are.

  • Page 14: Menu Tree

    LUBE-MASTER R10 Menu tree 14(21)

  • Page 15: Fast Menu Codes

    LUBE-MASTER R10 7. Fast Menu codes With a PC, the LUBE-Master WinTools software and a SIO, you can customize the quick menu that appear when you press ”?” on a keypad. To do this, assign a name to the menu, a module address and then a code. Password is optional. This code can also be used together with the address after you have typed SETUP followed by the password.

  • Page 16: Technical Specification

    LUBE-MASTER R10 Technical specification Printed circuit board Net ports: 5 LUBE-Master ports (A) for data communication, 2 without +24VDC. Discrete level inputs: 4 (F), for one or two levels. Switch or active signal max 50 V. Supports reorder and stop set-up for both fresh and waste oil.

  • Page 17: To Connect Discrete Level Sensors 53132/138/171 And Solenoid Valves

    LUBE-MASTER R10 9. To connect discrete level sensors 53132/138/171 and solenoid valves 9.1. Fresh oil tank, 53138 (2-levels) To achieve a proper function, that is the pump starts only if there are enough oil in the tank, a dispense point is open and the sensor works properly, the following connection should be made.

  • Page 18: One Tsm Port Controls A Number Of Pumps

    LUBE-MASTER R10 9.4. One TSM port controls a number of pumps It is possible to control several pumps with only one solenoid valve, that is all pumps starts if one dispense point is opened. To do this the solenoid valve is connected between +24V and Sol of a TSM port. The port is set to a tank that does not exist in the PC database and the Mask is set to 0.

  • Page 19: Connecting A Waste Oil Tank 53132 (2-Levels)

    LUBE-MASTER R10 10.1. Connecting a waste oil tank 53132 (2-Levels) To achieve a proper function, that is the pump stops if the physical tank is full or if the sensor is disconnected, the following connection should be made. The TSM port should be set to control the appropriate PC tank in relation to the physical tank. Correct TankType, TSMAddress and TSMPort should be set using with WinDB Manager MASK = 13, TankType = 11?.

  • Page 20: Connecting An Analogue Sensor

    LUBE-MASTER R10 11.2. Connecting an analogue sensor. The LUBE-Master TSM uses 2-lead 4-20mA 24VDC technique but there are several other techniques that uses more leads. Because of this the sensor can have more than 2-leads but they are not used. OBSERVE! Colors may vary between shipments and sensor types so check the sensor manual before connecting it.

  • Page 21: Connection

    LUBE-MASTER R10 12.1. Connection The analogue EX-barrier 53188 can handle 2 analogue sensors. Here is shown how to connect an analogue sensor 53417 to a TSM port using channel 1 of the EX-barrier. NOTE! The lead colours of the sensor may vary depending on the shipment and make but there are always +, - and GND/Screen.
