OWNER'S MANUAL
AIR
CONDITIONER
Read this owner's manual thoroughly before operating the appliance and keep it
handy for reference at all times.
TYPE: WALL MOUNTED
EN
English
IT
Italiano
EL
Ελληνικά
PT
Português
BG
Български
HR
Hrvatski
MFL70270101
Rev.02_013018
ES
Español
FR
Français
NL
Nederlands
PL
Polski
Copyright © 2017 - 2018 LG Electronics Inc. All Rights Reserved.
DE
Deutsch
HU
Magyar
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S4-W09M2MZA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG S4-W09M2MZA

Summary of Contents for LG S4-W09M2MZA

  • Page 1 Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. TYPE: WALL MOUNTED English Italiano Español Français Deutsch Ελληνικά Português Nederlands Polski Magyar Български Hrvatski www.lg.com MFL70270101 Rev.02_013018 Copyright © 2017 - 2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    Using the Comfort Air Function ..............19 Using the Energy Control Function ............20 Using Special Functions ................21 SMART FUNCTIONS .............23 Using LG SmartThinQ Application ............23 MAINTENANCE ..............26 Clean the Air Filter ...................27 Clean the 3M Filter ..................27 Clean the Ionizer ..................28...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 Installation •Do not install the air conditioner on an unstable surface or in a place where there is danger of it falling. •Contact an authorized service center when installing or relocating the air conditioner. •Install the panel and the cover of the control box safely. •Do not install the air conditioner in a place where flammable liquids or gases such as gasoline, propane, paint thinner, etc., are stored.
  • Page 5 •Do not use the air conditioner for an extended period of time in a small place without proper ventilation. •In the event of a gas leak (such as Freon, propane gas, LP gas, etc.) ventilate sufficiently before using the air conditioner again. •To clean the interior, contact an authorized service center or dealer.
  • Page 6 •The appliance shall be installed in accordance with national wiring regulations. •When the power cord is to be replaced, the replacement work shall be performed by authorized personnel using only genuine replacement parts. •This appliance must be properly grounded to minimize risk of electric shock. •Do not cut or remove the grounding prong from the power plug.
  • Page 7 •Install the air conditioner in a place where the noise from the outdoor unit or the exhaust fumes will not inconvenience the neighbors. Failure to do so may result in conflict with the neighbors. Operation •Remove the batteries if the remote control is not to be used for an extended period of time.

  • Page 8: Notes For Operation

    • Open windows regularly for ventilation. The indoor air quality may deteriorate if the air conditioner is used for long durations. • Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may block the air flow or reduce the unit performance. Specifications S4-W09M2MZA S4-W12M2MZA Unit (S4NW09M2MZA/ (S4NW12M2MZA/...

  • Page 9: Operation

    OPERATION Parts and Functions Indoor Unit Outdoor Unit On/Off Button Coolant Piping Signal Receiver Drain Hose Operation Lamp Connection Wire Ionizer Base Plate Air Deflector (Vertical Louver) Air Outlet Vents Air Deflector (Horizontal Vane) Air Intake Vents Air Outlet 3M Filter Air Filter Front Panel Indoor Display Screen...

  • Page 10: Wireless Remote Control

    Wireless Remote Control Operating Method Point the remote control towards the signal receiver Inserting Batteries at the right side of the air conditioner to operate it. If the display screen of the remote control begins to fade, replace the batteries. Insert AAA (1.5 V) batteries before using the remote control.
  • Page 11 Setting the Current Time Press the ON/OFF button. Insert batteries. • The icon below blinks at the bottom of the display screen. Press button to select the minutes. Press SET/CANCEL button to finish. Close the front panel as soon as you press the ON/OFF button.
  • Page 12 Using Wireless Remote Control You can operate the air conditioner more conveniently with the remote control. Display Description Button Screen To turn on/off the air conditioner. To adjust the desired room temperature in cooling, heating or auto changeover mode. To select the cooling mode. (P.14) To select the heating mode.
  • Page 13 Display Description Button Screen LIGHT To set the brightness of the display on the indoor unit. (P.19) ROOM To display the room temperature. TEMP °C↔°F [5 s] To change unit between °C and °F (P.11) COMFORT To adjust the air flow to deflect wind. (P.19) ENERGY To bring the effect of the power saving.

  • Page 14: Restarting The Air Conditioner Automatically

    Restarting the Air Using the Mode Function Conditioner Automatically This function allows you to select the desired function. When the air conditioner is turned on again after a Cooling & Heating Model power failure, this function restores the previous settings. Cooling Mode Disabling Auto Restart Open the front cover.
  • Page 15 Heating Mode Dehumidification Mode This mode removes excess moisture from a highly Turn the appliance on. humid environment or during the rainy season, in order to prevent mildew from setting in. This mode Press MODE button repeatedly to select the adjusts the room temperature and the fan speed Heating Mode.

  • Page 16: Using The Jet Mode Function

    Using the Jet Mode Function Auto Changeover Mode This mode changes the mode automatically to Changing Room Temperature maintain the set temperature at ±2 °C Quickly Turn the appliance on. This function allows you to cool indoor air quickly during the summer or warm it quickly during winter. Press MODE button repeatedly to select the Auto •...

  • Page 17: Using The Fan Speed Function

    Using the Fan Speed Using the Air Flow Direction Function Function This function adjusts the direction of the air flow Adjusting the Fan Speed vertically (horizontally). • Press FAN SPEED button repeatedly to adjust the • Press ) button repeatedly and select the SWING SWING fan speed.

  • Page 18: Setting The On/Off Timer

    Setting the On/Off Timer Setting the Off Timer This function sets the air conditioner to turn on/off Press button repeatedly. TIMER automatically at desired time. • The icon below blinks at the bottom of the On/Off Timer can be set together. display screen.

  • Page 19: Using The Sleep Function

    Using the Sleep Function Using the Light Off Function This function turns off the air conditioner Display Screen Brightness automatically when you go to sleep. You can set the brightness of the indoor unit display Turn the appliance on. screen. •...

  • Page 20: Using The Energy Control Function

    Using the Energy Control Function Turn the appliance on. Press ENERGY CTRL button. • Press ENERGY CTRL button repeatedly to select each step. 1 step 2 step 3 step NOTE • 1 step : The power Input is decreased by 20 % compared to rated power input.

  • Page 21: Using Special Functions

    Using Special Functions Canceling Special Functions Press FUNC button repeatedly to select the Turn the appliance on. desired function. Press FUNC button repeatedly to select the Press SET/CANCEL button to cancel the desired function. function. Press SET/CANCEL button to finish. Using the Air Purification Function These functions supply clean and fresh air by ion particles and the filter.
  • Page 22 Using the Silent Function NOTE • This function is available with Heating Mode. This function prevents potential claims by neighbors, • During LH operation, when you press buttons such reducing noise from outdoor units. , MODE, FAN SPEED, and then return •...

  • Page 23: Smart Functions

    NOTE NOTE • To verify the Wi-Fi connection, check that Wi-Fi • If you choose the simple login to access the LG icon on the control panel is lit. SmartThinQ application, you must go through the • The appliance supports 2.4 GHz Wi-Fi networks appliance registration process each time you only.
  • Page 24 Product Registration Using the Wi-Fi Modem Power Off Function Run the LG SmartThinQ application on a smart To reduce power consumption, you can turn off the phone. Wi-Fi modem. • Press and hold the and FAN SPEED button Create an account and sign in.
  • Page 25 LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

  • Page 26: Maintenance

    MAINTENANCE WARNING • Before cleaning or performing maintenance, disconnect the power supply and wait until the fan stops. If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition.

  • Page 27: Clean The Air Filter

    Clean the Air Filter Clean the 3M Filter Clean the air filters once every 2 weeks, or more, if Turn off the power to the unit. necessary. Turn off the power to the unit. Remove the air filters from the indoor unit. Open the front cover.

  • Page 28: Clean The Ionizer

    Clean the Ionizer Turn off the power to the unit. Use dry cotton bud to remove any dust. Ionizer CAUTION • Turn off the power and unplug the power cord before you perform any maintenance; otherwise it may cause electric shock. •...

  • Page 29: Troubleshooting

    TROUBLESHOOTING Self-diagnosis Function This product has a built-in self-diagnosis function. If an error occurs, the lamp of the indoor unit will blink in 2 second intervals. If this occurs, contact your local dealer or service center. Before Calling for Service Please check the following before you contact the service center.
  • Page 30 Problem Possible Causes Corrective Action • Make sure that there are no curtains, Air is not circulating properly. blinds, or pieces of furniture blocking the front of the air conditioner. • Clean the air filter once every 2 weeks. The air filter is dirty. •...
  • Page 31 • Find the Wi-Fi network connected to your you are trying to connect to is smartphone and remove it, then register incorrect. your appliance on LG SmartThinQ. • Turn off the Mobile data of your Mobile data for your smartphone smartphone and register the appliance is turned on.
  • Page 32 Memo...
