WARNING
A child or adult can tip the safe and be
killed or seriously injured.
Failure to secure the safe as shown in
these instructions can result in death or
serious injury to children and adults.
Children should not play with or around
the safe at any time.
Serial #
Combination #
IMPORTANT
• Record the serial number from the tag on the
back of the safe or from the tag on the front
bottom corner of the safe.
• Keep keys and combination in a secure place
away from children.
• Do not store the back up key, your combination
or this document in the safe.
• Warning: Keep your safe closed and locked at
all times when not in use. Children could
accidentally be locked inside the safe.
• Do not move this safe using its handle. The
handle should only be used for opening and
closing the door of the safe.
• Do not store electronic media, computer disks,
audio-visual media or photographic negatives in
this safe. This material will not survive the rated
internal temperature of the safe. This material
may be damaged or destroyed.
Instructions
BC-18-MB-E-S
BC-24-MB-E-S
BC-40-MB-E-S
Tip Over Hazard
Hardware Included:
(2) M10x70 Lag screws
(2) washers
(2) plastic anchors
BATTERY INSTALLATION
You must first install the battery which is located in the
front protective styrofoam
NOTE: When changing the battery, always hold the
battery connecting cap while disconnecting or attaching
the battery. Do not pull on the wires. Doing this could
cause the power supply to become disconnected from
the lock.
This safe uses one 9V alkaline battery. Under normal
use the batteries will last about 1 year.
When the battery is low and you press a button on the
keypad, a red light will come on warning you that the
battery is low.
To test the batteries, enter your security code. If the
batteries are low the red light will come on momentarily.
To replace the battery, remove the cover by pressing the
tab and turning the cover as shown in the illustration.
Replace the old battery and screw the cover back in
place.
Tools required:
drill
7/16" drill bit
3/8" drill bit
17mm socket wrench
Phillips screwdriver.
TAB
1
40427-1311
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Buck Commander BC-18-MB-E-S and is the answer not in the manual?

Questions and answers

Summary of Contents for Stack-On Buck Commander BC-18-MB-E-S

  • Page 1 Hardware Included: Tools required: Instructions (2) M10x70 Lag screws drill (2) washers 7/16” drill bit BC-18-MB-E-S (2) plastic anchors 3/8” drill bit BC-24-MB-E-S BC-40-MB-E-S 17mm socket wrench Phillips screwdriver. WARNING Tip Over Hazard A child or adult can tip the safe and be killed or seriously injured.
  • Page 2: Electronic Lock

    Customer Service. If you write down your combination you must keep this information in a secure place, away from children, not inside the safe.
  • Page 3: Locking The Safe

    LOCKING THE SAFE SECURING THE SAFE NOTE: The safe must be secured to the floor. To lock the safe, close the door and rotate the Use the hardware provided or consult your handle counter clockwise until it stops. If the hardware retailer for fastening hardware for your handle is not turned until it stops, the locking particular mounting surface.
  • Page 4 BACK UP KEY GUN REST INSTALLATION A "Back Up Key" has been provided in case you have The gun rest and full length shelf are supported on forgotten or lost your security code. To open the the outside wall brackets with 4 removable shelf clips. safe using the back up key follow the steps below: You will need to permanently secure the gun rests to 1.
  • Page 5 Keep this record of your serial number and combination in a secure place separate from your safe. To order a replacement key set, follow the instructions on the attached form. STACK-ON PRODUCTS CO. P.O. BOX 489, WAUCONDA, IL 60084 40427-1311...
  • Page 6 Verification of ownership is required in order to receive replacement key for your security product. In order to receive a replacement key: Complete the following form and send to Stack-On Products. Send a copy of your valid driver’s license along with the form.
  • Page 7 Valid Only for Purchases in North America) If your Stack-On Fire Resistant Steel Safe suffers damage due to theft or fire at any time while still owned by the original owner, Stack-On will either repair or replace (at Stack-On’s discretion) your safe free of charge. If Stack-On chooses to repair the safe, such repair work may be performed by a local technician approved by Stack-On.
  • Page 8: Installation Des Piles

    Matériel inclus: Outils nécessaires: (2) Les tire-fonds M10x70 forer Instructions (2) rondelles 7/16 "foret BC-18-MB-E-S (2) chevilles en plastique 3/8 "foret BC-24-MB-E-S Clé à douille de 17mm BC-40-MB-E-S Tournevis Phillips. Risque de basculement Un enfant ou un adulte peut faire basculer le coffre, ce qui peut causer la mort ou une blessure grave.
  • Page 9 à www.stack-on.com sous Customer Service. Si vous écrivez votre combinaison, vous devez conserver ces informations dans un endroit sûr, loin des enfants, pas l'intérieur du coffre.
  • Page 10 BLOCAGE DE LA COFFRE FORTE MONTAGE DE LA COFFRE FORTE NOTE: Le coffre-fort doit être fixé au sol. Pour verrouiller le coffre-fort, fermer la porte et Utilisez le matériel fourni ou consulter votre tourner le compteur de la poignée dans le sens revendeur de matériel pour la fixation matérielle horaire jusqu'à...
  • Page 11 CLÉ DE DÉPANNAGE INSTALLATION DES APPUIS À CANON Une « clé de dépannage » vous est fournie au cas où Le reste des armes à feu et le plateau de pleine longueur vous auriez oublié ou perdu votre code de sécurité. Pour sont pris en charge sur les supports muraux extérieurs ouvrir le coffre-fort à...
  • Page 12 Pour commander un jeu de clés de remplacement, suivez les instructions sur le formulaire ci-joint. STACK-ON PRODUCTS CO. P.O. BOX 489, WAUCONDA, IL 60084 40427-1311...
  • Page 13 Il faut procéder à une vérification du contrôle de possession avant de vous envoyer une clé de remplacement . Pour recevoir une clé de remplacement: Remplissez le formulaire qui suit et faites-le parvenir à Stack-On Products. Envoyez une copie de votre permis de conduire valide avec le formulaire. Envoyez une copie du reçu indiquant l'achat original.
  • Page 14 (Valide seulement sur les achats en Amérique du Nord) Si votre coffre d’acier résistant au feu Stack-On est endommagé par le feu ou lors d’un vol et que vous en êtes le premier propriétaire, Stack-On réparera ou remplacera le coffre gratuitement (à sa discrétion). Si Stack-On décide de réparer le coffre, la réparation pourra être effectuée par un technicien de votre localité...
  • Page 15: Instalación De Las Pilas

    Incluye piezas de montaje: Herramientas necesarias: (2) Los tornillos M10x70 perforar Instrucciones (2) arandelas 7/16 "broca BC-18-MB-E-S (2) anclajes de plástico 3/8 "broca BC-24-MB-E-S Llave de tubo de 17 mm BC-40-MB-E-S Destornillador Phillips. Puede Volcarse Un menor o un adulto pueden volcar la caja fuerte y pueden morir o ser dañados seriamente.
  • Page 16: Cerradura Electrónica

    Si el código funciona registrar exitosamente su número de combinación en el frente de este formulario o almacenar su combinación de nuestro sitio web seguro en www.stack-on.com en Customer Service. Si usted escribe su combinación debe mantener esta información en un lugar seguro, lejos de los niños, no dentro de la caja de seguridad, debe...
  • Page 17: Selección De La Ubicación

    BLOQUEO DE LA CAJA FUERTE PARA FIJAR LA CAJA FUERTE NOTA: La caja fuerte debe ser asegurado al suelo. Para bloquear la caja fuerte, cerrar la puerta y girar Utilice los accesorios suministrados o consulte el mango contra reloj hasta que se detenga. Si el con su proveedor de hardware para la fijación de mango no se enciende hasta que se detenga, el hardware para su superficie de montaje particular.
  • Page 18 LLAVE DE SOBREMANDO PISTOLA DE INSTALACIÓN TITULAR Una “Llave de Sobremando” ha sido provista en caso El resto pistola y la plataforma de larga duración son de olvidar su código de seguridad. Para abrir la caja compatibles con los soportes de pared exterior con 4 clips para baldas extraíbles.
  • Page 19 Guarde este documento con su número de serie y la combinación en un lugar separado de su caja fuerte. Para solicitar un duplicado de llaves, siga las instrucciones en el formulario adjunto. STACK-ON PRODUCTS CO. P.O. BOX 489, WAUCONDA, IL 60084 40427-1311...
  • Page 20 Para poder recibir su llave de reemplazo de su gabinete de seguridad: Llene y envíe esta solicitud a Stack-On Products. Envíe copia de su licencia de conducir junto con la solicitud. Envíe copia del recibo mostrando la fecha original de compra.
  • Page 21 Stack-On decide reparar la caja fuerte, dicha reparación puede ser hecha por un técnico local aprobado por Stack-On. Dependiendo de la magnitud del daño, Stack-On puede requerir que la caja fuerte se devuelva a la fábrica para reparación. Si la caja fuerte así se devuelve, Stack-On pagará...
