HydroTap G4
User Guide
Tap Operation..................(Pages 2-10)
•
LCD Screen & Menu .......(Pages 11-24)
•
Maintenance.................... (Pages 24-26)
•
Home Menu Icons............(Page 27)
•
Date of Installation............./......../.........
BCS Compact Commercial
Affix Model Number Label
802266NZ - HT-BCS; BCSH A-AV Compact User Guide - Feb 2016 - v2.01
®
Here
802266NZ
Page 1 of 28

Advertisement

loading

Related Manuals for Zenith HydroTap G4

Summary of Contents for Zenith HydroTap G4

  • Page 1 HydroTap G4 ® User Guide Tap Operation....(Pages 2-10) • LCD Screen & Menu ..(Pages 11-24) • Maintenance....(Pages 24-26) • Home Menu Icons....(Page 27) • Date of Installation...../../..BCS Compact Commercial Affix Model Number Label Here 802266NZ 802266NZ - HT-BCS; BCSH A-AV Compact User Guide - Feb 2016 - v2.01...
  • Page 2 Tap Safety The safety lock feature is provided to prevent boiling water flowing if the hot lever is inadvertently operated. This function can be activated and deactivated from either the Tap or from the touch screen display (Located on the unit in the cupboard). To set the tap safety setting: (Classic;...
  • Page 3 Tap functions Elite Tap: Boiling Button Chilled Button The Elite tap uses touch Safety Lock sensitive controls, to dispense Boiling, Chilled and Sparkling water. When operating the tap, ensure the touch surface is dry as moisture may interfere with the sensor touch control. The safety lock can be con- trolled from either the tap or from the touch screen display...
  • Page 4 Tap functions HydroTap Arc/Cube: On powerup, wait 30secs. for the unit to calibrate itself. Tapping the select button will allow the choice of Boiling (RED) with safety, Chilled (BLUE) or Sparkling (WHITE) water mode. The Arc/Cube control may be rotated in a forward or reverse direction to dispense Boiling or Chilled water.
  • Page 5 Tap operation To dispense chilled water: Classic Tap Press or pull lever HydroTap Classic and All-In-One taps: Depressing the “Blue” lever allows the dispensing of chilled water. Pulling forward the Blue lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable).
  • Page 6 Tap operation To dispense boiling water: (With the safety OFF) HydroTap Classic: Depressing the Red lever allows the dispensing of boiling water. Pulling forward the Red lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable). To reset, return the handle to the “Off”...
  • Page 7 Tap operation To dispense Sparkling water: HydroTap Classic and Operate both levers together All-In-One taps: Depressing both the ‘Red’ d the ‘Blue’ levers allows the dispensing of Sparkling water. Pulling forward both levers allows the tap to operate in a in a “no-touch”...

  • Page 8: Tap Lights

    Tap lights Red Boiling Water Light: (All) Red Lights Blue Lights On all the time: This indicates that the boiling water is ready. Flashing slowly: This indicates that the boiling water is below the desired temperature. Wait for the light to stop flashing before dispensing water.
  • Page 9 Filter Lights Filter light Filter light: Classic; Elite & AIO Filter Light Off: This indicates the filter is operating within its normal specified lifespan. Filter Change light flashing slowly: The light will flash slowly when the filter is due for replacement and the LCD will show “Filter Change”.
  • Page 10 Safety Sensor Calibration (lever models) Light intensity varies from site to site, therefore it is recommended that a re-calibration be performed at the time of the installation. All direct natural sun light must be shaded from the HydroTap, during the calibration.
  • Page 11 LCD Screen Zenith HydroTap introduces a ‘TOUCH’ screen for easy setup and operation adjustment. (See page 23 for Home Menu Icons) Other possible messages in status window: Status** Information Notes Safety OFF Product is in normal operation mode Safety ON...

  • Page 12: Lcd Screen Menu

    LCD Screen Menu Main Menu Sub Menu Sub Menu Options Section Language • English • Product Info • Product serial • System Faults Information • Lists • Event Log • Filter Flush • Filter Reset • Reset options • Boiling •...
  • Page 13 LCD Screen operation - Section A Set Language Language options will be available in some overseas markets LCD Screen operation - Section B System Information In this section, you can find your product serial number , check system fault messages or view the event logs of your product. 1.
  • Page 14 LCD Screen operation - Section C Install Once your Zenith HydroTap G4 unit has been installed, Go to Install menu to configure the system settings for your product. Sub menu: 1 - Filter Flush 2 - Filter Reset 3 - Boiling Calibration...
  • Page 15 LCD Screen operation - Section C 2. - Filter Reset After replacing the filter, the counters should be reset Press the [MENU] button for main menu. Press the [Install] button. Press the [Filter Reset] button. To set the filter life or edit filter usage, refer to section G- Filter.
  • Page 16 Service This section is reserved for service technicians only Note : Call a licensed electrician, plumber,or Zenith office on 0800 558055, for assistance, service, spare parts, or enquiries. Page 16 of 28 802266NZ - HT-BCS; BCSH A-AV Compact User Guide - Feb 2016 - v2.01...
  • Page 17 LCD Screen operation - Section E Security The Zenith HydroTap G4 allows the appliance coordinator to set up a pass- word to protect against users changing the preferred system settings. To set a password Press the [MENU] button for main menu.
  • Page 18 LCD Screen operation - Section F F Communication (when available) The Zenith HydroTap G4 allows the user to use wifi or Bluetooth to operate the product remotely. Not yet available LCD Screen operation - Section G nstructions Settings 1. Press the [MENU] button for main menu.
  • Page 19 Home screen. Set Temperature Zenith HydroTaps are designed to operate within 1ºC to 2ºC of set point for boiling water and between 3ºC to 5ºC for chilled drinking water. All boiling water units are self calibrating to 98ºC, which is the recommended setting.
  • Page 20 LCD Screen operation - Section G ions Filter Zenith HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
  • Page 21 LCD Screen operation - Section G Energy Modes This mode allows the HydroTap to enter into Energy Saving mode. There are two options available: ‘Sleep’ mode and ‘ON/OFF’ mode. In Sleep Mode the unit will go to “Sleep” after a 2hr period of inactivity. The Boiling water will gradually drop to either 68°C or room temp, as shown in the table below and the Chilled water will be ON or OFF.
  • Page 22 LCD Screen operation - Section G Note: Any attempt, during OFF mode, to dispense water, will bring the unit out of sleep mode. The unit will return to sleep mode after 2 hours of non use. Please allow sufficient time for the water to reach the set temperature after disabling the sleep mode.
  • Page 23 LCD Screen operation - Section G Safety To set the tap safety setting: • Press [MENU] button for main menu. • Press [Setting] button. • Press [Safety] button. • Press button - YES to allow the safety setting to be changed on the Tap To Enable or Disable the safety on the tap •...

  • Page 24: Filter Maintenance

    Filter Maintenance Water Filter The Zenith HydroTap notifies when filter replacement is due. If you notice one of the following, you will need to change the filter: • The Change Filter light will flash white once a second and remain so until reset.
  • Page 25 Air Inlet Filter The Zenith HydroTap air filter is conveniently located on the outside of the condenser. The filter screen is a sliding fit in the plastic housing on the side of the under sink unit. The screen may be removed for cleaning, by sliding it forward.
  • Page 26 Dispense some sparkling water from the tap and perform a taste test. Note: Do not discard your empty 2.64kg bottle. The 2.64 kg bottles are refillable. Return the empty bottle to your nearest Zenith service centre for exchange. Cleaning General cleaning Do not use strong, corrosive, spray or abrasive cleaners.
  • Page 27 Home Menu Icons Safety switch is LOCKED. The HydroTap will not dispense any Boiling water. See page 2 for safety switch operation Safety switch is UNLOCKED. Boiling water may be dispensed. See page 6 for tap operation details Sleep mode is active. There are 7 sleep mode options which display this icon on the home screen.

  • Page 28: Contact Details

    Telephone: 0800 558055 Facsimile: 0800 559055 As Zenith policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
