- Page 1 L enntech Series 100 zone ontroller info@lenntech.com Tel. +31-152-610-900 www.lenntech.com Fax. +31-152-616-289 User Guide...
-
Page 2: Table Of Contents
Contents Foreword Warranty For Your Safety Care and Maintenance Disposal / Recycling Guidelines on How to Measure Ozone About Your Controller Ozone Controller Components Setting Up the Ozone Controller Assembly Power Requirements External Control Wiring Operating Instructions Operating in Low or High Ozone Environments Operating as a Controller Setting the Control Set Points Operating as a Switch... -
Page 3: Foreword
Aeroqual reserves the right to revise this document or withdraw it at any time without prior notice. The availability of particular products may vary by region. - Page 4 Statement of Compliance The Aeroqual Series 100 Ozone Controller complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) these devices may not cause harmful interference, and (2) these devices must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Warranty
Aeroqual. Our Warranty Aeroqual warrants this product to be free from defects in material and workmanship at the time of its original purchase by a consumer, and for a subsequent period as stated in the following table... - Page 6 Aeroqual reserves the right to refuse warranty service if this information has been removed or changed after the original purchase of the product from the dealer.
-
Page 7: For Your Safety
Do not use the Ozone Controller in or near volatile fuel or chemicals. DO NOT EXPOSE SENSORS TO HIGH LEVELS OF OZONE This can adversely affect the calibration of Aeroqual sensor heads HEALTH AND SAFETY IN THE WORKPLACE The Aeroqual 100 Series Controllers are used to monitor Ozone concentration. -
Page 8: Care And Maintenance
Care and Maintenance Your Ozone Controller is a product of superior design and quality and should be treated with care. When using your Ozone Controller: Keep it and all its parts and accessories out of the reach of small children. Keep it dry. -
Page 9: Guidelines On How To Measure Ozone
Guidelines on How to Measure Ozone The following information is presented to help users operate their Aeroqual Ozone Controller in the most effective and efficient manner. General • Ozone is heavier than air and tends to sink. Thus detection of leaks from ozone generating equipment should be performed at the most appropriate position. - Page 10 False Readings • The Aeroqual Ozone Controller has been designed to respond selectively to ozone, however other oxidizing gases such as chlorine and nitrogen dioxide can generate false readings they high concentrations. High concentrations of hydrocarbon gases such as vapours of alcohol, oils and solvents can reduce and mask the concentration of ozone.
-
Page 11: About Your Controller
About Your Controller The Aeroqual Series 100 Ozone Controller is designed to measure and control ozone concentrations by activating an external relay controlled circuit. The unit can be used either as a control device (to maintain the ambient ozone concentration between user defined levels) or as a simple switching device (switching equipment on and off). -
Page 12: Ozone Controller Components
Ozone sensor head • User guide • 3 rubber pads • 4 Velcro dots Please check that all these components have been supplied and contact your dealer or Aeroqual on email at: L enntech info@lenntech.com Tel. +31-152-610-900 www.lenntech.com Fax. +31-152-616-289... -
Page 13: Setting Up The Ozone Controller
Setting up the Ozone Controller Assembly The following needs to be completed before the Ozone Controller is ready for use: - • Insert the sensor head into the top of the controller. The sensor head is keyed to ensure the head is inserted correctly. -
Page 14: External Control Wiring
External Control Wiring The pin numbers for the RJ45 connector, viewed from the front are numbered from 1 to 8 with pin number 1 being on the right. The pin designations are as follows: 1. GND 2. Relay switching signal 3. -
Page 15: Operating Instructions
Operating Instructions Operating in Low or High Ozone Environments The controller can operate either low or high ozone concentration sensor heads by setting the dip-switch on the controller printed circuit board for the appropriate ozone sensor head. Operating as a Controller The low and high control set points (‘dead band’) are set by adjusting the two rotary switches as shown in the diagram on the following page. -
Page 16: Setting The Control Set Points
Switch High High position conc. conc. conc. conc. head head head head - low - high - low - high rotary rotary rotary rotary 0.030 0.050 0.20 0.30 0.040 0.060 0.30 0.40 0.050 0.070 0.40 0.60 0.060 0.080 0.60 0.80 0.070 0.090 0.80... -
Page 17: Operating As A Switch
Operating as a Switch WARNING PERSONAL INJURY • DO NOT USE this product as a safety or emergency stop device, or in other applications where failure of the product could result in personal injury. • In hazardous environments, an approved Health and Safety plan should be in place. -
Page 18: Led Status Indicators
Status LED Indicator No power, No connection, Off – relay open controller failure Control Operation < Low Set Point Orange (constant) – relay closed Within Control Band Green (constant) > High Set Point (constant) – relay open Control Status Warm Up (30 minutes) Green (Slow Flash -2 sec period) - relay open Wrong Switch Setting (eg. -
Page 19: Specifications - Series 100
Specifications – Series 100 Sensor type (GSS) Gas Sensitive Semiconductor Measurement range Low concentration Ozone Head 0.000 to 0.500 ppm High concentration Ozone Head 0.00 to 5.00 ppm Accuracy Low concentration Ozone Head ± 0.010 ppm (0 to 0.100 ppm) ±... -
Page 20: Drawings
Drawings L enntech info@lenntech.com Tel. +31-152-610-900 www.lenntech.com Fax. +31-152-616-289...
