4.3.1

Euro torch connector without control cable

Item Symbol
1
2
3
4
4.3.2

Euro torch connector with control cable

Item Symbol
1
2
3
4
5
099-700003-EW501
14.09.2020
Product description – quick reference
Description 0
Anti-kink spring
Euro central connection
Welding current, shielding gas and torch trigger included
Quick connect coupling, blue (coolant supply)
Quick connect coupling, red (coolant return)
Description 0
Anti-kink spring
Euro central connection
Control cable plug
Only for control variant 2U/D.
Quick connect coupling, blue (coolant supply)
Quick connect coupling, red (coolant return)
Figure 4-3
Figure 4-4
Function torch
