Campbell Hausfeld FP2400 Operating Instructions Manual

Cordless Air Compressor
Compresseurs d'air sans fil
Compresor de aire sin cable
Notes
Notes
Notas
32
See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and/or property damage! Retain instructions for future reference.
BUILT TO LAST
Description
Record the Model No., Serial No. and
date of purchase located on the pump
Portable cordless air compressors are
in the space below.
for home and workshop use. All
models are equipped with regulators,
Model No. ____________________
ball bearings, and motors with
Serial No. ____________________
automatic overload protection.
Safety Guidelines
Date of purchase _________________
This manual contains information that
Retain these numbers for future
is very important to know and
reference.
understand. This information is
provided for SAFETY and to PREVENT
NOTE: Unit will not run when
EQUIPMENT PROBLEMS. To help
charging.
recognize this information, observe the
following symbols.
WARNING
!
Danger indicates
DANGER
! during shipping, handling or use.
an imminently
Damage may result in bursting and
hazardous situation which, if not
cause injury or property damage.
avoided, will result in death or serious
injury.

General Safety

Warning indicates
WARNING
!
a potentially
Since the air compressor and other
hazardous situation which, if not
avoided, could result in death or components (material pump, spray
serious injury.
guns, filters, lubricators, hoses, etc.)
Caution indicates a
used, make up a high pressure
CAUTION
!
potentially
pumping system, the following safety
hazardous situation which, if not
precautions must be observed at all
avoided, may result in minor or
times:
moderate injury.
Notice indicates 1. Read all manuals included
NOTICE
important
with this product
information, that if not followed, may
carefully. Be thoroughly
cause damage to equipment.
familiar with the controls
Unpacking
and the proper use of the
After unpacking the unit, inspect
equipment.
carefully for any damage that may have
2. Follow all local electrical and safety
occurred during transit. Make sure any
codes as well as in the US, National
loose fittings, bolts, etc., are tightened
Electrical Codes (NEC) and
before putting unit into service. Make
Occupational Safety and Health Act
sure to install fuse promptly after
(OSHA).
opening. Have the serial number,
3. Only persons well acquainted with
model number, and parts list (with
these rules of safe operation should
missing parts circled) before calling for
assistance be allowed to use the compressor.
4. Keep visitors away and NEVER allow
DO NOT RETURN THE
children in the work area.
PRODUCT TO THE
STOP!
RETAILER!
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2004 Campbell Hausfeld/Scott Fetzer For parts, product & service information
visit www.chpower.com
Model FP2400
Need
Assistance?
Call Us First!
1-800-543-8622
Cordless Air
Compressor
DANGER
!
Breathable Air Warning
This compressor/pump is not
equipped and should not be used
"as is" to supply breathing quality
air. For any application of air for
human consumption, the air
compressor/pump will need to be
fitted with suitable in-line safety
and alarm equipment. This
additional equipment is necessary
to properly filter and purify the air
Do not operate
to meet minimal specifications for
unit if damaged
Grade D breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used
for the purpose of breathing air
application and proper in-line
safety and alarm equipment is not
simultaneously used, existing
warranties shall be voided, and
Campbell Hausfeld disclaims any
liability whatsoever for any loss,
personal injury or damage.
MANUAL
5. Wear safety glasses and
use hearing protection
when operating the
pump or unit.
6. Do not stand on or use the pump or
unit as a handhold.
7. Before each use, inspect compressed
air system and electrical components
for signs of damage, deterioration,
weakness or leakage. Repair or
replace defective items before using.
8. Check all fasteners at frequent
intervals for proper tightness.
IN606903AV 9/04
