Magic-Pak All-In-One EWC V Series Installation Instructions Manual page 7

Indoor Blower
Model
TAP 1 (HEAT) *
TAP 2 (HEAT)
EWC0512P12B TAP 3 (HEAT)
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT)
TAP 2 (HEAT) *
EWC0712P12B TAP 3 (HEAT)
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT)
TAP 2 (HEAT) *
EWC0512P18B
TAP 3 (HEAT)
EWC0712P18B
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT)
TAP 2 (HEAT)
EWC1012P18B TAP 3 (HEAT) *
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT)
TAP 2 (HEAT)
EWC1012P24B TAP 3 (HEAT) *
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT)
TAP 2 (HEAT)
EWC1512P24B TAP 3 (HEAT) *
TAP 4 (COOL) †
TAP 5 (COOL)
TAP 1 (HEAT) *
TAP 2 (HEAT)
EWC1012P30B TAP 3 (COOL) †
TAP 4 (COOL)
TAP 5 (COOL) †
TAP 1 (HEAT)
TAP 2 (HEAT) *
EWC1512P30B TAP 3 (COOL) †
TAP 4 (COOL)
TAP 5 (COOL) †
NOTE: EWC**30B models shipped with Low and High stage Cooling taps connected for use of the two-stage system.
* As shipped speed for Heating operation
† As shipped speed for Cooling operation
Table 2. Supply Airflow Performance (SCFM) as a Function of External Static Pressure
507390-02
Unit Voltage
Speed (V)
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
208 or 230
0.1 0.2
" w.c. " w.c.
615 590
655 630
795 780
480 460
530 505
615 590
655 630
795 780
480 460
530 505
805 785
825 805
910 890
560 540
610 580
805 785
825 805
910 890
560 540
610 580
805 785
825 805
910 890
770 750
820 790
805 785
825 805
910 890
770 750
820 790
825 805
910 890
530 510
570 545
950 920
825 805
910 890
530 510
570 545
950 920
Issue 2127
0.3 0.4
" w.c. " w.c.
570 545
610 590
760 745
440 415
485 460
570 545
610 590
760 745
440 415
485 460
770 750
785 770
875 860
520 500
560 535
770 750
785 770
875 860
520 500
560 535
770 750
785 770
875 860
730 710
770 750
770 750
785 770
875 860
730 710
770 750
785 770
875 860
490 465
530 505
900 885
785 770
875 860
490 465
530 505
900 885
0.5
" w.c.
525
570
725
390
430
525
570
725
390
430
730
750
845
475
505
730
750
845
475
505
730
750
845
690
730
730
750
845
690
730
750
845
440
480
865
750
845
440
480
865
Page 7 of 12
