- Page 1 GRAIN CART RETROFIT DEMCO SWIVEL HITCH SCALE SYSTEM Instructions 7600413 REVA...
-
Page 2: Table Of Contents
SCALE BRACKET AND LOAD CELL MOUNTING INSTALLATION ..............4 Scale Installation ............................4 JUNCTION BOX MOUNTING .......................... 8 Four Hole Junction Box ..........................8 INDICATOR MOUNTING ..........................9 RAM MOUNT............................. 9 TESTING AND TROUBLE SHOOTING ......................10 Inaccurate weights? ..........................10 Erratic weights?............................10 7600413 REVA Page 2... -
Page 3: Introduction
INTRODUCTION INTRODUCTION Congratulations on the purchase of your new Scale-Tec Grain Cart scale system. This scale system is specifically designed to weigh the hopper on your Grain Cart. This scale kit is specifically designed for your make and model of Grain Cart. These instructions will guide you through general installation of the kit. -
Page 4: Scale Bracket And Load Cell Mounting Installation
IMPORTANT! It may be necessary to utilize a large pipe wrench, penetrating oil, or a slam hammer to remove rusted in axles. As a last resort, heat the sleeves with a torch to remove spindles. Fig. 2 7600413 REVA Page 4... - Page 5 Install the Hub gasket Install the Hub. IMPORTANT –Grease the bearings during installation if needed. 4. Reinstall the wheel and tighten wheel lugs. 5. Repeat steps one through three for installation of the other side. 7600413 REVA Page 5...
- Page 6 Unbolt and remove the pintle receiver from the vertical adjustment hitch. IMPORTANT!! For Digi-Star load cells arrow sticker must be pointed up. For Weigh-Tronix weigh Bars “TOP” sticker must be positioned to the top. Fig. 5 7600413 REVA Page 6...
- Page 7 Install the vertical adjustment hitch onto the load cell. iv. Install the pintle receiver onto the vertical adjustment. Fig. 6 7. Route cabling and mount the Junction Box. See Junction Box mounting section for detailed instructions. 7600413 REVA Page 7...
-
Page 8: Junction Box Mounting
7. Assure that gasket is properly installed in the cover. 8. Attach cover using 4 screws (provided). Installing Wires into Terminal Block 1. Open levers 90º to locked position. 2. Insert individual wires into terminal. 3. Close lever. 4. Tug wire to assure solid connection. 7600413 REVA Page 8... -
Page 9: Indicator Mounting
This particular instruction shows mounting with a “ram” type mount. Your particular kit may only come with a fixed mounting plate. Contact Scale-Tec for other mounting options for your need. 1. Bolt the readout directly to the ram mount utilizing the indicator mounting screws provided. -
Page 10: Testing And Trouble Shooting
3) Zero out the indicator. IF the indicator won’t zero out the problem is the junction box or the junction box cable. IF it will zero out: 4) Reconnect the load cells ONE AT A TIME, zeroing out the indicator each time. When you reconnect the faulty load cell, you will have erratic readings again. 7600413 REVA Page 10...
