Summary of Contents for UltraLite PROFILE 200 DYNAMIC WHITE Series
- Page 1 PROFILE 200 DYNAMIC WHITE ULP200DW1528 / ULP200DW2240 Version 1.0 USER MANUAL Be sure to read the USER MANUAL carefully before using this product. Be sure to keep the USER MANUAL properly for future needs. Use this product correctly when you can fully understand the User Manual...
-
Page 2: Safety Instructions
PROFILE DYNAMIC WHITE 1.Safety instructions Thank you for choosing our PROFILE 200 Dynamic White . for your own safety, please read this user manual carefully BEFORE YOU INITIAL START - UP! CAUTION! Be careful with your operations. With a high voltage you can suffera dangerous electric shock when touching the wires! This device has left our premises in absolutely perfect condition. -
Page 3: Power Connector
PROFILE DYNAMIC WHITE 2.UNPACKING The PROFILE adopts 200W LED lamp which features high brightness and stability. Please carefully unpack it when you receive the fixture and check whether it is damaged during the transportation. And please check whether the following items are included inside the box: ▲... -
Page 4: Technical Information
PROFILE DYNAMIC WHITE 3.TECHNICAL INFORMATION... - Page 5 PROFILE DYNAMIC WHITE 4.PHOTOMETRICS DIAGRAM PROFILE 15°-28° PROFILE 22°-40° mt 8 mt 8 mt 4 mt 4 mt 3 mt 3 mt 2 mt 2 mt 1 mt 1 Lux center Lux center 18580 4645 2065 1162 34000 8500 3778 2125 Beam angle 22°...
-
Page 6: Installations
PROFILE DYNAMIC WHITE 6.INSTALLATIONS Cautions: For added protection mount the fixtures in areas outside walking paths, seating areas, or in areas were the fixture might be reached by unauthorized personnel. Before mounting the fixture to any surface, make sure that the installation area can hold a minimum point load of 10 times the device’s weight. -
Page 7: Control Connection
PROFILE DYNAMIC WHITE 7.CONTROL CONNECTION LCD DISPLAY ARTHEA LUCE LED LINE POWER 90/260Vac 50/60Hz MENU ENTER DMX 512 POWER Connect the provided XLR cable to the female 5-pin XLR output of your controller and the other side to the male 5-pin XLR input of the moving head. You can chain multiple projectors together through serial linking. -
Page 8: Menu Operations
PROFILE DYNAMIC WHITE 8.MENU OPERATIONS LCD DISPLAY ARTHEA LUCE LED LINE POWER N°SERIAL DATE MENU ENTER Description MENU DMX address setting Dmx Address Dmx Address A001~AXXX Xeno it can simulate dimmer effect with Dimmer Tungsten or Xenon lamp Tungsten White Tmp 2800K to 5800K 0-255 Dimmer 0-255... - Page 9 PROFILE DYNAMIC WHITE ty p e o f c ha nne l func ti o n e ffe c t d e c im a l p e rc e nta g e c o ntro l m a s te r d i m m e r proportional adjust luminous output intensity from 0 to 100% - 100%...
-
Page 10: Maintenance And Cleaning
PROFILE DYNAMIC WHITE 10.Maintenance and cleaning It is absolutely essential that the fixture is kept clean and that dust, dirt and smoke-fluid residues must not build up on or within the fixture. Otherwise, the fixture‘s light-output will be significantly reduced. Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably throughout its life.A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances should alcohol or solvents be used! - Page 11 PROFILE DYNAMIC WHITE Information on disposal of the equipment The equipment at the end of its useful life must be disposed of at an appropriate recycling center for waste electrical and electronic equipment. The treatment and disposal of environmentally friendly, helps prevent potential negative environmental and health and promote the reuse and / or recycling of materials making up the equipment.
- Page 12 ULTRALITE DEUTSCHLAND Haerle Lichttechnik GmbH • Marie-Curie-Str. 4 • 89584 Ehingen Germany • +49 7391 7747 0 • www ultralite.eu • info@ultralite.eu...
