Technical Specifications

6.1 General features

Cover and Socket material:
Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage
Order Code RX1___-_4:
Relay output for Heater Break Alarm
(only with HB option)

6.2 Input features

Digital Input:
Volt Analogic input:
Current Analogic input:
Potentiometer:
Logic input SSR (Fast Enable):

6.3 Output features (power device)

Nominal
Current Voltage
range (Ue)
(A) (V) (480V)
120 24÷600
150 24÷600
180 24÷600
210 24÷600

6.4 Fan Specification

Supply: 24Vdc
Repetitive peak
Latching
reverse voltage
current
(Uimp)
(600V) (mAeff)
1200 1600 600
1200 1600 300
1200 1600 300
1200 1600 300
PolymericV2
AC-51 AC-55b
20
Single Phase Load
24Vdc (1A)
0.5A a 125VAC
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 5Hz max
0 ÷ 10Vdc impedance 15 kΩ
4 ÷ 20mA impedance 100 Ω
10 kΩ min.
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
3Hz Max duty cycle min. 100 ms
FUSE I2T
value
Max peak Leakage
Suggested
one cycle current
(at500V)
(10 msec.) (mAeff)
(A) 10msec
1900 15 14280
5000 15 17500
5000 15 30800
5000 15 53900
Power 7W (1 Fan)
16
User's manual
Power loss
Frequency
Thyristor +
range
A2s Fuse
tp= (Hz) I =Inom (W)
47÷70 200
47÷70 205
47÷70 235
47÷70 304
Isolation
Voltage
(Ui)
(Vac)
3000
3000
3000
3000
