IBM E1-700 Manual

IBM E1-700 Manual

Pci adapter with escala power7 processors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCI Adapter Placement for E1-700, E1-
705, E3-700 or E3-705
REFERENCE
86 A1 87FF 05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1-700 and is the answer not in the manual?

Questions and answers

Related Manuals for IBM E1-700

Summary of Contents for IBM E1-700

  • Page 1 PCI Adapter Placement for E1-700, E1- 705, E3-700 or E3-705 REFERENCE 86 A1 87FF 05...
  • Page 3 PCI Adapter Placement for E1-700, E1-705, E3-700 or E3-705 The ESCALA Power7 publications concern the following models: - Bull Escala E1-700 (Power 710 / 8231-E2B) - Bull Escala E1-705 (Power 710 / 8231-E1C) - Bull Escala E2-700 / E2-700T (Power 720 / 8202-E4B)
  • Page 4 The following copyright notice protects this book under Copyright laws which prohibit such actions as, but not limited to, copying, distributing, modifying, and making derivative works. Copyright © Bull SAS 2012 Printed in France Trademarks and Acknowledgements We acknowledge the rights of the proprietors of the trademarks mentioned in this manual. All brand names and software and hardware product names are subject to trademark and/or patent protection.

  • Page 5: Table Of Contents

    Contents Safety notices ....... . . v PCI adapter placement for the 31E/2B, 31E/1C, or 31E/2C ....1 Supported PCI adapters for the 31E/2B, 31E/1C, or 31E/2C .
  • Page 6 PCI adapter placement for the 31E/2B, 31E/1C, or 31E/2C...

  • Page 7: Safety Notices

    Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition.
  • Page 8 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
  • Page 9 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
  • Page 10 CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.
  • Page 11 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
  • Page 12 CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027) CAUTION: This product contains a Class 1M laser.

  • Page 13: Pci Adapter Placement For The 31E/2B, 31E/1C, Or 31E/2C

    PCI adapter placement for the 31E/2B, 31E/1C, or 31E/2C Find information about the Peripheral Component Interconnect (PCI), PCI-X, and PCI Express (PCIe) adapters that are supported for the 31E/2B, 31E/1C, or 31E/2C systems. The following features are electromagnetic compatibility (EMC) Class B features. See the Class B Notices in the Hardware Notices area.
  • Page 14 Table 2. PCIe adapters supported on the AIX, , or Linux operating system System Feature CCIN Description code 31E/2B, 31E/1C, and 31E/2C 5277 57D2 4-Port Async EIA-232 PCIe 1X LP Adapter (FC 5277; CCIN 57D2) v Low-profile adapter v Extra-high bandwidth v Short, x1 v OS support: AIX and Linux operating systems 31E/2C...
  • Page 15 Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/2C 5773 5773 4 Gigabit PCI Express Single Port Fibre Channel Adapter (FC 5773; CCIN 5773) v Short, x4 v High bandwidth v OS support: AIX and Linux operating systems 31E/2C 5774...
  • Page 16 Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/2B, 31E/1C, and 31E/2C 5272 5732 10 Gigabit Ethernet-CX4 PCI Express Adapter (FC 5272; CCIN 5272) v Low-profile adapter v Short, x8 v OS support: AIX and Linux operating systems 31E/2B, 31E/1C, and 31E/2C 5274...
  • Page 17 Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/2C 5708 2B3B 10 Gb FCoE PCIe Dual Port Adapter (FC 5708; CCIN 2B3B) v Regular full-height v Extra-high bandwidth v PCIe 2.0 adapter with x8 Generation-1 v Convergence enhanced Ethernet (CEE) supported v OS support: AIX, Linux, and operating systems with VIOS.
  • Page 18 Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/1C and 31E/2C 9056 5767 PCIe LP 2-Port 1 GbE TX adapter (FC 9056; CCIN 5767) v Low-profile, PCIe x4 v PCIe 1.0a compliant v High bandwidth v Two full-duplex 10/100/1000 Base-TX UTP connections to gigabit Ethernet (GbE) LANs...
  • Page 19 Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/2C 2055 57CD PCIe RAID and SSD SAS Adapter 3 Gb with Blind-Swap Cassette (FC 2055; CCIN 57CD) v Low-profile adapter, requires two slots v Short, x8 v OS support: AIX, , and Linux operating systems v VIOS attachment requires version 2.2, or later...

  • Page 20: Pci Adapters Placement Rules And Slot Priorities For The 31E/2B, 31E/1C, Or 31E/2C

    Table 2. PCIe adapters supported on the AIX, , or Linux operating system (continued) System Feature CCIN Description code 31E/2C 2894 576C PCI Express 2-Line WAN with Modem (FC 2894; CCIN 576C) v Short, x4 v CIM v OS support: AIX, , and Linux operating systems PCI adapters placement rules and slot priorities for the 31E/2B, 31E/1C, or 31E/2C Find information about the placement rules and slot priorities for the Peripheral Component Interconnect...
  • Page 21 Table 3. PCI slot locations and descriptions Slot Location code Description Adapter size Slot 1 P1-C3 PCIe x8 PCIe PHB0 module A Low-profile Slot 2 P1-C4 PCIe x8 PCIe PHB1 module A Low-profile Slot 3 P1-C5 PCIe x8 PCIe PHB2 module A Low-profile Slot 4 P1-C6...
  • Page 22 Table 4. Adapter slot priorities and maximums for PCIe adapters (continued) Maximum number of adapters supported per Feature code Description system 5260 PCIe2 LP 4-port 1 GbE Adapter (FC 5260; CCIN 576F) v Low-profile adapter v PCIe generation-1 or generation-2, x4 v High bandwidth v Four-port 1 Gb Ethernet v OS support: AIX, , and Linux operating systems...

  • Page 23: Pci Adapter Placement Rules And Slot Priorities For The 31E/1C

    Performance notes Use the information in this section to help determine the maximum number of adapters that can be placed in a system while still maintaining optimum performance. Performance notes regarding GX++ channel adapters Table 4 on page 9 identifies the slot placement priorities and the maximum number of specified adapters that can be installed for connectivity.
  • Page 24 The following PCIe adapters are not supported at PCIe slot 6 (P1-C7): v FC 5277 v FC 5269 v FC 5278 PCIe adapters Use this information to identify slot placement priorities and the maximum number of specified adapters that you can install. Ensure to verify if the adapter is supported for your system. For details about the supported adapters, see “Supported PCI adapters for the 31E/2B, 31E/1C, or 31E/2C”...
  • Page 25 Table 6. Adapter slot priorities and maximums for PCIe adapters (continued) Maximum number Feature of adapters code Description Slot priorities supported 5269 POWER GXT145 PCI Express Graphics Accelerator (FC 1, 2, 3, 4, 5 5269; CCIN 5269) v Low-profile adapter v Short, x1 v OS support: AIX and Linux operating systems 5260...
  • Page 26 Table 6. Adapter slot priorities and maximums for PCIe adapters (continued) Maximum number Feature of adapters code Description Slot priorities supported 5280 PCIe2 LP 2x10 GbE SR 2x1 GbE UTP Adapter (FC 5280; 1, 2, 3, 4, 5, 6 CCIN 2B54) v Low-profile, short, x8 v PCIe 2 v OS support: Linux operating system...

  • Page 27: Pci Adapter Placement Rules And Slot Priorities For The 31E/2C

    Table 6. Adapter slot priorities and maximums for PCIe adapters (continued) Maximum number Feature of adapters code Description Slot priorities supported EC29 PCIe2 LP 2-Port 10 GbE RoCE SR adapter (FC EC29; 1, 2, 3, 4, 5, 6 CCIN EC29) v Low-profile adapter v PCIe generation-2, x8 v Extra-high bandwidth, low latency 10 Gb Ethernet...
  • Page 28 PCI slot descriptions The 31E/2C system has five PCIe x8 G2 low-profile slots and one PCIe x4 low-profile slot. All slots support enhanced error handling (EEH), but are not hot pluggable. Figure 3 shows the rear view of the system with the location codes for the PCI adapter slots. Table 7 provides information about the slots. All slots in this system are low-profile slots only.
  • Page 29 Table 8. Adapter slot priorities and maximums for PCIe adapters Feature Description Slot priorities Maximum number code of adapters supported 5277 4-Port Async EIA-232 PCIe 1X LP Adapter (FC 5277; 1, 2, 3, 4, 5 CCIN 57D2) v Low-profile adapter v Extra-high bandwidth v Short, x1 v OS support: AIX and Linux operating systems...
  • Page 30 Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported 5773 4 Gigabit PCI Express Single Port Fibre Channel Adapter (FC 5773; CCIN 5773) v Short, x4 v High bandwidth v OS support: AIX and Linux operating systems 5774 4 Gigabit PCI Express Dual Port Fibre Channel Adapter...
  • Page 31 Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported 5272 10 Gigabit Ethernet-CX4 PCI Express Adapter (FC 5272; 1, 2, 3, 4, 5, 6 CCIN 5272) v Low-profile adapter v Short, x8 v OS support: AIX and Linux operating systems 5274...
  • Page 32 Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported 5708 10 Gb FCoE PCIe Dual Port Adapter (FC 5708; CCIN 2B3B) v Regular full-height v Extra-high bandwidth v PCIe 2.0 adapter with x8 Generation-1 v Convergence enhanced Ethernet (CEE) supported v OS support: AIX, Linux, and operating systems with VIOS.
  • Page 33 Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported 5899 PCIe2 4-port 1 GbE Adapter (FC 5899; CCIN 576F) 1, 2, 3, 4, 5, 6 v Regular-height adapter v PCIe generation-1 or generation-2, x4 v High bandwidth v Four-port 1 Gb Ethernet...
  • Page 34 Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported 2053 PCIe RAID and SSD SAS Adapter 3 Gb Low-profile (FC 1, 2, 3, 4, 5, 6 2053; CCIN 57CD) v Low-profile adapter, requires two slots v Short, x8 v OS support: AIX, , and Linux operating systems...

  • Page 35: I/O Expansion Units

    Table 8. Adapter slot priorities and maximums for PCIe adapters (continued) Feature Description Slot priorities Maximum number code of adapters supported ESA2 PCIe2 RAID SAS Adapter Dual-port 6 Gb LP (FC ESA2; 1, 2, 3, 4, 5, 6 CCIN 57B4) v Short, low-profile v PCIe generation-2, x8 v OS support: AIX, , and Linux operating systems...

  • Page 36: Pci Adapters Slot Priorities For The 58/02 And 58/77 Expansion Units

    PCI adapters slot priorities for the 58/02 and 58/77 expansion units Learn about the PCI Express (PCIe) slots in the 58/02 and 58/77 expansion units. System description The 58/02 and 58/77 expansion units are 19-inch, rack-mountable, I/O expansion drawers that are designed to be attached to the system using 12X double data rate (DDR) cables.
  • Page 37 v A second I/O chip controls slots P1-C4, P1-C5, and P1-C6. v A third I/O chips controls slots P1-C7, P1-C8, P1-C9, and P1-C10. For best performance, fill P1-C1, P1-C4, P1-C2, P1-C5, P1-C3, and P1-C6 first with the highest bandwidth adapters. Then fill the remaining slots. PCI adapter placement...
  • Page 38 PCI adapter placement for the 31E/2B, 31E/1C, or 31E/2C...

  • Page 39: Notices
