- Page 1 BATH.EDBYELLEN.COM...
- Page 2 ED is Ellen DeGeneres’ iconic style, values and personality shared through collections of beautifully designed, high-quality products for home, pets and people. All ED merchandise design and materials are approved by Ellen, ensuring it maintains her standards and upholds her promise to make each item feel...
- Page 3 ITEM # 3629222; 3629223 24-IN FLOOR CABINET MODEL # 1480FC-24-201; 1480FC-24-283 MODEL NUMBER DESCRIPTION 1480FC-24-201 24" White Finish Floor Cabinet 1480FC-24-283 24" Coastal Oak Finish Floor Cabinet ATTACH YOUR RECEIPT HERE Serial Number__________________ Purchase Date__________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Package Contents...........................5 Hardware Contents..........................5 Safety Instructions...........................5 Preparation ............................6 Assembly or Installation Instructions .....................6 Care and Maintenance .........................10 Warranty ............................10 Replacement Parts List ........................ 11... -
Page 5: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Cabinet Wall Mounting Spacer Bar (preassembled to Cabinet (A)) Shelf Drawer Divider Drawer box Upper Drawer (preassembled to Cabinet (A)) Lower Drawer (preassembled to Cabinet (A)) HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Touch Up Pen Handle (2 Options) Shelf Pin Qty. -
Page 6: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 30 minutes. Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, power drill with drill bit. - Page 7 INSTALLATION INSTRUCTIONS 3. Clean area where the cabinet (A) will be permanently located prior to beginning installation, ensuring the cabinet (A) will not interfere with any plumbing or electrical lines once mounted. Locate wall studs and mark locations. With the help of another adult, place completed cabinet assembly in its final location.
- Page 8 INSTALLATION INSTRUCTIONS 5. Insert two drawer dividers (D) into the notch of upper drawers (F) inside. Place the two drawer boxes (E) flat in the lower drawer (G). 6. As shown in the diagram, fully extend the drawer and locate the plastic levers on the metal glide tracks.
- Page 9 INSTALLATION INSTRUCTIONS 7. To reinstall drawer(s) into cabinet (A), fully extend metal glide tracks. Gently lower and slide drawer box into rear glide catch. Next, lower drawer box down to completely rest on extended glides. Then, push plastic levers to lock the drawer box in place. Note: Drawer box alignment can be adjusted, if necessary.
-
Page 10: Care And Maintenance
CARE AND MAINTENANCE • Dust the floor cabinet regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the floor cabinet with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 11: Replacement Parts List
REPLACEMENT PARTS LIST FOR 1480FC-24-201 For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m., EST, Monday - Friday. PART DESCRIPTION PART # Wall Mounting Spacer Bar FC-WALL MOUNTING BAR-201 Shelf 1480FC-24-201-SHELF Drawer Divider 1480FC-24-201-DIVIDER... - Page 12 REPLACEMENT PARTS LIST FOR 1480FC-24-283 For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m., EST, Monday - Friday. PART DESCRIPTION PART # Wall Mounting Spacer Bar FC-WALL MOUNTING BAR-283 Shelf 1480FC-24-283-SHELF Drawer Divider 1480FC-24-283-DIVIDER Drawer Box 1480FC-24-283-DRAWER BOX 1480FC-24-283-...
