Hardware Package Contents; Parts Not Supplied - Zephyr ZML-M90BG Use, Care And Installation Manual

MODELS: ZML-M90BG/BS , ZML-E42BG/BS
PARTS SUPPLIED

HARDWARE PACKAGE CONTENTS

(3) Wire Nuts
(4) M6 x 1-1/2"
(wood screws)
(10) M4 x 8
(4) 3/16 x 8
(canopy screws)

PARTS NOT SUPPLIED

- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Duct cover extension accessory
- Recirculating kit accessory
2 - Top duct covers
2 - Thick trim pieces
2 - Bottom duct covers
2 - Thin trim pieces
1 - 8" round damper (pre-installed)
1 - Hood body w/ blower (pre-installed)
1 - Canopy, glass or stainless
4 - 3W LED lights
2 - Aluminum mesh filters
(14) M3 x 6
(duct cover screws)
(1) M4 x 12
(safety screw)
4
www.zephyronline.com
1 - Top support frame
Front of Hood
C L
B
Cut-Out Shaded Area
1 - Paper ceiling
template
A
1 - Support frame bracket
1 - Bottom support frame
1 - Hardware package
(4) ø12 OD / ø5 ID
Washers
