Campbell Hausfeld FP2000 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
The Campbell Hausfeld portable
contractor air compressor is intended for
use in construction and workshop
conditions. An oil lubricated, electric
motor driven compressor provides
compressed air to power nailers, staplers,
paint guns and other air tools. The
compressed air produced by the unit will
contain traces of oil and water. In-line
filters may be required for some
applications.
A pressure switch shuts off the
compressor when the tank is filled to 125
PSI. When air is used and the tank
pressure drops to 100 PSI, the compressor
will restart automatically. The regulator
may be set to provide a line pressure
lower than the tank pressure.
The valve on the compressor outlet
fitting vents air for ease in motor startup.
The sound of vented
NOTICE
air is especially
noticeable when the tank pressure is low
and is not a defect.
The pressure switch also has an unloader
valve to vent air when the compressor
stops.

Safety Guidelines

This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Danger indicates
DANGER
!
an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
Warning indicates
WARNING
!
a potentially
hazardous situation which, if not
avoided, could result in death or serious
injury.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2002 Campbell Hausfeld/Scott Fetzer
Oil Lubricated
Portable Air
Compressors
Caution indicates a
CAUTION
!
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
NOTICE
important
information, that if not followed, may
cause damage to equipment.
Unpacking
When unpacking unit, inspect carefully
for any damage that may have occurred
during transit. Make sure to tighten
fittings, bolts, etc., before putting unit
into service.

General Safety

Do not operate
WARNING
!
unit if damaged
during shipping, handling or use.
Damage may result in bursting and cause
injury or property damage.
Air compressors are utilized in a variety
of air system applications. Because air
compressors and other components
(material pump, spray gun, filters,
lubrications, hoses, etc.) used make up a
high pressure pumping system, the
following safety precautions should be
observed at all times. Only persons well
acquainted with these rules of safe
operation should be allowed to use the
air compressor.
1. Read all manuals
included with this
product carefully. Be
thoroughly familiar
with the controls and
the proper use of the
equipment.
2. Keep visitors away and NEVER allow
children in the work area.
3. Before each use, inspect compressed
For parts, product & service information
visit www.chpower.com
!

Breathable Air Warning

This compressor/pump is NOT
equipped and should NOT be used
"as is" to supply breathing quality
air. For any application of air for
human consumption, the air
compressor/pump will need to be
fitted with suitable in-line safety
and alarm equipment. This
additional equipment is necessary
to properly filter and purify the air
to meet minimal specifications for
Grade D breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
IN THE EVENT THE COMPRESSOR IS
USED FOR THE PURPOSE OF
BREATHING AIR APPLICATION AND
PROPER IN-LINE SAFETY AND
ALARM EQUIPMENT IS NOT
SIMULTANEOUSLY USED, EXISTING
WARRANTIES SHALL BE VOIDED,
AND CAMPBELL HAUSFELD
DISCLAIMS ANY LIABILITY
WHATSOEVER FOR ANY LOSS,
PERSONAL INJURY OR DAMAGE.
air system and electrical components
MANUAL for signs of damage, deterioration,
weakness or leakage. Repair or
replace defective items before using.
4. Check all fasteners at frequent
intervals for proper tightness.
5. Do not exceed pressure rating of any
component in system.
FP2000, FP2012
DANGER
IN608400AV 10/02
