- Page 1 SMART SPOT100 WHITE 3000°K / 5600°K ULSSF100CW / ULSSPC100CW / ULSSF100WW / ULSSPC100WW Version 1.0 USER MANUAL Be sure to read the USER MANUAL carefully before using this product. Be sure to keep the USER MANUAL properly for future needs. Use this product correctly when you can fully understand the User Manual...
-
Page 2: Safety Instructions
SPOT WHITE 1.Safety instructions Thank you for choosing our SMART SPOT 100 White . for your own safety, please read this user manual carefully BEFORE YOU INITIAL START - UP! CAUTION! Be careful with your operations. With a high voltage you can suffera dangerous electric shock when touching the wires! This device has left our premises in absolutely perfect condition. -
Page 3: Power Connector
SPOT WHITE 2.UNPACKING The SPOT adopts 100W LED lamp which features high brightness and stability. Please carefully unpack it when you receive the fixture and check whether it is damaged during the transportation. And please check whether the following items are included inside the box: ▲... -
Page 4: Technical Information
SPOT WHITE 3.TECHNICAL INFORMATION... - Page 5 SPOT WHITE 4.PHOTOMETRICS DIAGRAM FRESNEL mt 12.5 mt 12.5 mt 10 mt 10 mt 7.5 mt 7.5 mt 5 mt 5 mt 2.5 mt 2.5 Lux center Lux center 11463 2865 1273 Lux center Lux center 10517 2619 1168 Beam angle 8° Beam angle 8°...
-
Page 6: Installations
SPOT WHITE 6.INSTALLATIONS Cautions: For added protection mount the fixtures in areas outside walking paths, seating areas, or in areas were the fixture might be reached by unauthorized personnel. Before mounting the fixture to any surface, make sure that the installation area can hold a minimum point load of 10 times the device’s weight. -
Page 7: Control Connection
SPOT WHITE 9.CONTROL CONNECTION MADE IN ITALY Connect the provided XLR cable to the female 5-pin XLR output of your controller and the other side to the male 5-pin XLR input of the moving head. You can chain multiple projectors together through serial linking. -
Page 8: Menu Operations
SPOT WHITE 10.MENU OPERA TIONS MADE IN ITALY Description MENU DMX address setting Dmx Address Dmx Address A001~AXXX Xeno it can simulate dimmer effect with Tungsten or Xenon lamp Tungsten White Tmp 0-255 Dimmer 0-255 Effect 0-255 Store 0-255 1 chn 1 Channel MODE 5 chn 5 Channel MODE... - Page 9 SPOT WHITE type of 1c hannel 5c hannel func tion effec t dec imal perc entage c ontrol master dimmer adjust luminous output intensity from 0 to 100% proportional 100% spare c hannel no effect step 100% no effect step dimmer fine fine dimmer control 16 bit.
-
Page 10: Maintenance And Cleaning
SPOT WHITE 10.Maintenance and cleaning It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build up on or within the fixture. Otherwise, the fixture‘s light-output will be significantly reduced. Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably throughout its life.A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances should alcohol or solvents be used! - Page 11 SPOT WHITE Information on disposal of the equipment The equipment at the end of its useful life must be disposed of at an appropriate recycling center for waste electrical and electronic equipment. The treatment and disposal of environmentally friendly, helps prevent potential negative environmental and health and promote the reuse and / or recycling of materials making up the equipment.
- Page 12 ULTRALITE DEUTSCHLAND Haerle Lichttechnik GmbH • Marie-Curie-Str. 4 • 89584 Ehingen Germany • +49 7391 7747 0 • www ultralite.eu • info@ultralite.eu...
