- Page 1 Network Video Recorder Quick Installation Guide DS-1100 Pro Series DS-1105/1109/1112/1116/1120/1126/1132/1136 Pro Quality Service Group 1.0.0.8 Information in this document is subject to change without notice. © Copyright 2015, DIGIEVER Corporation. All rights reserved.
-
Page 2: Pre-Installation Notice
NVR. Please read the following description carefully. Pre-installation Notice Please make sure the following items are prepared for installing DIGIEVER NVR DS-1100 Pro Series. Network connection ... - Page 3 For channels over 16: IDDR3 8G or above Graphics Adapter AGP or PCI-Express, minimum 1024×768, 16 bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024 x 768 in order to experience the full benefits of the software.
-
Page 4: Package Contents
Package Contents NVR Network Video Recorder Power Cord Power adaptor Screw Bag Ethernet Cable Stand Product CD Assembly drawing... -
Page 5: Hardware Description
Hardware Description Front View Rear View Power button LED indicators: HDD USB 2.0 x1 (Support auto video backup) USB 2.0 x1 Power connector USB 3.0 x 2 DVI-I eSATA x 1 HDMI x 1 10. Gigabit LAN 11. USB 2.0 x 2 12. -
Page 6: Hard Disk Installation
Hard Disk Installation Please follow the steps as illustrated below to install the hardware:... - Page 7 Connection to DIGIEVER NVR Please insert the product CD-ROM on a PC to install EZ Search and S-NVR Decoder. Finally, you can start Quick Configuration on a web page. Install EZ Search for finding NVR in the network.
- Page 8 Connect to NVR 1. Connect to NVR After setting the EZ Search and S-NVR Decoder, the user can connect to the monitoring page by the following two options: EZ Search Once you click “Connect” or double click the selected NVR list, the IE browser will pop up automatically.
- Page 9 2. Enter a user name and password Log in the NVR with the default administer account (user name: admin, password: admin). 3. Install the ActiveX control in order to successfully view the interface of NVR from IE browser...
-
Page 10: Quick Configuration
Quick configuration After you install the ActiveX control, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once the five steps of Quick Configuration are complete, you can click “Start Liveview”...
