Using the CLI

FortiGate-1000A/AFA2 FortiOS 3.0 MR6 Install Guide

01-30006-0461-20080131
To add an outgoing traffic firewall policy
Go to Firewall > Policy.
Select Create New.
Set the following and select OK.
Source Interface Select the port connected to the network.
Source Address All
Destination Interface Select the port connected to the Internet.
Destination Address All
Schedule always
Service Any
Action Accept
To add an incoming traffic firewall policy
Go to Firewall > Policy.
Select Create New.
Set the following and select OK.
Source Interface Select the port connected to the Internet.
Source Address All
Destination Interface Select the port connected to the network.
Destination Address All
Schedule always
Service Any
Action Accept
Firewall policy configuration is the same in NAT/Route mode and Transparent
mode.
Note that these policies allow all traffic through. No protection profiles have been
applied. Ensure you create additional firewall policies to accommodate your
network requirements.
After connecting to the CLI, you can use the following procedures to complete the
basic configuration of the FortiGate unit. Ensure you read the section
to the CLI" on page 19 before beginning.

Switching to Transparent mode

The FortiGate unit comes preset to NAT mode. You need to switch to Transparent
mode.
To switch to Transparent mode
config system settings
set opmode transparent
set manageip <address_ip> <netmask>
set gateway <address_gateway>
end
Configuring Transparent mode
"Connecting
27
