ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
PLD2850RDC0
Series
24" Built-in
Color
stainless
Owner's Guide
154493801
Service Data Sheet
154493101
Energy Guide
154494101
Installation Instructions 154427301
Market
North America
Publication No.
5995415972
04/09/07
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
PLD2850RD
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire PLD2850RD
Summary of Contents for Frigidaire PLD2850RD
- Page 1 24" Built-in Color stainless Owner's Guide 154493801 Service Data Sheet 154493101 Energy Guide 154494101 Installation Instructions 154427301 Market North America 24-INCH BUILT-IN DISHWASHER PLD2850RD Publication No. 5995415972 04/09/07 (EN/SERVICE/ECL) © Copyright 2004 Electrolux Home Products, Inc. Model No. All rights reserved.
-
Page 2: Control Panel
Publication No: 5995415972 PLD2850RDC0 CONTROL PANEL 09/04... - Page 3 POS. NO PART NO. 154486103 154459903 154522805 154200401 154460601 154478901 154474801 154486201 154423601 154436201 154433501 154474401 154468901 154494101 5303322387 # Functional Parts * Non-Illustrated Parts PLD2850RDC0 CONTROL PANEL DESCRIPTION Panel, control, black Insert, control panel, black, w/12p switch Board, control Screw, 6-10 x 3/8, pan plask Cover, control Gasket, cover...
- Page 4 Publication No: 5995415972 PLD2850RDC0 DOOR 09/04...
- Page 5 POS. NO PART NO. 154430601 154325201 154093301 154325302 154325301 154400601 154079601 154494601 154452704 154294701 154103702 12 # 154529403 154481102 154253201 5304428306 154470405 154297603 154211401 154320301 154425001 316279700 154409401 # Functional Parts * Non-Illustrated Parts PLD2850RDC0 DOOR DESCRIPTION Spring, door, (2) Linkage, door spring, (2) Screw, arm assy, (4) Arm Assy, LH...
- Page 6 Publication No: 5995415972 PLD2850RDC0 09/04...
- Page 7 POS. NO PART NO. 154534701 154429101 154211801 154200602 154333902 5303943103 154446002 5303318539 24 # 154411003 25 # 154209701 154408701 29 # 154290204 154241101 154297701 154447102 154447301 154041001 5300807270 # Functional Parts * Non-Illustrated Parts PLD2850RDC0 DESCRIPTION Tub assy, w/frame parts Strike, door Gasket, tub Screw, 10-16 x 3/8, hex...
-
Page 8: Motor & Pump
Publication No: 5995415972 PLD2850RDC0 MOTOR & PUMP 09/04... - Page 9 POS. NO PART NO. 154482901 154106201 154289801 154465101 154245501 154246801 154461902 154246502 5304404947 154467702 154468502 154478201 154464101 154491101 154406401 154348401 154348502 154106801 154380601 154234401 154362301 5303316032 154246402 154246901 154247001 154491301 5303318719 154463402 154294102 154252201 154252302 154283005 154252702 70 # 154523501 71 # 154473901 154200601...
