CABLE DIAGRAM

The cable diagram shows the proper route of the
cable. Use the diagram to make sure that the cable
and the cable guards have been assembled correctly.
4
If the cable has not been correctly routed, the
strength equipment will not function properly and
damage may occur. The numbers show the correct
route of the cable. Make sure that the cable guards
do not touch or bind the cable.
5
88
Do not tighten the Set
Screws (88) more than
85 inch/pounds (9.6
Newton-meters).
1
3
2
