3

Technical data

Technical data – General
Gas category
Diameter of the gas pipe
Diameter of the heating pipe
Expansion relief valve connection
pipe (min.)
Condensed water drain pipework
(min.)
G20 gas supply pressure
Gas flow at P max. – domestic hot
water (G20)
CE number (PIN)
SAP 2009/2012 annual efficiency
(%)
Flue gas mass flow rate in heating
mode at P min.
Flue gas mass flow rate in heating
mode at P max.
Flue gas mass flow rate in do-
mestic hot water mode at P max.
Released system types
Nominal efficiency at 80/60 °C
Nominal efficiency at 50/30 °C
Nominal efficiency in partial load
mode (30%) at 40/30 °C
NOx class
Product dimensions, width
Product dimensions, depth
Product dimensions, height
Net weight
Weight when filled with water
Technical data – G20 power/load G20
Maximum heat output (factory
setting – d.00)
Effective output range (P) at
50/30 °C
Effective output range (P) at
80/60 °C
Domestic hot water heat output
range (P)
Maximum heat input – heating (Q
max.)
Minimum heat input – heating (Q
min.)
Maximum heat input – domestic
hot water (Q max.)
Minimum heat input – domestic
hot water (Q min.)
Technical data – Heating
Maximum heating flow temperat-
ure (factory setting – D.71)
Max. range of the flow temperat-
ure control
0020239562_04 EASICOM 3 Installation and maintenance instructions
EASICOM 3 24c EASICOM 3 28c
I2H I2H
1/2 inch 1/2 inch
3/4 inch 3/4 inch
15 mm 15 mm
21.5 mm 21.5 mm
20 mbar 20 mbar
2.6 m³/h 3.0 m³/h
CE-0063CP3646 CE-0063CP3646
89.6 89.6
2.34 g/s 2.80 g/s
9.2 g/s 11.1 g/s
11.1 g/s 12.9 g/s
C13, C33 C13, C33
98.9 % 99 %
104 % 104 %
109.8 % 108.5 %
5 5
418 mm 418 mm
300 mm 300 mm
740 mm 740 mm
32 kg 32.6 kg
36 kg 37.1 kg
EASICOM 3 24c EASICOM 3 28c
20 kW 24 kW
5.3 to 21.2 kW 6.3 to 25.7 kW
5.0 to 20.2 kW 6.1 to 24.4 kW
5 to 24.2 kW 6 to 28 kW
20.4 kW 24.7 kW
5.1 kW 6.1 kW
24.7 kW 28.6 kW
5.1 kW 6.1 kW
EASICOM 3 24c EASICOM 3 28c
75 ℃ 75 ℃
10 to 80 ℃ 10 to 80 ℃
7
