Frigidaire PLD2855RFC Factory Parts Catalog

24-inch built-in dishwasher
Hide thumbs

Advertisement

P30L0060.eps P30C0144.eps P30B0036.eps P30U0021.eps P30M0036.eps P30F0022.eps
P30R0075.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLD2855RFC0
Series
Built-in 24"
Color
stainless
Owner's Guide English 154575701
Owner's Guide Spanish 154575703
Owner's Guide French
154575702
Service Data Sheet
154493101
Energy Guide
154540024
Installation Instructions 154427301
Market
North America
Publication No.
5995469292
06/07/20
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
PLD2855RF
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire PLD2855RFC

  Related Manuals for Frigidaire PLD2855RFC

  Summary of Contents for Frigidaire PLD2855RFC

  • Page 1 Owner's Guide Spanish 154575703 Owner's Guide French 154575702 Service Data Sheet 154493101 Energy Guide 154540024 Installation Instructions 154427301 Market North America 24-INCH BUILT-IN DISHWASHER PLD2855RF Publication No. 5995469292 06/07/20 (EN/SERVICE/ECL) © Copyright 2006 Electrolux Home Products, Inc. Model No. All rights reserved.
  • Page 2: Control Panel

    Publication No: 5995469292 PLD2855RFC0 CONTROL PANEL 07/06...
  • Page 3 POS. NO PART NO. 154486103 154459903 154555005 154200401 154554601 154478901 154474801 5303318719 154486201 154423601 154436201 154433501 154474401 154546901 154540024 # Functional Parts * Non-Illustrated Parts PLD2855RFC0 CONTROL PANEL DESCRIPTION Panel, control, black Insert, control panel, black, w/12p switch Board, control Screw, 6-10 x 3/8, pan plask Cover, control Gasket, cover...
  • Page 4 Publication No: 5995469292 PLD2855RFC0 DOOR 07/06...
  • Page 5 POS. NO PART NO. 154430601 154325201 154093301 154558103 154558503 154529101 154079601 154494603 154542104 154294701 154103702 12 # 154529403 154533201 154253201 5304428306 154470405 154297603 154211401 154320301 154425001 154409401 # Functional Parts * Non-Illustrated Parts PLD2855RFC0 DOOR DESCRIPTION Spring, door, (2) Linkage, door spring, (2) Screw, arm assy, (4) Arm Assy, LH Arm Assy, RH...
  • Page 6 Publication No: 5995469292 PLD2855RFC0 07/06...
  • Page 7 POS. NO PART NO. 154594101 154429101 154561002 154200602 5304456938 5303943103 154446002 5303318539 24 # 154525301 25 # 154209702 154408701 29 # 154290204 154241101 154297701 154447102 154447301 154041001 5300807270 # Functional Parts * Non-Illustrated Parts PLD2855RFC0 DESCRIPTION Tub assy, w/frame parts Strike, door Gasket, tub Screw, 10-16 x 3/8, hex...
  • Page 8: Motor & Pump

    Publication No: 5995469292 PLD2855RFC0 MOTOR & PUMP 07/06...
  • Page 9 POS. NO PART NO. 154482901 154106201 154289801 154465101 154245501 154246801 154461902 154246502 154467702 154468502 154478202 154464101 154491101 154406401 154106801 154380601 154234401 154362301 5303316032 154246402 154246901 154247001 154491301 5303318719 154463402 154294102 154252201 154252302 154283005 154252702 70 # 154574701 71 # 154473901 154376001 154200601 # Functional Parts...
  • Page 10 Publication No: 5995469292 PLD2855RFC0 FRAME 07/06...
  • Page 11 POS. NO PART NO. 154476101 154208701 154589403 154589503 5300808658 154200701 154200601 154571101 154209601 154412301 154290101 154290001 154041001 154200602 154409401 # Functional Parts * Non-Illustrated Parts PLD2855RFC0 FRAME DESCRIPTION Valve, water Brace, front frame Toeplate, adjustable, black Kickplate Assy, black Screw, #8A x .375", black Screw, #10-32 x 3/8 Screw, #10-16 x 3/8 Leg, leveling, (4)
  • Page 12 Publication No: 5995469292 PLD2855RFC0 RACKS 07/06...
  • Page 13 POS. NO PART NO. 154432604 154424002 154424102 154494404 154494502 5304440996 154232701 154174503 154466902 154436104 154425503 154480403 154480503 154428402 154242002 14A* 154242102 154424203 154424303 154530702 154530902 154570402 154570502 # Functional Parts * Non-Illustrated Parts PLD2855RFC0 RACKS DESCRIPTION Rack assy, lower, grey Basket, silverware, grey, main Basket, silverware, grey, (2), side Rack assy, upper, grey...
