Summary of Contents for HAUSSLER Landscape light
- Page 1 Operating instructions Landscape light Landscape light XL Original operating instructions...
-
Page 2: Table Of Contents
Contents 1 Welcome… ......................3 to the world of milling, kneading, baking, and pasta-making! ........ 3 For your safety ....................4 Table of symbols ...................... 4 Intended use ......................4 Basic rules ........................ 4 Safety information ....................4 3 Product guide .....................6 Product description .................... -
Page 3: Welcome
Häussler. You have decided to purchase our landscape light, a fire under glass for your garden. With its contemporary look and the flame generated, the light adds an unforgettable, appealing atmosphere to any environment. -
Page 4: For Your Safety
The landscape light meets the prescribed, product-specific safety regulations. The landscape light is only intended to be used as an outdoor light. The use of any fuel other than wood pellets is prohibited. Any other use shall be considered improper use. - Page 5 Do not leave infants, children, or animals unatten- ded in the vicinity of the landscape light. Let the landscape light cool down completely before touching it. ⚠ Risk of burns from high flames ...
-
Page 6: Product Guide
3 Product guide Product description You have purchased a very high-quality outdoor light: our Landscape light. This outdoor light is simple to operate, easy-care, and requires virtually no maintenance. With the relevant accessories, it can also be used as a barbecue. - Page 7 Product guide Firing values Value Rated thermal input 5.2 kW/kg Carbon content 3.49% Exhaust mass flow rate 31.3 g/s Dust 2.80 mg Tab. 3: Output and emissions...
-
Page 8: Scope Of Delivery
Scope of delivery 4 Scope of delivery Designation Base Upper section Grate Burner cover Glass insert Glass insert XL Tab. 4: Scope of delivery Please note that the scope of delivery contains either the short glass insert or the XL glass insert, depending on the version ordered. -
Page 9: Setting Up The Device
Place the upper section 2 onto the base 5 . Press down onto the base until it stops. Unpack the separately packaged glass insert 1 and put it on the upper section 2 . Caution: Fragile Your landscape light is now set up and ready to use. -
Page 10: Fuel To Be Used
Fuel to be used 5 Fuel to be used ⚠ WARNING Risk of fatality from explosion Darting flame Never use easily and highly flammable liquids such as denatured alcohol, etc. Never use an accelerant on pellets that have been fired up and are warm. ⚠... - Page 11 Fuel to be used Burning aids Only use wood shaving bundles soaked in wax as a burning aid. They are toxin-free, have a neutral odour and taste, and burn without leaving residue behind. Helpful hint: Optimal flame ignition With Häussler pellet starter, you can optimally ignite the flame.
-
Page 12: Filling And Firing Up
When handling the barbecue, wear barbecue mitts. Use proper barbecue tools with long, heat-resistant handles. Ensure that the landscape light is in a stable, even upright position. Before filling it with pellets, make sure that the grate is in the firing chamber. -
Page 13: Filling Capacity
Filling and firing up Filling capacity Level Filling capacity Burning period approx. 3 kg approx. 1 hour approx. 6 kg approx. 2 hours approx. 9 kg approx. 3 hours The times are only approximate since the burning period may vary with the slider setting and natural draught. - Page 14 Filling capacity Filling Remove the upper section and burner cover Fill the firing chamber with pellets to the from the landscape light and store them out top edge of the grate guide. of the way. Adding starter Firing up Pour some Häussler pellet starter...
- Page 15 Only touch the short glass insert when wearing barbecue mitts. Place the hot short If you’ve just used the barbecue or short glass insert on a heat-resistant surface only. landscape light, be careful with hot compo- nents and use barbecue mitts.
-
Page 16: Cleaning
Let the glass insert cool down completely before cleaning it. Let the landscape light cool down completely before touching it. After each use, remove the ashes from the firing chamber of the landscape light. Always let the firing chamber cool down before emptying the ashes. -
Page 17: Maintenance
Maintenance 8 Maintenance Before each use, check the landscape light for damage. In case of damage, replace the defective part(s) before firing up again. Remove the old grease from the upper section with a cloth at regular intervals and apply a new layer of multi-purpose grease for high temperatures. -
Page 18: Troubleshooting
Troubleshooting 9 Troubleshooting Problem Cause Resolution No flame visible Flame extinguished Carefully remove the upper after firing up section, including the glass insert and burner cover, and fire up again. Flame is too small The burner head and Let the pellets burn out. Wait grate were not cleaned until the device has cooled down before resolving the problem. - Page 19 If a gust of wind unexpectedly blows out the landscape light’s flame, dense smoke may be produced. In case of wind, move the landscape light to a place that is protected against the wind or use a wind deflector.
- Page 20 For your own protection, it is essential to wear barbecue mitts. Burning process Firing up the landscape light again As soon as the burning wood shaving Drop the burning bundle into the firing bundle is held in the smoke-filled glass chamber.
-
Page 21: Disposal
Disposal 10 Disposal Keep the landscape light clean at all times and when disposing of residual materi- als. Do not remove the ashes until they have completely cooled down. Only use the intended containers made of metal or noncombustible materials to dispose of the residual waste or ashes. -
Page 22: Accessories
Accessories 11 Accessories Barbecue attachment Ten minutes after being fired up, the Häussler barbecue is ready for use. Barbecue trouble-free and carbon-neutral – even on your balcony or in an urban environment. Material Cast iron Barbecue attachment outer dimensions W x H 13 x 59 cm Weight 10 kg... - Page 23 Accessories Swissflame fire-lighter Wood shaving bundle soaked in wax. For wood-burning ovens, tile ovens, wood-burning kitchen stoves, fireplaces, barbecues. Burning period 8-10 minutes. Burns toxin-free, neutral odour and taste without leaving residue behind. May be stored indefinitely. 600 g / contents approx. 50 pc. Item number: 201808 Stainless steel maintenance spray Developed specifically for the cleaning, maintenance, and protec-...
- Page 24 Accessories Barbecue/landscape light cover Keeps stormy weather away from your Häussler barbecue. And effortlessly ensures a long service life. Barbecue cover: Item no.: 3/304006 Landscape light cover: Item no.: 3/304007 You will find these accessories and others at www.backdorf.de and in our Häussler catalogues.
-
Page 25: Warranty
Warranty 12 Warranty You will receive a 12-month factory warranty on your device, beginning on the date of the invoice. Karl-Heinz Häussler GmbH produced your device in accordance with the technological state of the art. All devices that leave our factory are made from high-quality materials and were thoroughly inspected. - Page 26 Visit our baking centre… Under the name of Häussler, we have devoted our work to the pleasure of doing it yourself for more than 35 years. We are a family-run company with around 100 employees and our headquarters is in Heiligkreuztal/Upper Swabia. We produce our devices there, including our wood- burning ovens, for example.
- Page 27 Our service for you Information on other destinations and places to stay in the area Cosy consulting rooms Children’s play area Guest toilets with changing tables Seating Loading service On-site service for your devices on our premises We also offer you ...
- Page 28 Karl-Heinz Häussler GmbH Nussbaumweg 1 88499 Heiligkreuztal, Germany Telephone +49 73 71/93 77-0 Fax + 49 73 71/93 77-40 Email: info@backdorf.de Version: 30/10/2019...
