Table Of Contents - Fostex VC-8 Service Manual

1. SPECIFICATIONS ............................................................................................. 4
2. CONTROLS, INDICATORS AND CONNECTORS ..................................... 5
3. EXPLODED VIEW ........................................................................................... 6
4. PARTS LIST ...................................................................................................... 8
5. PCB PATTERN DRAWING .......................................................................... 10
6. CIRCUIT DIAGRAMS ................................................................................... 12
NOTES
* Parts List and circuit diagrams are given in this manual to assist the service technician in
maintaining the Model VC-8.
* The following accessories are supplied with VC-8 as the standard accessories.
Owner's manual, VC-8, MLT
AC adaptor AD-12A
* Following is the packing material for the Model VC-8.
PACK, SIDE, L, DE-1
PACK, SIDE, R, DE-1
CARTON, INNER, VC-8
CARTON, OUTER, VC-8
CAUTION
Parts marked with this sign are safety critical components. They must always be replaced
with identical components. Refer to the Fostex Parts List and ensure exact replacement.

TABLE OF CONTENTS

: 8288444000
: 8270727003 (for USA/CND)
: 8270727006 (for EUR)
: 8270727007 (for UK)
: 8270727010 (for JPN)
: 8228454000
: 8228455000
: 8228727000
: 8228906000
VC-8
3
