Summary of Contents for Lenntech Testomat 2000 Polymer
- Page 1 L enntech Operating Instructions ® Testomat 2000 Polymer Process Photometer for Polyacrylate L enntech L enntech info@lenntech.com Tel. +31-152-610-900 info@lenntech.com Tel. +31-152-610-900 www.lenntech.com Fax. +31-152-616-289 www.lenntech.com Fax. +31-152-616-289...
-
Page 2: Table Of Contents
Content Content Content ....................2 Important safety information ............. 4 Intended use ..................4 Qualification of the staff ................ 4 Warning notices in these instructions ........... 5 Further documents ................5 Pay particular attention to ..............5 General instructions ................5 Installation ..................... - Page 3 Content Switch functions of the limit value outputs LV1 and LV2 ....27 Switch function 0, duration ..............27 Switch function 1, impulse ..............27 Switch function 2, interval ..............27 Switch function 3, two-point ..............28 Switch function 4, Duration/inverse ............ 28 Switch function 5, range LV1-LV2 ............
-
Page 4: Important Safety Information
Always adhere to hazard warnings and safety information when using reagents, chemicals and cleaning agents. Please adhere to the respective safety data sheet! Download the safety data sheets for the supplied reagents at www.lenntech.com Intended use ® The process photometer Testomat 2000... -
Page 5: Warning Notices In These Instructions
Important safety information Warning notices in these instructions The warning notices in these instructions warn the user about potential dangers to individuals and property resulting from incorrect handling of the instrument. The warning notices are structured as follows: Description of the type or source of danger Description of the consequences resulting from non-observance SIGNAL WORD! ... -
Page 6: Installation
Important safety information Installation Always completely disconnect the relevant plant part before installing the instrument or connecting/disconnecting it to/from the WARNING power supply. Secure the plant against reconnection. Only connect the instrument to the mains voltage specified on the rating plate. -
Page 7: Scope Of Delivery
Scope of delivery Scope of delivery ® 1x Testomat 2000 Polymer 1x plastic bag containing 2 screw caps with a hole and an insert for the reagent bottles 1x operating instructions Performance specifications ® The process photometer Testomat 2000 Polymer is a robust wet- chemical online monitor for monitoring the polyacrylate content from 0 to 50 mg/l (ppm) (with the factor set to 1.00) using the photometric analysis principle. -
Page 8: Application Instructions
Application instructions Application instructions Wait at least 5 seconds before switching the instrument on and then off again at the main switch. If the measuring water contains more than 20 mg/I CO (carbonic acid), incorrect evaluations cannot be excluded. ... -
Page 9: Installation
Installation Installation Risks resulting from incorrect installation! WARNING ® Install Testomat 2000 Polymer at a location where it is protected against dripping or splash water, dust and aggressive substances – e.g. in a switch cabinet or on a suitable wall. Information for trouble-free operation NOTE ®... -
Page 10: Connecting The Water Inlet And Outlet
Installation Connecting the water inlet and outlet Information for trouble-free operation The water pressure must be between 0.3 bar and 8 bar NOTE Avoid strong pressure fluctuations The measuring water temperature must be between 10 °C and 40 °C ... -
Page 11: Connecting The Power Supply And Devices
Installation Connecting the power supply and devices Risk of electric shocks during installation! If the power supply is not disconnected prior to installation, it may WARNING result in personal injuries, destruction of the product or damage to plant parts. Always disconnect the relevant plant parts before installing ®... - Page 12 Installation ® Internal design Testomat 2000 Polymer Terminal strip for inputs Start, Stop, IN1, IN2, and output OUT Mains switch Terminal strip for power input and power output ...
-
Page 13: Connecting The Mains Voltage
Installation Connecting the mains voltage Only connect the instrument to the specified mains voltage. Refer to the rating plate for the appropriate mains voltage. Connect the cables as follows: Loosen both fastening screws and open the upper door. The ... -
Page 14: Connecting The Plant Components
Installation Connection example Connecting the plant components Limit value contact LV 1 switches mains voltage Connect the plant components to the output terminals of relays 1 to 19 (e.g. valves). If the plant components require mains voltage, connect the ... -
Page 15: Connecting The Inputs And Outputs
Installation Connecting the inputs and outputs ® Testomat 2000 Polymer has the following connections for control and monitoring functions. Do not connect an external voltage to these connections! Ensure that the leads are held securely in the terminals. ... -
Page 16: Commissioning
Commissioning Commissioning Handling of reagents CAUTION Adhere to the respective safety data sheet! Inserting the reagent bottles Open the lower housing door by pulling on the right-hand side. Remove the cap from the indicator bottle. Remove the plastic bag from inside the lower housing door. The ... -
Page 17: Opening The Water Inlet
Functions of the operating and display elements Opening the water inlet Open the lower housing cover. Slowly open the manually operated shut-off valve to prevent the measuring chamber overflowing. The flow regulator requires a few seconds to function correctly. ... -
Page 18: Display Functions
Functions of the operating and display elements Display functions Polymer 20.2 mg/l 1:0025.6 2:0015.4 mg/l Inlet Analysis Without Analysis Outlet Dosing valve stop function running valve message 1 Limit value status displays (red/green) The display 1 illuminates red if limit value 1 has been reached or exceeded. -
Page 19: Operating Elements And Function Keys
Functions of the operating and display elements Operating elements and function keys Programming keys (cursor block) Function keys Press the "manual" key to start an analysis by hand Press the "STANDBY" key to put the instrument into standby mode (automatic analyses are not carried out: analysis stop) -
Page 20: Operating System
Functions of the operating and display elements Operating system Testomat instrument Instrument settings and data input (display) in display mode Date, time and weekday input Press the "M" key The basic menu " " appears Use the cursor block to select the desired menu item "... -
Page 21: Password Protection And Basic Program
Password protection and basic program Testomat instrument Password protection and basic (display) in display mode program A four-digit password is required to enter data and to carry out settings in the basic program. The password is the current time of ®... - Page 22 Password protection and basic program Enter the interval pause and the flush times ▼▲ In , select => => => Analysis Enter the " interval in minutes (m) Sequence of (1 minute is preset) times Enter the " in seconds (s) (00 seconds (s) is preset) ...
-
Page 23: Selecting The Display Unit
Password protection and basic program The analysis is carried out once the programmed water quantity has Volumen control / been measured. An analysis is always triggered with higher priority Time priority when the programmed interval time has been reached. Selecting the volume control/time priority ▼▲... -
Page 24: Factor
Password protection and basic program Factor ▼▲ The factor required for the measurement of various products can be entered here. The input range is between 0.01 and 99.99 In > , select => => Enter the desired factor. ... -
Page 25: Entering Further Basic Program Data
Entering further basic program data Entering further basic program data For selecting and entering data for these functions, please proceed as described under "Entering basic program data". Internal flushing To ensure that the analysed sample represents the current value, the sampling line must be sufficiently flushed. -
Page 26: Interval Pause
Entering further basic program data Interval pause If the analysis is triggered via a timer, the interval between two analyses (plus flushing time) is determined by the interval pause. The shortest interval can be 0 minutes. In this case, analyses are carried out continuously. -
Page 27: Hysteresis
Entering further basic program data Hysteresis The respective limit value output only switches after the first, second Suppression of or third bad analysis (suppression of the first or the second measured bad analyses value). This increases the reliability of the analysis evaluation, e.g. after the measuring point has been switched over or if the sampling line has not been flushed sufficiently. -
Page 28: Switch Function 3, Two-Point
Entering further basic program data Switch function 3, two-point If the upper limit value LV1 has been exceeded, the output relay LV1 switches. If the value falls below the lower limit value LV2, the output relay LV1 drops out again. The output relay LV2 switches according to the programmed switch function. -
Page 29: Water Meter
Entering further basic program data Press "ENTER" to confirm the entry In , select => => Select a normally closed or normally open contact Press "ENTER" to confirm the entry Water meter It is necessary to connect a water meter to input IN2 for quantity- ▼▲... -
Page 30: Function Aux
Entering further basic program data Function AUX The AUX relay output can be programmed for the following control functions: For example, it is possible to control the cooling water inlet of an upstream cooler via a solenoid valve. This ensures that the cooling water only flows when required, i.e. -
Page 31: Maintenance Interval
Description of the signal inputs/outputs Maintenance interval Observance of the maintenance intervals is monitored and displayed ▼▲ ® by Testomat 2000 Polymer. Program the desired maintenance interval in days here. (0 days equals no maintenance interval) In , select =>... -
Page 32: Interfaces (Optional)
Description of the signal inputs/outputs In , select ▼▲ => => Select the type of contact Press "ENTER" to confirm the selection Function Test Action period Fixed, As long as the contact at external measuring point the input is 'open' or terminals 24,25 switch-over 'closed', analyses are... -
Page 33: Monitoring A Measuring Point
Description of the signal inputs/outputs Switch off the instrument. Insert the plug-in circuit board into the left-hand slot with the component side on the left. (Contact no.1 is at the top) ® Switch on Testomat 2000 Program the desired type of current (0/4-20mA) (for SK910). Monitoring a measuring point A printer can be connected to record the analysis results. -
Page 34: Set Range Of Readings
Description of the signal inputs/outputs Set range of readings This menu is for matching the current range to an end value. Measuring values in the selected range can be represented by a corresponding current. For all values that are larger than the upper ▼▲... -
Page 35: Serial Interface Rs232
Description of the relay outputs Serial interface RS232 ® Testomat 2000 Polymer can also be connected to a log printer via the serial interface RS232 to enable the printout of measuring results and error messages. Analyses can then be continuously logged. This option is only possible in connection with the RS-232 interface card for log printer, RS910 (Art. -
Page 36: Measuring Points 1 Or 2 (Measuring Point Switch-Over)
Description of the relay outputs Function Contact Action Volt-free Programmable: Limit value 1 change- terminals 3, 4, 5 - Continuous contact Relay switches when the over - Impulse (1-99 seconds/minutes) limit value is exceeded at: - Interval (1-255 seconds/minutes) contact Limit value 1 or - Two-step controller (only for one measuring point 1... -
Page 37: Alarm (Fault Message Output)
Description of the relay outputs Alarm (fault message output) The "Alarm" output is a volt-free change-over relay contact. During trouble-free operation, the contact between the terminals 15 – 16 is Alarm closed and the one between terminals 14 – 16 is open. In case of a terminals 14, 15, 16 voltage breakdown, the contact between the terminals 14 –... -
Page 38: Information Menu "I
Information menu "i" Information menu "i" In the information menu, it is possible to request active settings and Customer service (2) statuses of the instrument, the error history, the date for the next maintenance and the customer service address. Display of the customer service address or, e.g., a service hotline. -
Page 39: Program Menu "M
Program menu "M" Program menu "M" Service I (2) Call: (1) Input indicator (3) Use the key to open the program menu "M". Enter the new filling levels after It is possible to call up all the functions without password protection each refill or reagent bottle except for the basic program. - Page 40 Program menu "M" Confirm maintenance (10) After maintenance has been carried out, confirm it by pressing the "ENTER" key and exit this item via the "M" key. The maintenance interval is restarted. Confirm a maintenance request once the maintenance interval has expired in the M menu.
-
Page 41: Structure Of The Basic Program
Program menu "M" Structure of the basic program Call the basic factory program by simultaneously pressing and holding down the "M" and "i" keys while switching on the instrument. CAUTION, the last set of programming will be erased! -
Page 42: Error Messages/Troubleshooting
Error messages/Troubleshooting Error messages/Troubleshooting Displayed message (flashes at Instrument result functions Possible causes Remedies selected display) Replace fuse F4 or F8 - After programming: - Internal power failure of the Ff. POWER FAILURE 24 V 24 V supply Continuous alarm or message (The control lamp "Power"... -
Page 43: Further Information
Error messages/Troubleshooting Further information Error Possible causes Remedies - Incorrect measured value at the output or Replace fuse F7 Current interface functions incorrectly no power supplied Replace the interface circuit board Unit is not functioning, even though it is - Fuse F9, F5 or F2 (240 V: F1) defective ... -
Page 44: Maintenance
Maintenance Maintenance Required maintenance measures NOTE Regular maintenance is necessary to ensure trouble-free operation of the instrument! Please regularly carry out the maintenance work described in the following section when the programmed maintenance date has been reached (display "maintenance interval exceeded") ... -
Page 45: Service Instructions
Maintenance have formed on the sight-glass windows. In this case, clean the sight-glass windows as described below for cleaning the measuring chamber. The measuring chamber can be cleaned with a cleaning agent suitable for decalcification and rust removal. Flush the measuring chamber thoroughly after cleaning. -
Page 46: Maintenance Message Pump Head
Testomat 2000® spare parts and accessories Maintenance message pump head During operation, the effective run time of the pump head is counted. When a run time of 150 hours is reached, the maintenance message for the pump head appears. During normal operation (analysis interval, every 15 min), this run time is achieved after approximately ▼▲... - Page 47 Testomat 2000® spare parts and accessories ® Testomat 2000 spare parts and accessories Art. no. Pressure controller Art. no. Instrument spare parts 40125 Controller / Filter receiver, complete 31582 Fuse M4A 40120 Controller / Filter receiver 40294 Base circuit board T2000 complete 230 V 40129 Controller plug T2000, complete...
-
Page 48: Accessories
Testomat 2000® spare parts and accessories Accessories Please refer to our delivery programme for an up-to-date overview of available accessories. Reagent Type Art.-no.: Polymer Reagent A 156271 Polymer Reagent B 156272 Art. no. Description 040123 Retrofit kit for water inlet 040315 Discharge hopper for Testomat 2000/ECO 270305 Current interface card 0/4 - 20 mA, SK 910... -
Page 49: Technical Data
We reserve the right to make technical changes without notice in the interest of constantly improving our products! Our manuals are updated regularly. If you have an older version (see version at the back of the manual) you will find the current manual on our website www.lenntech.com. -
Page 50: Conformity Declaration
® Check List Testomat 2000 Dear customers and service technicians, This check list cannot replace your expertise or extensive experience in fault resolution. It is intended to support fast and systematic error diagnosis and error documentation. This list does not claim to be complete. We are therefore always grateful for any advice and information you may be able to provide. - Page 51 Instrument settings Caution! Your settings may be deleted if repairs are carried out. Therefore, note down your instrument settings in the table below before sending the instrument to our service team for repairs. Please enclose a copy of the table with the instrument. If you have noted down the settings, they can be easily re-entered by your service staff once any repairs have been completed.
-
Page 52: Product Overview Testomat 2000 -Instruments
Product overview Testomat 2000®-Instruments ® Product overview Testomat 2000 -Instruments Model/Type Measuring Measuring Applications/Functions Parameter Range • Water hardness • Universal for water treatment ® Testomat 2000 0.05-25 °dH plants • Carbonate 0,5-20 °dH • allowed for boiler houses hardness 1-15 mmol/l •... - Page 53 L enntech L enntech info@lenntech.com Tel. +31-152-610-900 info@lenntech.com Tel. +31-152-610-900 www.lenntech.com Fax. +31-152-616-289 www.lenntech.com Fax. +31-152-616-289 Scan the code and visit us on our website!
