Anti-masking
To test the anti-masking system, follow these steps:
1. Put the power on. Seal microphone completely with elastic
material like plasticine, chewing gum or isolation tape.
INTRUSION and FAULT relays will open after max.
of 180 s signalling masking of microphone.
2. Remove sealing material from microphone. Relays will
close in less than minute.
Understanding the LED when the detector
is in operation
The LED can have the following states in operation:
•
Flashes 1 to 3 times when powered ON: Indication of
range setting after power-on
•
Off: Normal state, no alarms
• Permanently on: Intrusion detected – if detector in Latch
mode
•
Permanently on with 1 dip per 3 s: Masking detected
•
Permanently on with 2 dips per 3 s: Low supply voltage or
self-test failure
• Short blink: Antimasking warning – foreign object in close
proximity of microphone
Understanding the LED when testing the
detector with GS960-TR tester
The LED can have the following states during the test:
•
Flickers: In test mode
•
Flickers and blinks: In calibration mode
•
Flashes 1.5 s: Confirms received signal
•
Blinks slowly 1 time each 2.5 s after calibration: Set range
setting to Zone 1 (4 to 9 m)
•
Blinks slowly 2 times each 2.5 s after calibration: Set
range setting to Zone 2 (2 to 4 m)
•
Blinks slowly 3 times each 2.5 s after calibration: Set
range setting to Zone 3 (1 to 2 m)

Troubleshooting

Detector does not respond:
•
Check the supply voltage and polarity
LED permanently on:
•
Switch off the detector for a short period
•
Check if LED is in latching mode (DIP 1 ON)
LED permanently on with 1 dip per 3 s:
•
Check if microphone not masked with foreign material
LED permanently on with 2 dips per 3 s:
• Check supply voltage – it should be higher than 7 V
No alarm:
•
Check the INTRUSION and FAULT relay wiring
•
Check the alarm loop wiring
P/N 422-6368-ML • REV E • ISS 03DEC18

Specifications

Type (thickness) of protected glass:
Minimum
Maximum
Size of protected glass
Max range
Range setting
Supply voltage
Max. voltage ripple
Voltage monitoring
Current consumption, max.
D/N signal levels
INTRUSION output, FAULT output
INTRUSION and FAULT relay
contact rating
TAMPER contact rating
Intrusion/fault indication
Environmental class EN 50130-
5:2011, VdS 2110
Operating temp. range
Operating humidity range
Housing material
Dimensions (W x H x D)
Security grade
Approvals
Accessory
Regulatory information
Manufacturer PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092,
USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings THESE PRODUCTS ARE INTENDED FOR
and disclaimers SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
Float (4 mm)
Laminated P4 (4 + 4 mm)
40 × 40 cm min.
9 m radius/165°
Zone 1: 4 to 9 m
Zone 2: 2 to 4 m
Zone 3: 1 to 2 m
7 to 30 V DC
2 Vp-p at 12 V, 4 Vp-p at 24 V
Fault signalled at < 7 V
11.4 mA at 12 V, 7.2 mA at
24 V
DAY: D/N open or < 2.5 V,
NIGHT: D/N > 2.5 V
Relay
50 mA, 50 V DC / peak AC,
Rs ≤ 30 Ω
50 mA / 50 V DC / peak AC
LED
Class I
+5 to 40°C
Max. 93% RH
Plastic ABS, white
68 x 109 x 40 mm
EN 50131-2-7-1:2012/A1:2013,
Grade 3; VdS 2332, class B
VdS: G118505
GS960-RB plug-in EOL resistor
board
or scan the QR code.
5 / 14
