Page 2: Suggested Tools
Considering the various dirt or clay surfaces that Nitro Dirt Oval cars are raced on today, the INTIMIDATOR GSX2 has been designed to be competitive on high bite and well groomed clay tracks with rubber or foam racing tires. The instructions will build the kit using the most verastale set-up Custom Works has found in testing on different types of tracks, however there are various other suspension configurations available to you that you may find more suitable for your local track.
Page 3: Front Suspension
Bag A Bag A Bag A Bag A Bag A Front Suspension Front Suspension Front Suspension Front Suspension Front Suspension -Parts for Step#1 1255 Qty 2 3332 Qty 1 3255 Qty 2 3258 Qty 2 4240 Qty 2 5230 Qty 24 Spacer 2.2”...
Page 4: Rear Suspension
STEP #2 STEP #3 - Insert the 7200 Axle into the 3304 3202 Steering Arm so the holes are in-line. -8122 MOUNTS IN 8122 OUTER HOLES ON -Align the Steering Arm into BOTH SIDES. the 3205 Castor Block and 7209 8122 press the 7209 Ball Stud Kingpin thru the assembly...
Page 5 Bag D Bag D Bag D Bag D Bag D Rear Suspension Rear Suspension Rear Suspension Rear Suspension Rear Suspension -Parts for Step#1 3241 Qty 2 1226 Qty 4 4235 Qty 2 1255 Qty 10 5230 Qty 24 Bearing Carrier Ball Bearing Rear Outer Susp Pin Spacer...
Page 6: Diff Assembly
Bag E Bag E Bag E Bag E Bag E Diff Assembly Diff Assembly Diff Assembly Diff Assembly Diff Assembly -Parts for Step#1 4403 Qty 1 4404 Qty 2 4205 Qty 2 4361 Qty 1 4204 Qty 6 4361 Qty 1 1229 Qty 2 Right Outdrive...
Page 7: Spur Gear Assembly
Bag G Bag G Bag G Spur Gear Assembly Spur Gear Assembly Bag G Bag G Spur Gear Assembly Spur Gear Assembly Spur Gear Assembly -Parts for Bag G 4424 Qty 1 4423 Qty 1 2228 Qty 1 4966 Qty 1 5252 Qty 2 2228...
Page 8: Shock Assembly
Shock Bag Shock Bag Shock Assembly Shock Assembly Shock Bag Shock Bag Shock Bag Bag J Bag J Shock Assembly Shock Assembly Shock Assembly Bag J Bag J Bag J -Parts for Step#1 1250 Qty 8 1435 Qty 6 1426 Qty 2 1425 Qty 4...
Page 9 Bag J Bag J Bag J Bag J Bag J Bag K Bag K Bag K Fuel Tank / Motor Mounts Fuel Tank / Motor Mounts Bag K Bag K Fuel Tank / Motor Mounts Fuel Tank / Motor Mounts Fuel Tank / Motor Mounts -Parts for Step#1...
Page 10 STEP #3 5246 5246 Collar Ball Cup 5228 5246 SHORT Rod Throttle Rod Assembly: Tubing - Thread the 5228 Throttle Rod into 5246 Ball Cup. 5246 Swivel 5228 - Slide the parts shown on the Throttle Rod, LONG Rod 5246 secure the collars using 5282 set screws.
Page 11: Clutch Assembly
Clutch Bag Clutch Bag Clutch Bag Clutch Bag Clutch Bag Clutch Assembly Clutch Assembly Clutch Assembly Clutch Assembly Clutch Assembly -Parts for Clutch 4438 Qty 1 4439 Qty 1 5208 Qty 1 4430 Qty 1 4437 Qty 1 4435 Qty 2 4431 Qty 2 4440...
Page 12 Tire Bag Tire Bag Tire Bag Tire Bag Tire Bag Tire & Wheel Installation Tire & Wheel Installation Tire & Wheel Installation Tire & Wheel Installation Tire & Wheel Installation -Parts for 5207 Qty 4 7047 Qty 6 8-32 Lock Nut Spacer Tire Bag 1226...
Page 13: Maintenance
You have now completed the assembly process of your new Custom Works Intimidator GSX2. In the next section of this manual you will find some basic setup hints and advice. It is important to remember that all tracks and racing surfaces are different.
Page 14 SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: When looking for the “perfect set-up” it is important to remember 2 things... 1) Keeping things simple is best. 2) As you are making your set-up change, the track is changing too! Ask a local racer what the track usually does from begining to end, especially day to night.
Page 15 Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Difference in the amount of Rear Toe-In among the rear tires. Typically used only on high bite tracks with MORE toe-in on the Left Rear tire than the Right so the rear of the car helps turn the car LEFT under acceleration.
