Campbell Hausfeld HX5100 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
This oil-lubricated compressor is
designed for do-it-yourselfers with a
variety of home and automotive jobs.
These compressors can power spray
guns, impact wrenches and other tools.
Compressed air from this unit will
contain moisture. Install a water filter
or air dryer if application requires dry
air.

Safety Guidelines

This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Danger indicates an
imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates a
potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service. In case of
questions, damaged or missing parts,
© 2010 Campbell Hausfeld/Scott Fetzer
STOP!
Record the Model No., Serial No. and date
of purchase located on the base below the
pump in the space below.
Model No.
Serial No.
Date of purchase
Retain these numbers for future reference.
please call 1-800-543-6400 for customer
assistance. Have the serial number,
model number, and parts list (with
missing parts circled) before calling.
General Safety Information
CalIfornIa propoSItIon 65
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
dust when you cut, sand, drill
or grind materials such as
wood, paint, metal, concrete,
cement, or other masonry. This dust
often contains chemicals known to
cause cancer, birth defects, or other
reproductive harm. Wear protective
gear.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
oil-lubricated
Compressors
Do not rEtUrn tHE
proDUCt to tHE
rEtaIlEr!
______________________
______________________
______________________
This product or
its power cord may
You can
create
HX5100, HX5101
Breathable Air Warning
this compressor/pump is not
equipped and should not be
used "as is" to supply breathing
quality air. for any application of
air for human consumption, the
air compressor/pump will need
to be fitted with suitable in-line
safety and alarm equipment.
this additional equipment is
necessary to properly filter
and purify the air to meet
minimal specifications for Grade
D breathing as described in
Compressed Gas association
Commodity Specification G
7.1 - 1966, oSHa 29 Cfr 1910.
134, and/or Canadian Standards
associations (CSa).
DISClaIMEr of WarrantIES
In the event the compressor
is used for the purpose of
breathing air application
and proper in-line safety
and alarm equipment is not
simultaneously used, existing
warranties shall be voided, and
the manufacturer disclaims any
liability whatsoever for any loss,
personal injury or damage.
GEnEral InforMatIon
Do not operate unit
if damaged during
shipping, handling or use. Damage may
result in bursting and cause injury or
property damage.
Do not run
unattended.
Leaving compressor in AUTO position
may allow it to turn on inadvertently.
To prevent this and possible damage
from power surge, turn to OFF position
after each use.
IN634800AV 8/10
