January 2018
Second Printing
Supplement
Focus ST
Litho in USA
JM5J 19A285 HA
owner.ford.com (U.S.)
ford.ca (Canada)
This Supplement is not intended to
replace your vehicle Owner's Manual
which contains more detailed
information concerning the features
of your vehicle, as well as important
safety warnings designed to help
reduce the risk of injury to you and
your passengers. Please read your
entire Owner's Manual carefully as
you begin learning about your new
vehicle and refer to the appropriate
sections when questions arise.
All information contained in this
supplement was accurate at the
time of duplication. We reserve the
right to change features, operation
and/or functionality of any vehicle
specification at any time. Your Ford
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner's Manual.
2 0 1 8 F O R D F O C U S S T
S U P P L E M E N T
Advertisement
Table of Contents
Related Manuals for Ford Focus ST 2018
Summary of Contents for Ford Focus ST 2018
- Page 1 We reserve the right to change features, operation and/or functionality of any vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
- Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2017 All rights reserved. Part Number: JM5J 19A285 HA 201706 20171115115345...
-
Page 4: Table Of Contents
Table of Contents Introduction Capacities and Specific- ations About This Supplement.........3 Engine Specifications........27 SVT.................4 Motorcraft Parts..........28 Team RS...............4 Capacities and Specifications....29 Ford Performance..........4 Warranty Terms and At a Glance Conditions At a Glance............6 Base Warranty..........32 Instrument Cluster Gauges..............10 Information Displays Information Messages........12 Transmission Manual Transmission........13... - Page 5 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing...
-
Page 6: Introduction
Although performance significant interior and exterior is at the heart of every Ford Performance enhancements. developed vehicle, we go much further. Our goal is to deliver a comprehensive,... -
Page 7: Svt
SVT Focus in North America. In 2003, The Special Vehicle Team (SVT) was Team RS replaced SVE in Europe when we established in 1991 to polish the Ford Oval brought performance car and motorsport by creating low-volume, factory-produced personnel together as one team. - Page 8 Introduction experiences for enthusiasts. This includes across Ford’s product portfolio. accelerating the development of advanced We are proud and passionate about what aerodynamics, lightweighting, electronics, we do and we look forward to a long and powertrain performance, fuel efficiency exciting relationship with you. Thank you...
-
Page 9: At A Glance
• ST-tuned 2.5 in (63.5 mm) center exit • ST-tuned electric power assisted exhaust system. steering. • Getrag-Ford MMT6 6-speed manual • AdvanceTrac® stability enhancement transaxle. system with three modes: Normal, • Active sound symposer. Sport and Disabled. - Page 10 At a Glance • P235/40-18 Pirelli P-Zero Nero • Leather wrapped ST sport steering performance all-season tires wheel with improved grip contour. (optional). • ST-unique instrument panel appliques, • ST-engineered front and rear fascias shift knob, shift boot and pedal pads. and rear wing.
- Page 11 At a Glance Item Description 1.952 4.063 1.321 4.063 1.321 4.063 1.129 2.955 0.943 2.955 Reverse 4.600 2.955 Engine Specifications Item Description Configuration Transversely mounted I4, cast aluminum cylinder block and cylinder heads Bore x stroke 3.4 in (87.5 mm) bore x 3.2717 in (83.1 mm) stroke Displacement 122 in³...
- Page 12 At a Glance Item Description Turbo Single scroll / 21 psi max boost* Exhaust system 2.5 in (63.5 mm) diameter * SAE Certified Performance ratings are achieved with 19.5 psi, but up to 21 psi can be delivered to maximize power depending on fuel quality and atmospheric conditions. Suspension Specifications Item Description...
-
Page 13: Instrument Cluster
Instrument Cluster GAUGES E194323 Tachometer. Fuel gauge. Coolant temperature gauge. Speedometer. 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing... - Page 14 Instrument Cluster If the engine oil pressure drops below the normal range, the oil pressure gauge pointer drops into the red section of the gauge scale and the engine oil pressure warning lamp in the main instrument cluster illuminates. Stop the vehicle as soon as safely possible and switch off the engine immediately.
-
Page 15: Information Displays
Information Displays INFORMATION MESSAGES Electronic Stability Control Message Action and Description Electronic Stability Displays when you switch the system off. Control Off 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing... -
Page 16: Transmission
Transmission 2. Press the clutch pedal to the floor, then MANUAL TRANSMISSION put the transmission in neutral (N). 3. Start the engine, then press the brake pedal and release the parking brake. 4. Move the transmission to position 1 , then slowly release the clutch pedal while slowly pressing on the accelerator. - Page 17 Transmission Before operating your vehicle at high speeds: • Verify correct tire pressures. See Tires (page 22). • Inspect wheels and tires for wear and damage. Replace any wheels or tires that have damage. • Do not operate your vehicle at high speeds with more than two passengers or while carrying cargo.
-
Page 18: Stability Control
Stability Control USING STABILITY CONTROL The AdvanceTrac® system includes traction control and electronic stability control. See the Traction Control and Stability Control chapters of the Owner's Manual for more information. Never switch off stability control or select sport mode when an emergency wheel or compact wheel is fitted as spare wheel. - Page 19 Stability Control AdvanceTrac Modes Mode Description Button operation Display Normal Daily usage with all None None driver aids engaged. Spirited driving. Single press • Message center Sport Thresholds altered displays: Sport on traction control Mode. and electronic • Amber light in stability control to cluster illumin- allow more tire spin...
-
Page 20: Driving Hints
Driving Hints The system allows a maximum of 20 ENGINE OVERSPEED seconds of engine overboost. After this the system reduces turbo charger boost WARNING and maximizes it at a predetermined limit. Do not operate the engine at high Once the turbo charger boost drops below engine speeds while the vehicle is the predetermined limit the system resets stationary. -
Page 21: Roadside Emergencies
• Towing — independent service ROADSIDE ASSISTANCE contractors, if not prohibited by state, local or municipal law, shall tow Ford Vehicles Sold in the United States: eligible vehicles to an authorized dealer Getting Roadside Assistance within 35 mi (56 km) of the... - Page 22 Roadside Emergencies Vehicles Sold in Canada: Getting Roadside Assistance To fully assist you should you have a vehicle concern, Ford Motor Company of Canada, Limited offers a complimentary roadside assistance program. This program is eligible within Canada or the continental United States.
-
Page 23: Maintenance
Maintenance UNDER HOOD OVERVIEW E180866 Engine coolant reservoir. Engine oil dipstick. Engine oil filler cap. Brake fluid and clutch fluid reservoir. Battery. Engine compartment fuse box. Engine air cleaner. Washer fluid reservoir. 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing... -
Page 24: Engine Oil Dipstick
Maintenance ENGINE OIL DIPSTICK E169062 Minimum. Maximum. DRIVE BELT ROUTING Drivebelt Routing 2.0L EcoBoost E180867 A. Long drivebelt is on the first pulley groove closest to the engine. B. Short drivebelt is on the second pulley groove farthest from the engine. 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing... -
Page 25: Wheels And Tires
Wheels and Tires • When installing wheels, always torque WHEELS lug nuts to specification with a torque wrench. Your ST vehicle is equipped with unique wheels matched to the tires. These wheels • Inspect your wheels for damage on a are more susceptible to damage due to regular basis. -
Page 26: Using Winter Tires
• For tire pressures, see the placard winter use on ice or snow and you cannot located on the B-pillar inside the use them with snow chains. Ford does not driver's door. recommend using the original equipment • Always maintain your tire pressures... - Page 27 Required wheel. 235/40-18 Original equipment ST wheel or equivalent. 235/45-17 Owner supplied. See your Ford dealer for suitable wheels from the Focus lineup. 215/50-17 * Required size to prevent vehicle damage if snow chain use is required. Please call the Ford Performance Info Center at 1-800-FORD-SVT (367-3788) for specific winter tire recommendations.
-
Page 28: Technical Specifications
Wheels and Tires TECHNICAL SPECIFICATIONS WHEELS Wheel Specification Diameter and width 18 inches x 8.0 inches Offset 2.2 in (55 mm) Backspacing 6.7 in (16.949 cm) Center bore 2.5 in (63.5 mm) Weight 25 lb (11 kg) Your ST vehicle is equipped with unique wheels matched to the tires. These wheels are more susceptible to damage due to their diameter, width and low profile tires. - Page 29 Wheels and Tires Spare tire Continental ContiProContact Usage All Season Wheel 17 in. x 7.5 in, 52.5mm offset steel wheel See the Wheels and Tires chapter of your owner's manual for instructions on changing a road wheel. Your ST vehicle is equipped with a full-size, dissimilar spare tire assembly. Although the spare is a traditional, full size tire (as opposed to a mini-spare), it is different in both size and handling characteristics from the standard Focus ST performance tire.
-
Page 30: Engine Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 2.0L EcoBoost engine Cubic inches Required fuel Minimum 87 octane Firing order 1 3 4 2 Ignition system Coil on plug Compression ratio 9.3:1 Spark plug gap 0.027-0.031 in (0.70-0.80 mm) 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing... -
Page 31: Motorcraft Parts
WW-2803 (passenger side) WW-1295 (rear) We recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability. -
Page 32: Capacities And Specifications
Adding Engine Oil We recommend that you use Motorcraft Quantity oil and fluids for your vehicle. Only use fluid that meets Ford specifications. 0.8 qt (0.8 L) Using other fluids could result in damage The quantity of engine oil required to raise not covered by the vehicle Warranty. - Page 33 Capacities and Specifications Name Specification Motorcraft® SAE 5W-30 Synthetic Motor Oil / Huile moteur synthétique SAE 5W-30 Motorcraft® (Canada) XO-5W30-QFS (U.S.) CXO-5W30-LFS6 (Canada) Motorcraft® Orange Prediluted Antifreeze/Coolant (U.S.) WSS-M97B44-D2 Motorcraft® Orange Prediluted Antifreeze/Coolant / Antigel/liquide de refroidissement prédilué orange Motorcraft® (Canada) VC-3DIL-B (U.S.) CVC-3DIL-B (Canada) Motorcraft®...
- Page 34 Capacities and Specifications Motor oils of the recommended viscosity Using oil and fluids that do not meet the grade that display the API Certification defined specification and viscosity grade Mark for gasoline engines are also may lead to: acceptable. Do not use oil labeled with •...
-
Page 35: Warranty Terms And Conditions
Ford Focus models. This information is covered in its entirety in the warranty information. You can obtain warranty service for your ST vehicle or any ST vehicle at any Ford dealer nationwide. Ford Global Performance does not recommend modifying or racing ST, SVT... - Page 36 Vehicles Sold in the United States: Getting Engine Overspeed...........17 Roadside Assistance........18 Engine Specifications........27 Vehicles Sold in the United States: Using Roadside Assistance........18 Roadside Emergencies.........18 Ford Performance..........4 Stability Control..........15 SVT.................4 Gauges..............10 Oil Pressure Gauge..........11 Oil Temperature Gauge........11 Team RS...............4 Turbocharger Boost Gauge........11...
- Page 37 Index Tires See: Wheels and Tires........22 Transmission.............13 Under Hood Overview........20 Using Stability Control........15 Enhanced Torque Vectoring Control....16 Using Winter Tires..........23 Warranty Terms and Conditions....32 Wheels and Tires..........22 Technical Specifications........25 Wheels..............22 Winter Tires See: Using Winter Tires........23 2018 Focus ST (CDH) ST, Canada/United States of America, JM5J 19A285 HA enUSA, Edition date: 201706, Second Printing...
- Page 38 JM5J 19A285 HA, Edition date: 201706...
