Installing firmware images from a system reboot using the CLI
14
8 Type I and the Configuration and information menu is displayed:
[S]: Set serial port baudrate(will take effect on next
boot).
[T]: Set image download port.
[C]: Set DHCP enable (will take effect on next boot).
[D]: Set bootup debug message display (will take effect on
next boot).
[I]: Display hardware information.
[Q]: Quit this menu.
[H]: Display this list of options.
Enter S,T,C,D,I,Q,or H:
9 Type T to set the image download interface. The following message is displayed:
Enter image download port number [1]:
10 Enter the number of the FortiGate interface that you connected to the same
network as the TFTP server and press Enter.
For example, if you have connected interface 6 (port6) to the network, enter 6 and
press Enter.
11 Type Q to return to the previous menu.
12 Type G to get to the new firmware image form the TFTP server.
The following message appears:
Enter TFTP server address [192.168.1.168]:
13 Type the address of the TFTP server and press Enter:
The following message appears:
Enter Local Address [192.168.1.188]:
14 Type an IP address that the FortiGate image download interface (see step 10) can
use to connect to the TFTP server.
This IP address is a temporary IP address only assigned to this interface for
uploading the firmware image from the TFTP server. The IP address can be any
IP address that is valid for the network that the image download interface is
connected to. Make sure you do not enter the IP address of another device on this
network.
The following message appears:
Enter File Name [image.out]:
15 Type the new firmware image filename and press Enter.
The TFTP server uploads the firmware image file to the FortiGate module and
messages similar to the following are displayed:
Save as Default firmware/Backup firmware/Run image without
saving: [D/B/R]
16 Type D.
The FortiGate module installs the new firmware image and restarts. The
installation might take a few minutes to complete. The FortiGate starts up in the
factory default configuration.
