Quick Reference Guide

For models with electronic controls only.

Room Air Conditioner

1

TO START UNIT

Touch the Power button. The unit will automatically be in regular COOLING
mode with the temperature set at 75°F (24°C) and the fan speed at F1
(SLEEP).
2

TO ADJUST TEMPERATURE

COOLER – Touch
and hold until the display shows the desired room
temperature.
WARMER – Touch
and hold until the display shows the desired room
temperature.
3

TO ADJUST THE FAN SPEED

Touch Fan Speed until the display shows the desired fan speed. F1 is the
lowest setting (SLEEP SETTING / LOW), F2 is MED, F3 is HIGH, and SF is
SMART FAN. With SMART FAN on, the fan speed will adjust automatically
to maintain the desired comfort level.
4

TO SET THE CLOCK TIME

Touch Set Hour (Clock light on), then press
to the actual time appears in the display. Make sure you set A.M. and P.M.
properly (P.M. is indicated by a red light in the upper left corner of the display).
Minutes will NOT show on the display.
For complete operating instructions refer to your Installation & Operation Manual.
or
until the hour closest
PM
3
Fan
Speed
Mode
Timer
Set
Hour
On/Off
5
4
5

TO SET THE TIMER

START TIME – After the clock time has been set, press Set Hour (Start
Time light on) then press
come on appears in the display.
STOP TIME – After the start time has been set, press Set Hour (Stop
Time light on), then press
shut off appears in the display.
Touch Timer On/Off (light on) to activate the timer function. Touch Timer
On/Off (light off) to cancel the timer function. Once the on and off times
have been selected, they will remain in memory. However, if the power
is interrupted, set the clock time again.
920-199-00 (7-06)
1
Power
Cool
Money Saver
®
Fan Only
2
Clock
Start Time
Stop Time
Temp/Hour
and
until the hour you want the unit to
and
until the hour you want the unit to
