minrray UV830 Series User Manual

Hd video conference camera
Hide thumbs Also See for UV830 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
UV830 Series HD Video
Conference Camera
User Manual
1.0 version
（English）
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UV830 Series and is the answer not in the manual?

Questions and answers

Related Manuals for minrray UV830 Series

Summary of Contents for minrray UV830 Series

  • Page 1 UV830 Series HD Video Conference Camera User Manual 1.0 version （English）...
  • Page 2 Preface: Thanks for using our HD color video conference camera. This manual introduces the function installation and operation of the HD camera. Prior to installation and usage, please read the manual thoroughly. Warning This product can be only used in specified range in order to avoid any damage or danger;...

  • Page 3: Table Of Contents

    CONTENTS 1.Notes ..........4 2.Accessories ..........4 3.Fast Installation .......... 5 4.Camera Highlights ........7 5.Camera Specifications ........7 6.Camera Interface Explanation ......8 7.Remote Controller Explanation ......9 8.Usage of IR Remote Controller ......11 9.RS-232C Interface (Pin Specs) ......14 10.Menu Setting ..........

  • Page 4: Notes

    Notes Electric Safety Installation and operation must accord with electric safety standard Caution to transport Avoid stress, vibration and soakage in transport, storage and installation. Polarity of power supply The power supply of the product is ±12V; the max electrical current is 2A. Polarity of the power supply drawing Careful of installation Never move the camera by seizing the camera head.

  • Page 5: Fast Installation

    Fast Installation 1. Please check the connection before turning on the power. 2. Bottom Dial Switch Setting Set the two switches 【ON】.it is the normal working mode. SW2-2 SW2- Instructions Undefined Updating mode Debugging mode Working mode 3. The Rotary Switch Setting The choice for16 rotary switch video formats Dial-up 1080P60...
  • Page 6 -------- -------- -------- -------- -------- -------- -------- Display the video format set on the menu Note: Restart the camera after switching the dial code. 4.When the power supply switch is “【on】”, the indicator light is open (red color) 5, Camera initializes after powering on: horizontally to the left turn to the limit position, vertically turn to the bottom;...

  • Page 7: Camera Highlights

    Camera Highlights 1.Equipped with modern appearance and 20X HD CMOS sensor,delivering vivid images. 2.Support sound interfaces,DVI interface (inclding YPbPr, VGA and HDMI signal) and HD-SDI interface. 3.IR remote controller signal transparent transmission function: camera can receive both its own remote controller signal and the one from terminal equipment, by transmitting the signal through VISCA IN to terminal equipment IR receiver.

  • Page 8: Camera Interface Explanation

    Camera Interface Explanation 1.Camera lens 2.Camera base 3.Power indicator light 4.Remote Controller Receiver light 5.Bottom dial Switch 6.Tripod screw hole 7.Installation Orientation Hole 8.Rotary Switch : video format optional 9.RS232 controller serial interface (input ) 10.RS232 controller serial interface (output ) 11.CVB interface (for selection) 12.HD-SDI interface 12.DVI-I interface(including YPbPr ,HDMIHD Digital Output and VGA interface)

  • Page 9: Remote Controller Explanation

    Remote Controller Explanation Definition of IR controller 0、Standby key After pressing the standby key, the camera will step into standby mode.Press again,the camera will open again.(Note: Standby mode power consumption is about half of the normal mode) 1、Number key Setting or locating presets 2、* key Key combination use 3、Set preset key:...
  • Page 10 Press key ：down Press key ：left Press key：right “HOME” key: Return to the middle position 9、Menu setting Open or close the OSD menu 10、Zoom Control key zoom＋：lens near zoom－：lens far 11.Camera IR remote control address selection 【*】+【＃】+【F1】 ：Camera Address No.1 【*】+【＃】+【F2】...

  • Page 11: Usage Of Ir Remote Controller

    Usage of IR Remote Controller Finishing initialization, it can receive and execute the IR commands. Users can control the pan/tilt/zoom, setting and running preset positions via the IR remote controller. Key Instruction： 1 、 In this instruction, “press the key” means a click rather than a long-press, and a special note will be given if a long-press for more than one second is required.
  • Page 12 3. Focus Control Focus (far)： Press ”【focus+】” key Focus (near)： Press “【focus-】“key Auto Focus: Press "【auto】" Manual Focus: Press "【manual】" Press and hold the key, the action of focus continues and stops as soon as the key is released. 4.BLC Setting BLC ON / OFF :not support 5.
  • Page 13 Press a number key 0-9 directly to run a relative preset. Note: Action in vain if a relative preset position is not existed. 7.Camera Selection Select the camera address to control. 8.Camera Remote Controller Address Setting 【*】+【＃】+【F1】 ：Camera Address No.1 【*】+【＃】+【F2】...

  • Page 14: Rs-232C Interface (Pin Specs)

    RS-232C Interface (Pin Specs) Camera Windows DB-9 Function TXD1 RXD1 IR OUT Camera Mini DIN Camera RS485 VISCA OUT Function VISCA OUT Function...
  • Page 15 COM control In the normal working condition, the camera can be controlled via the RS-232C/RS485 command (VISCA IN) . The parameter of the RS232C COM is as following : Baud Rate ：2400/4800/9600/115200 Bit/S Start bit：1bit ; Data bit: 8bit ; Stop bit : 1bit;...
  • Page 16 Command Function Command Packet Note AddressSet Broadcast 88 30 01 FF Address setting IF_Clear Broadcast 88 01 00 01 FF I/F Clear CommandCancel 8x 21 FF 8x 01 04 00 02 FF CAM_Power Power ON/OFF 8x 01 04 00 03 FF Stop 8x 01 04 07 00 FF Tele(Standard)
  • Page 17 Command Function Command Packet Note Down 8x 01 04 0D 03 FF Direct 8x 01 04 4D 00 00 0p 0q FF pq: Bright l Positon 8x 01 04 3E 02 FF Exposure Compensation ON/OFF 8x 01 04 3E 03 FF Reset 8x 01 04 0E 00 FF CAM_ExpComp...
  • Page 18 Part3 Checking Command Command Command Packet Return Packet Note y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF Off(Standby) CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position y0 50 02 FF Auto Focus CAM_FocusModeInq...
  • Page 19 Note : 【x】 means the camera address you want to control , 【y】=【x + 8】. Pelco-D Protocol Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF...

  • Page 20: Menu Setting

    Query Pan Position Value High Value Low 0xA0 Address 0x00 0x59 0xAF Response Byte Byte Query Tilt Position 0xA0 Address 0x00 0x53 0x00 0x00 0xAF Query Tilt Position Value High Value Low 0xA0 Address 0x00 0x5B 0xAF Response Byte Byte Query Zoom Position 0xA0 Address...
  • Page 21 MAIN ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ LANGUAGE／语言设置 （SYSTEM OPTION） （CAMERA OPTION） （PT OPTION） （V. FORMAT） （RESET） （HELP） VGA OUTPUT EXIT／ＭＥＮＵ LANGUAGE: Language setting, Chinese / English SYSTEM OPTION：system setting CAMERA OPTION：camera setting PT OPTION：pan tilt setting V. FORMAT: video format setting RESET：reset setting HELP：for help VGA OUTPUT：ON / OFF VGA in the P video format , No VGA in the I video format Note:Component signal is available only when VGA is off.
  • Page 22 3.CAMERA OPTION Move the pointer to the (CAMERA SET) in the Main Menu, click the【 HOME】 and enter the (CAMERA SET) as follow, CAMERA SET ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ （EXPOSURE） （COLOR） （LEN） BACK／ＭＥＮＵ EXPOSURE：exposure setting COLOR: color setting LEN: lens setting 3.1 EXPOSURE SETTING Move the pointer to the (EXPOSURE) in the Main Menu, click the【HOME】and enter the (EXPOSURE SET) as follow, EXPOSURE...
  • Page 23 3.2 COLOR SETTING Move the pointer to the (COLOR SET) in the Main Menu, click the【HOME】and enter the (COLOR SET) as follow, COLOR ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ WB. MODE R. GAIN B.GAIN SATURATION APERTURE FLICK BACK／ＭＥＮＵ WB MODE： White balance mode setting:Auto、 Indoor、 Outdoor、 OnePush、 ATW、 Manual R.GAIN：Red gain setting：0~50（only available in Manual mode）...
  • Page 24 PT SET ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ POWER. ACT SPEEDBYZ MOUNT. MODE IR M.SPEED IR Z.SPEED MIN.SPEED SCAN. SPEED BACK／ＭＥＮＵ 返回／ＭＥＮＵ POWER ACT: 0/1( the camera will move to no.0/1 preset position after 12 seconds without control since power on), Off SPEEDBYZ：only work for IR remote control: On（...
  • Page 25 ALL RESET： reset above 3 items 6. HELP Show instruction of the OSD menu operation HELP ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ ∧ ∨ SELET MENU ＜ ＞ CHANGESETTING ＨＯＭＥ ENTER ＭＥＮＵ RETURN BACK／ＭＥＮＵ 7. EXIT In main menu, press the key【MENU】again will show the exit window as follows: EXIT ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝...
  • Page 26 Wireless Launcher etc. Image effective will not be good when the light is not accordant with camera’s lux. Troubleshooting Image No image 1, Check whether the power cord, voltage is OK, power indicator light is ON. 2, Turn off the power supply to check whether the camera can auto configure. 3, Check the dial switch in bottom and make sure the two dial position are all on OFF.
