EDG-13H KEY FEATURES:
• Nominal steady-state intensity of 15,000 µW/cm
• Large coverage area of 18 inches x 16 inches with a minimum UV-A intensity
of 1,000 µW/cm
• Less than 2.0 foot-candle (22 lux) visible light emission.
• Long-lasting UV-A Lenses.
• Cool running, fanless design.
• Multiple units can be ganged together, utilizing a single power source.
• Adjustable mounting bracket.
• IP65 Rated: The EDGE™ 13 Series lamps are protected from total dust ingress
and from low pressure jets of water (from all directions). For more details,
consult EN 60529 (British BS EN 60529:1992, European IEC 60509:1989).
• The EDGE™
Meets EN ISO 3059 standards for non-destructive testing.

FIRST USE

• The EDGE™ 13 UV-A LED flood lamp is shipped factory set at the specified
intensity for optimal performance during inspections.
• Carefully unpack and inspect the lamp for possible damage during shipment.
If any damage is noted, immediately notify the carrier and supplier before
attempting to use the lamp.
• Make tests in a darkened area for best fluorescent response.
• Prior to plugging the unit into a grounded receptacle, ensure that the power
switch is in the OFF position. The EDG-13H lamps have a two-position rocker
switch (O = off; I = on).
• Push the power switch to the ON position. Instant-on operation ensures that
each of the UV-A LEDs reaches full intensity very quickly. Check to see if the
unit is operating optimally.
UV emitted from this product. Avoid eye and skin exposure to unshielded products.
.
2
13 is CE,
WARNING
FOR PROFESSIONAL EXAMINATION USE ONLY
2
CCC, RoHS,
2
at 15 inches (38cm).
and WEEE compliant.
