PRODUCT NO.
FDBC45BAB2
FDBC45BAS2
MARKET
North America
SERVICE DATA SHEET # - 154441701
OWNER'S GUIDE # - 154436501
INSTALLATION INSTRUCTIONS # - 154427301
ENERGY GUIDE LABEL # - 154399010
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDBC45BA
24" Built-in
FDBC45BA
24" Built-in
Publication No.
5995379350
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
black
white
021007
©2002 Electrolux Home Products, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
FDC45BA
