Campbell Hausfeld HL540200 Operating Instructions And Parts Manual

See Warranty on page 12 for important information about commercial use of this product.
Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
This oil-lubricated compressor is
designed for do-it-yourselfers with a
variety of home and automotive jobs.
These compressors power spray guns,
impact wrenches and other tools.
Compressed air from this unit will
contain moisture. Install a water filter
or air dryer if application requires dry
air.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service. In case of
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance. Have the serial number,
model number, and parts list (with
missing parts circled) before calling.
DO nOt retUrn
tHe PrODUCt tO
STOP!
tHe retaILer!
Do not operate unit
if damaged during
shipping, handling or use. Damage may
result in bursting and cause injury or
property damage.
reaD & FOLLOW aLL InStrUCtIOnS
Save tHeSe InStrUCtIOnS
DO nOt DISCarD
© 2010 Campbell Hausfeld/Scott Fetzer
Record the Model No., Serial No. and
date of purchase located on the base
below the pump in the space below.
Model No.
Serial No.
Date of purchase
Retain these numbers for
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or
serious injury.
hazardous situation which, if not
avoided, COULD result in death
or serious injury.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information,
visit www.chpower.com
HL540200
____________________
_________________
future reference.
Danger indicates
an imminently
Warning indicates
a potentially
Oil-Lubricated
Compressors

Breathable Air Warning

this compressor / pump is not
equipped and should not be
used "as is" to supply breathing
quality air. For any application of
air for human consumption, the
air compressor / pump will need
to be fitted with suitable in-line
safety and alarm equipment.
this additional equipment is
necessary to properly filter
and purify the air to meet
minimal specifications for Grade
D breathing as described in
Compressed Gas association
Commodity Specification
G 7.1 - 1966, OSHa 29 CFr 1910.
134, and / or Canadian Standards
associations (CSa).
DISCLaIMer OF WarrantIeS
In the event the compressor is
used for the purpose of breathing
air application and proper in-line
safety and alarm equipment is
not simultaneously used, existing
warranties shall be voided, and
the manufacturer disclaims any
liability whatsoever for any loss,
personal injury or damage.
Caution indicates
a potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
important
information, that if not followed,
may cause damage to equipment.
nOte: Information that requires special
attention.
HL540200
