- Page 1 GRAIN CART RETROFIT DEMCO TRACKS SCALE SYSTEM Instructions 7600414 REVA...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Anamosa, Iowa USA TABLE OF CONTENTS INTRODUCTION ............................. 3 Charging Battery and Welding ........................3 SCALE BRACKET AND LOAD CELL MOUNTING INSTALLATION ..............4 Scale Installation ............................4 JUNCTION BOX MOUNTING .......................... 7 Four Hole Junction Box ..........................7 INDICATOR MOUNTING .......................... -
Page 3: Introduction
Grain Cart. These instructions will guide you through general installation of the kit. The scale kit can be used to record and monitor seed weight going into or out of the grain cart. This SAFETY ALERT SYMBOL indicates important safety messages in the manual. When you see this symbol, be alert to the possibility of PERSONAL INJURY and carefully read the message that follows. -
Page 4: Scale Bracket And Load Cell Mounting Installation
SAFETY!!! Ensure you properly block the Grain Cart to provide support in the event of a jack failure or lifting device failure. Only install one side at a time. Lifting both sides simultaneously may be too unstable and result in serious injury or death. - Page 5 Scale Installation 3. Repeat steps one through two for installation of the other side. 4. Remove existing hitch and Install hitch load cell. Refer to Fig. 2 i. Unbolt the swivel retaining collar and remove the collar from the swivel shaft. ii.
- Page 6 Scale Installation 5. Install hitch load cell. Refer to Fig. 3 i. Insert the load cell into the sleeve of the grain cart. IMPORTANT!! For Digi-Star load cells arrow sticker must be pointed up. For Weigh-Tronix weigh Bars “TOP” sticker must be positioned to the top.
-
Page 7: Junction Box Mounting
Junction Box Mounting JUNCTION BOX MOUNTING Four Hole Junction Box The junction box is water resistant, not water-proof. It should be mounted to avoid submersion during wetweather and to avoid physical abuse. The junction box can be mounted on the frame of the grain cart. -
Page 8: Indicator Mounting
INDICATOR MOUNTING RAM MOUNT The scale indicator can be mounted in the tractor cab or on the grain cart with various mounting options. This particular instruction shows mounting with a “ram” type mount. Your particular kit may only come with a fixed mounting plate. Contact Scale-Tec for other mounting options for your need. -
Page 9: Testing And Trouble Shooting
Testing and Troubleshooting TESTING AND TROUBLE SHOOTING IMPROTANT All bars need to weigh accurately before it will be beneficial to recalibrate your indicator Inaccurate weights? 1) Measure the same person, or a 200 pound bag of seed, on each of the weigh bars. ...
