Page 1
All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Current Tools does not assume any liability for damages resulting from misuse or incorrect application of its products.
Page 2
Parts List — Model 751 Mechanical Bender . . . . . . . . . . . . . . . . .
Page 3
RETAIN SAFETY INFORMATION This manual should be read and understood by all personnel who operate or service this Mechanical Bender. Failure to understand how to safely operate and service this unit could result in injury or death. This unit should only be operated or serviced by qualified personnel. IMPORTANT SAFETY INFORMATION Follow ALL safety information provided by the manufacturer.
Page 4
SPECIFICATIONS Model No. Capacity 1¼" and 1½" RIGID and IMC conduit and schedule 40 pipe Overall Dimensions 48" L x 24" W x 38 ¹/ " H Weight 104 lbs. OPERATING INSTRUCTIONS 1. Cut a 5' length of 1" RIGID conduit and insert it into the ratchet arm as shown in Figure 1.
Page 5
MAINTENANCE Monthly: Apply multi-purpose grease at grease fitting. See Item #38 on Exploded View on Page 7. STUB BENDING INFORMATION To locate bending marks for stubs: 1. Check the Stub Dimensions Chart (below) for Minimum Stub Length. The stub being bent must be equal to or longer than the Minimum Stub Length. 2.
Page 6
OFFSET BENDING INFORMATION To mark conduit for offsets: 1. Measure distance from end of conduit to start of first bend and mark conduit. This is mark #1. See Figure 1 and 2. 2. Refer to Deduct Chart and deduct this length from mark #1 and place mark #2 on conduit.
Page 7
EXPLODED VIEW — Model 751 Mechanical Bender...
