Technical data
Technical data – General
Gas category
Diameter of the gas pipe
Diameter of the heating
connections
Expansion relief valve con-
nection pipe (min.)
Condensate discharge
pipe (min.)
G20 gas supply pressure
Gas flow at P max. – do-
mestic hot water (G20)
Gas flow at P max. – heat-
ing mode (G20)
Gas flow at P min. (G20)
CE number (PIN)
SAP 2009/2012 annual effi-
ciency (%)
Flue gas mass flow rate in
heating mode at P min.
Flue gas mass flow rate in
heating mode at P max.
Flue gas mass flow rate in
domestic hot water mode
at P max.
Flue gas temperature (80
°C/60 °C) at P max.
Flue gas temperature (80
°C/60 °C) at P min.
Flue gas temperature (50
°C/30 °C) at P max.
Flue gas temperature (50
°C/30 °C) at P min.
Flue gas temperature in
domestic hot water mode
Flue gas temperature when
overheating
Released system types
Nominal efficiency at 80/60
°C
Nominal efficiency at
50/30 °C
Nominal efficiency at
40/30 °C
Nominal efficiency in par-
tial load operation (30%) at
40/30 °C
NOx class
Product dimensions, width
Product dimensions,
height
Net weight
Weight when filled with
water
0020238431_03 EASICOM 3 Installation and maintenance instructions
EASICOM 3
25r - A (H-
GB)
I
2H
1/2 inch
3/4 inch
15 mm
21.5 mm
2.0 kPa
(20.0 mbar)
3.2 m³/h
2.7 m³/h
0.648 m³/h
CE-
0063CP3646
89.7
2.81 g/s
11.5 g/s
13.8 g/s
77 ℃
55 ℃
62 ℃
35 ℃
68 ℃
95 ℃
C13, C33,
C53
98.8 %
104.0 %
106.0 %
109.7 %
6
375 mm
602 mm
22 kg
27 kg
Technical data – G20 power/load G20
Maximum heat output
Effective output range (P)
at 40/30 °C
Effective output range (P)
at 50/30 °C
Effective output range (P)
at 80/60 °C
Domestic hot water heat
output (P)
Maximum heat input –
heating (Q max.)
Minimum heat input – heat-
ing (Q min.)
Maximum heat input – do-
mestic hot water (Q max.)
Minimum heat input – do-
mestic hot water (Q min.)
Technical data – Heating
Max. flow temperature ad-
justment range (default
setting: 75 °C)
Maximum permissible
pressure
Nominal water flow
(ΔT = 20 K)
Nominal water flow at
Pmin (ΔT = 20 K)
Nominal water flow
(ΔT = 30 K)
Nominal water flow at
Pmin (ΔT = 30 K)
Approximate value for the
condensate volume (pH
value between 3.5 and 4.0)
at 50/30 °C
Technical data – Electrics
Electrical connection
Built-in fuse (slow-blow)
Max. electrical power con-
sumption
Standby electrical power
consumption
IP rating
EASICOM 3
25r - A (H-
GB)
25 kW
6.5 to
27.0 kW
6.4 to
26.5 kW
6.0 to
25.2 kW
6.0 to
30.0 kW
25.5 kW
6.1 kW
30.6 kW
6.1 kW
EASICOM 3
25r - A (H-
GB)
10 to 80 ℃
0.25 MPa
(2.50 bar)
1,085 l/h
9,999 l/h
723 l/h
9,999 l/h
2.55 l/h
EASICOM 3
25r - A (H-
GB)
230 V /
50 Hz
T2/2A, 250V
29 W
2 W
IPX4D
7
