Ford Focus ST 2017 Owner's Manual Supplement

Hide thumbs
Table of Contents

Advertisement

Quick Links

March 2017
Second Printing
Supplement
Focus ST
Litho in USA
HM5J 19A285 AB
owner.ford.com (U.S.)
ford.ca (Canada)
This Supplement is not intended to
replace your vehicle Owner's Manual
which contains more detailed
information concerning the features
of your vehicle, as well as important
safety warnings designed to help
reduce the risk of injury to you and
your passengers. Please read your
entire Owner's Manual carefully as
you begin learning about your new
vehicle and refer to the appropriate
sections when questions arise.
All information contained in this
supplement was accurate at the
time of duplication. We reserve the
right to change features, operation
and/or functionality of any vehicle
specification at any time. Your Ford
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner's Manual.
2 0 1 7 F O R D F O C U S S T
S U P P L E M E N T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Focus ST 2017 and is the answer not in the manual?

Questions and answers

Related Manuals for Ford Focus ST 2017

Summary of Contents for Ford Focus ST 2017

  • Page 1 We reserve the right to change features, operation and/or functionality of any vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
  • Page 2 2017 FORD FOCUS ST Owner's Manual Supplement...
  • Page 3 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2017 All rights reserved. Part Number: HM5J 19A285 AB 201608 20170103162253...

  • Page 4: Table Of Contents

    Table of Contents Motorcraft Parts..........28 Introduction Capacities and Specifications....29 About This Supplement.........3 SVT.................4 Warranty Terms and Team RS...............4 Conditions Ford Performance..........4 Base Warranty..........32 At a Glance At a Glance............6 Instrument Cluster Gauges..............10 Warning Lamps and Indicators....12 Transmission Manual Transmission........14 Stability Control Using Stability Control........16...
  • Page 5 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...

  • Page 6: Introduction

    Although performance significant interior and exterior is at the heart of every Ford Performance enhancements. developed vehicle, we go much further. Our goal is to deliver a comprehensive,...

  • Page 7: Svt

    SVT Focus in North America. In 2003, The Special Vehicle Team (SVT) was Team RS replaced SVE in Europe when we established in 1991 to polish the Ford Oval brought performance car and motorsport by creating low-volume, factory-produced personnel together as one team.
  • Page 8 Introduction experiences for enthusiasts. This includes across Ford’s product portfolio. accelerating the development of advanced We are proud and passionate about what aerodynamics, lightweighting, electronics, we do and we look forward to a long and powertrain performance, fuel efficiency exciting relationship with you. Thank you...

  • Page 9: At A Glance

    • ST-tuned 2.5 in (63.5 mm) center exit • ST-tuned electric power assisted exhaust system. steering. • Getrag-Ford MMT6 6-speed manual • AdvanceTrac® stability enhancement transaxle. system with three modes: Normal, • Active sound symposer. Sport and Disabled.
  • Page 10 At a Glance • P235/40-18 Pirelli P-Zero Nero • Leather wrapped ST sport steering performance all-season tires wheel with improved grip contour. (optional). • ST-unique instrument panel appliques, • ST-engineered front and rear fascias shift knob, shift boot and pedal pads. and rear wing.
  • Page 11 At a Glance Item Description 1.952 4.063 1.321 4.063 1.321 4.063 1.129 2.955 0.943 2.955 Reverse 4.600 2.955 Engine Specifications Item Description Configuration Transversely mounted I4, cast aluminum cylinder block and cylinder heads Bore x stroke 3.4 in (87.5 mm) bore x 3.2717 in (83.1 mm) stroke Displacement 122 in³...
  • Page 12 At a Glance Item Description Turbo Single scroll / 21 psi max boost* Exhaust system 2.5 in (63.5 mm) diameter * SAE Certified Performance ratings are achieved with 19.5 psi, but up to 21 psi can be delivered to maximize power depending on fuel quality and atmospheric conditions. Suspension Specifications Item Description...

  • Page 13: Instrument Cluster

    Instrument Cluster GAUGES E207713 Information display. Speedometer. Engine coolant temperature gauge. Fuel gauge. Tachometer. Trip Computer Information Display Vehicle Settings and Personalization Odometer Engine Coolant Temperature Records the total distance traveled by your Gauge vehicle. WARNING Outside Air Temperature Never remove the coolant reservoir Shows the outside air temperature.
  • Page 14 Instrument Cluster At normal operating temperature the Oil Temperature Gauge indicator will remain in the center section. Indicates the temperature of the engine Note: Do not restart the engine until the oil. cause of overheating has been determined If the needle enters the red section, the and resolved.

  • Page 15: Warning Lamps And Indicators

    Instrument Cluster WARNING LAMPS AND INDICATORS Gauges E194323 Tachometer. Fuel gauge. Coolant temperature gauge. Speedometer. 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...
  • Page 16 Instrument Cluster If the engine oil pressure drops below the normal range, the oil pressure gauge pointer drops into the red section of the gauge scale and the engine oil pressure warning lamp in the main instrument cluster illuminates. Stop the vehicle as soon as safely possible and switch off the engine immediately.

  • Page 17: Transmission

    Transmission 2. Press the clutch pedal to the floor, then MANUAL TRANSMISSION put the transmission in neutral (N). 3. Start the engine, then press the brake pedal and release the parking brake. 4. Move the transmission to position 1 , then slowly release the clutch pedal while slowly pressing on the accelerator.
  • Page 18 Transmission Before operating your vehicle at high speeds: • Verify correct tire pressures. See Tires (page 23). • Inspect wheels and tires for wear and damage. Replace any wheels or tires that have damage. • Do not operate your vehicle at high speeds with more than two passengers or while carrying cargo.

  • Page 19: Stability Control

    Stability Control USING STABILITY CONTROL The AdvanceTrac® system includes traction control and electronic stability control. See the Traction Control and Stability Control chapters of the Owner's Manual for more information. Never switch off stability control or select sport mode when an emergency wheel or compact wheel is fitted as spare wheel.
  • Page 20 Stability Control AdvanceTrac Modes Mode Description Button operation Display Normal Daily usage with all None None driver aids engaged. Spirited driving. Single press • Message center Sport Thresholds altered displays: Sport on traction control Mode. and electronic • Amber light in stability control to cluster illumin- allow more tire spin...

  • Page 21: Driving Hints

    Driving Hints The system allows a maximum of 20 ENGINE OVERSPEED seconds of engine overboost. After this the system reduces turbo charger boost WARNING and maximizes it at a predetermined limit. Do not operate the engine at high Once the turbo charger boost drops below engine speeds while the vehicle is the predetermined limit the system resets stationary.

  • Page 22: Roadside Emergencies

    • Towing — independent service ROADSIDE ASSISTANCE contractors, if not prohibited by state, local or municipal law, shall tow Ford Vehicles Sold in the United States: eligible vehicles to an authorized dealer Getting Roadside Assistance within 35 mi (56 km) of the...
  • Page 23 Roadside Emergencies Vehicles Sold in Canada: Getting Roadside Assistance To fully assist you should you have a vehicle concern, Ford Motor Company of Canada, Limited offers a complimentary roadside assistance program. This program is eligible within Canada or the continental United States.

  • Page 24: Maintenance

    Maintenance UNDER HOOD OVERVIEW E180866 Engine coolant reservoir. Engine oil dipstick. Engine oil filler cap. Brake fluid and clutch fluid reservoir. Battery. Engine compartment fuse box. Engine air cleaner. Washer fluid reservoir. 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...

  • Page 25: Engine Oil Dipstick

    Maintenance ENGINE OIL DIPSTICK E169062 Minimum. Maximum. DRIVE BELT ROUTING Drivebelt Routing 2.0L EcoBoost E180867 A. Long drivebelt is on the first pulley groove closest to the engine. B. Short drivebelt is on the second pulley groove farthest from the engine. 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...

  • Page 26: Wheels And Tires

    Wheels and Tires TIRES Tires Standard Optional Goodyear Eagle F1 Pirelli P-Zero Nero Size 235/40-18 235/40-18 Speed rating Load rating Usage Summer only All season Wheels 18 in. x 8.0 in., 55 mm offset aluminum wheels • Inspect your tires for damage on a As standard, your ST vehicle is equipped regular basis.

  • Page 27: Using Winter Tires

    They are not designed for maintain it properly. Tire pressure can winter use on ice or snow and you cannot diminish over time and fluctuate with use them with snow chains. Ford does not temperature. recommend using the original equipment Optional All-Season Tires tires when temperatures drop to approximately 41°F (5°C) or below...

  • Page 28: Technical Specifications

    Wheels and Tires Please call the Ford Performance Info for specific winter tire recommendations. Center at 1-800-FORD-SVT (367-3788) TECHNICAL SPECIFICATIONS WHEELS Wheel Specification Diameter and width 18 inches x 8.0 inches Offset 2.2 in (55 mm) Backspacing 6.7 in (16.949 cm) Center bore 2.5 in (63.5 mm)

  • Page 29: Ations

    Wheels and Tires Spare tire Continental ContiProContact Usage All Season Wheel 17 in. x 7.5 in, 52.5mm offset steel wheel See the Wheels and Tires chapter of your owner's manual for instructions on changing a road wheel. Your ST vehicle is equipped with a full-size, dissimilar spare tire assembly. Although the spare is a traditional, full size tire (as opposed to a mini-spare), it is different in both size and handling characteristics from the standard Focus ST performance tire.

  • Page 30: Engine Specifications

    Capacities and Specifications ENGINE SPECIFICATIONS Engine 2.0L EcoBoost engine Cubic inches Required fuel Minimum 87 octane Firing order 1 3 4 2 Ignition system Coil on plug Compression ratio 9.3:1 Spark plug gap 0.027-0.031 in (0.70-0.80 mm) 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...

  • Page 31: Motorcraft Parts

    WW-2803 (passenger side) WW-1295 (rear) We recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability.

  • Page 32: Capacities And Specifications

    Adding Engine Oil We recommend that you use Motorcraft Quantity oil and fluids for your vehicle. Only use fluid that meets Ford specifications. 0.8 qt (0.8 L) Using other fluids could result in damage The quantity of engine oil required to raise not covered by the vehicle Warranty.
  • Page 33 Capacities and Specifications Name Specification Huile moteur synthétique Motorcraft® (Canada) XO-5W30-QFS (U.S.) CXO-5W30-LFS12 (Canada) Motorcraft® Orange Prediluted Antifreeze/Coolant (U.S.) WSS-M97B44-D2 Orange Prediluted Antifreeze/Coolant / Antigel/liquide de refroidissement prédilué orange (Canada) VC-3DIL-B (U.S.) CVC-3DIL-B (Canada) Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid WSS-M6C65-A2 (U.S.) DOT 4 LV High Performance Motor Vehicle Brake Fluid / Liquide de...
  • Page 34 Capacities and Specifications Motor oils of the recommended viscosity Do not use supplemental engine oil grade that meet API SN requirements and additives because they are unnecessary display the API Certification Mark for and could lead to engine damage that may gasoline engines are also acceptable.

  • Page 35: Warranty Terms And Conditions

    Ford Focus models. This information is covered in its entirety in the warranty information. You can obtain warranty service for your ST vehicle or any ST vehicle at any Ford dealer nationwide. Ford Global Performance does not recommend modifying or racing ST, SVT...
  • Page 36 Vehicles Sold in the United States: Using Roadside Assistance........19 Roadside Emergencies.........19 Engine Oil Dipstick.........22 Engine Overboost...........18 Engine Overspeed...........18 Stability Control..........16 Engine Specifications........27 SVT.................4 Ford Performance..........4 Team RS...............4 Technical Specifications See: Capacities and Specifications....27 Tires..............23 Gauges..............10 Optional All-Season Tires.........24 Engine Coolant Temperature Gauge.....10 Tire Pressure............23 Fuel Gauge..............11...
  • Page 37 Index Using Stability Control........16 Enhanced Torque Vectoring Control....17 Using Winter Tires..........24 Warning Lamps and Indicators....12 Gauges...............12 Warranty Terms and Conditions....32 Wheels and Tires..........23 Technical Specifications........25 Winter Tires See: Using Winter Tires........24 2017 Focus ST (CDH) ST, Canada/United States of America, HM5J 19A285 AB enUSA, Edition date: 201608, Second Printing...
