Olimpia electronics POWER LIGHT Series Manual

``POWER LIGHT`` SERIES FOR NON MAINTAINED EMERGENCY LUMINAIRES

TECHNICAL CHARACTERISTICS

OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Pb)
BATTERY PROTECTION
INDICATIONS - CONTROLS
CHARGING TIME
MINIMUM AUTONOMOUS DURATION
LIGHT SOURCE
EMERGENCY ILLUMINATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
GENERAL
These luminaires are used indoors (ta 40 C)
where emergency light is needed. Each
luminaire must be permanently connected to
mains power supply. In normal operation the
power indicator lights and the charge
indicator blinks to show that the batteries are
in charging condition. In case of a mains
power supply failure
charge indicators turns off and the luminaire
will light the spot lamps automatically in
emergency mode. When the mains power
supply is restored the device turns to normal
operation.
INSTALLATION
To install the luminaire follow the installation
instructions οn page 3.
OPERATION
When the device is powered from the mains,
the charge indicator blinks and confirms the
charging of the batteries. When the batteries
are charged, it lights constantly. If it does not
light, probably,
disconnected. If it does not light and the
batteries are connected, then contact the
technician. As long as the charge indicator
blinks, the batteries of the luminaire are
Page 1 from 3
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
Thank you for your trust in our products
Olympia Electronics - European manufacturer
the power and the
the batteries
(for LED MODULE Specifications see page 2)
GRL-21
220-240V AC/50-60Hz
5.6W/7.5VA
6V/4Ah
From overcharge and deep discharge
Power indicator, battery charge indicator, TEST button
90 min
White LEDs
790lm
IP42
5 to 40 C
Up to 95%
ABS/PC, PC
302 x 94 x 345 mm.
2080gr.
3 years (1 year for the battery)
charging and in this period, any autonomy test
o
must be avoided. When the charging circle is
complete, the indicator lights continuously (it
can be used as an indication of a power
interruption). The batteries charging is done by
a 3 stages technological advanced procedure,
to ensure the appropriate and full charging of
the batteries. The power indicator confirms the
proper connection to the mains. The TEST
button, has a dual use. If pressed instantlly
while the device is connected to the mains, the
device simulates the power interruption, by
lighting the lamps for 3''. In this way, we can
control the driver circuit of the lamps and the
lamps as indicated in paragraph 3 in the text
below.
DIMMING OPTION
When the voltage is interrupted, with
corresponding pressings of the button, we can
choose the illumination of 100%, 50%, 33% or
turned off, either to increase the autonomy time
or not to consume the battery power
unnecessarily. This option is canceled when the
are
network is restored.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance or
GRL-29
14.4W/16VA
12V/7Ah
24h
180 min
1620lm
o
3560gr.
