WATERPROOF NON-MAINTAINED LUMINARIES
TECHNICAL CHARACTERISTICS
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Ni-Cd)
BATTERY PROTECTION
INDICATIONS
CHARGE TIME
MINIMUM DURATION
LIGHT SOURCE
EMERGENCY ILLUMINATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIAL
EXTERNAL DIMENSION
WEIGHT
GUARANTEE
GENERAL
These devices are used indoors (ta 40 C)
in places where emergency luminaires are
needed. The luminaires GR-470/WP and
GR-472/WP are suitable for corridors
lighting and the GR-471/WP and GR-
473/WP for open area lighting. Each
device must be permanently connected to
mains power supply. In normal operation
the battery is charging. In case of a mains
power supply failure the device will light
the illumination led automatically in
emergency mode. When the mains power
supply is restored the device turns to
normal operation.
INSTALLATION
To install the luminaire follow the
Installation Instructions οn page 2.
ΑΤΤΕΝΤΙΟΝ
!!!
1. Operations for installation, maintainance
or testing must be done by authorized
personel only.
2. The device must be connected to the
mains power supply thru a fuse dependent
by the total amount of the line's
load.
3. It is suggested to check every month the
indication LED for battery charging, and by
Page 1 from 6
GR-470/WP
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
158 x 158 x 60,4mm (without decorative bezel)-195 x 195 x 60,4 (with decorative bezel)
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
power
(for LED MODULE specifications see page 4)
GR-471/WP
220-240V AC / 50-60Hz
2,6W / 2,9VA
3,6V/1 Ah
Deep discharge and overcharge protection
Charge LED, Magnetic Test Contact
1,5 hour
1 white power LED
145lm
5 to 40 C
Up to 95%
ABS/PC, PC
3 years (1 year for the battery)
placing the test card
o
operation test is initiated, to check the
emergency cirquit. The illumination source
should light as long as the card is present
In the opposite condition contact the
installer.
4. It is sugested to check every 6 months
the minimum autononous duration by
disconnecting the mains power supply.
Count the time that the luminaire lights and
in case of less time than the minimum
autonomous duration the battery must be
r e p l a c e d . I f t h e m e a s u r e d t i m e i s
considerably less than the minimum
autonomous duration
I n c a s e o f b a t t e r y o r l i g h t s o u r c e
replacement, these must be replaced by
parts of the same type, by the manufacturer
or by a competent person.
5. In case of inactive use for a period
greater than 2 months, disconnect the
b a t t e r y b y p u l l i n g o u t t h e b a t t e r y 's
connector.
6. I s not allowed to discard batteries in
t i
to common trash bins, they must
be discarded only
recycling points. Do not incinerate.
GR-472/WP
24 hours
3 hour
80lm
IP65
o
470gr.
(A-1900)
contact the installer.
923473000_09_001
GR-473/WP
(page 5) an
.
in battery
Advertisement
Table of Contents
Related Manuals for Olimpia electronics GR-470/WP
Summary of Contents for Olimpia electronics GR-470/WP
- Page 1 These devices are used indoors (ta 40 C) emergency cirquit. The illumination source in places where emergency luminaires are should light as long as the card is present needed. The luminaires GR-470/WP and In the opposite condition contact the GR-472/WP are suitable for corridors installer.
- Page 2 4. Reinstall the diffusor and re-tighten the 4 screws in a diagonally manner with a torque of 0,9 N*m. NOTE!! After finishing the installation you must power the luminaire for at least 24 hours in order to completely charge the batteries. The rated autonomous duration can be achieved after this. GR-470/WP, GR-472/WP GR-471/WP, GR-473/WP Open Corridor...
- Page 3 MOUNTING IN SUSPENDED CEILING plastic mounting luminary’s bracket base Required opening 14,5*14,5cm plastic plugs plastic plugs screws screws 1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the four retaining screws (figure 1) without removing them and remove the diffusor. 2.
- Page 4 MOUNTING IN SUSPENDED CEILING Other SURFACE MOUNTING possible Cable entry holes washer rabber o-ring 1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the four retaining screws without removing them and remove the diffusor. 2.
- Page 5 LED MODULE CHARACTERISTICS GR-470/WP GR-471/WP GR-472/WP GR-473/WP Olympia Electronics S.A. Manufacturer Model Number 0205183 Voltage Range 5.6-6.6V DC Nominal Power Connections fixed connection between main pcb and led module Temperature (tc) 55 °C max. across the board Manual TEST with the A-1900 Test card (not included and is available only on request).
- Page 6 WARRANTY Olympia Electronics guarantees the quality, condition and operation of the goods. The period of warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet, which accompanies each product. This warranty ceases to exist if the buyer does not follow the technical instructions included in official documents given by Olympia Electronics or if the buyer modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia Electronics has fully agreed to them in writing.
