• Hot! Do not touch! The glass
and surfaces of this appliance
will be hot during operation and
will retain heat for a while after
shutting
Severe burn may result.
• Carefully supervise children in
the same room as appliance.
• If small children are present in the home, it
is recommended that this appliance be used
with a fire screen kit. See page 35 for
ordering information.
Printed in Canada
TM
off
the
appliance.
Rev. 07
Installation and Operating
This installation manual will help you
obtain a safe, efficient, dependable
installation
chimney system.
understand these installation instructions
before beginning your installation.
CAUTION: Do not attempt to modify or
alter the construction of the fireplace or
its components.
alteration of construction may void the
warranty, listings and approvals of this
system. In that case, Security Chimneys
International Ltd will not be responsible
for damages. Install the fireplace only as
described in these instructions.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
operated without a door. Consult your
dealer to select the correct door model of
your choice.
This fireplace is also certified for use in
mobile or manufactured homes
2125 Monterey St., Laval, Quebec, Canada, H7L 3T6
July 2009
Instructions
for
your
fireplace
Please read and
Any modification or
The fireplace cannot be
Listed to standards:
ULC-S610,UL-127
Report # 3074084
PIBISTRADCE
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIS Tradition CE and is the answer not in the manual?

Questions and answers

Related Manuals for Security Chimneys International BIS Tradition CE

Summary of Contents for Security Chimneys International BIS Tradition CE

  • Page 1 Installation and Operating Instructions This installation manual will help you obtain a safe, efficient, dependable installation your fireplace chimney system. Please read and understand these installation instructions before beginning your installation. CAUTION: Do not attempt to modify or alter the construction of the fireplace or its components.

  • Page 2: Table Of Contents

    3.2.6 Medium Combustion 3.2.7 Slow Combustion 3.2.8 Refuelling For Best Performance 3.2.9 Smoking – Causes and Troubleshooting MAINTAINING YOUR BIS TRADITION CE ..............8 3.3.1 Creosote 3.3.2 Chimney Maintenance 3.3.3 Top Baffle Removal Prior to Cleaning The Chimney 3.3.4 Dealing with a Chimney Fire 3.3.5...

  • Page 3: Safety Rules

    SAFETY RULES FOR OPERATING YOUR FIREPLACE MODEL BIS TRADITION • Use only a Security Fireplace glass door, specifically designed for the model BIS TRADITION CE fireplace. • When cleaning the fireplace, the ashes should be placed in a metal container with a tight fitting lid.

  • Page 4: Certification Label

    CERTIFICATION LABEL...

  • Page 5: The Fireplace

    Security Chimneys International (CSIL) components. • The BIS TRADITION CE is NOT intended for use with a gas log set. Do not use a fireplace insert or any other product with this fireplace unless it is specified by CSIL. For use with this appliance.

  • Page 6: Operating The Bis Tradition Ce

    OPERATING THE BIS TRADITION CE 3.2.1 Fuel The BIS TRADITION CE fireplace is designed to work best when fuelled with seasoned cordwood. Hardwoods are preferred to softwoods since the energy content of wood is relative to its density. Hardwoods will result in a longer burning fire and less frequent refuelling.

  • Page 7: Primary Air And Air Boost Controls

    By this method, the BIS TRADITION CE fireplace can produce up to 55,000 BTU of heat per hour. However, it will be necessary to reload with wood every one or two hours. This is the least efficient method of burning the BIS TRADITION CE fireplace.

  • Page 8: Medium Combustion

    Creosote may accumulate on the glass door. This method of burning should be used only after operating the BIS TRADITION CE fireplace with the air control opened to produce a hot fire for about an hour or at medium pace for at least 3 hrs. Slow combustion can be used at night in order to reduce the heat output and to prolong the burn.

  • Page 9: Smoking - Causes And Troubleshooting

    3.2.9 Smoking – Causes and Troubleshooting To reduce the likelihood of smoking when opening the door, set the combustion air controls to the left before opening the door. Your fireplace has been designed and tested to provide smoke free operation. Occasionally, there may be a small amount of smoking upon lighting the fire, until the chimney heats up but this should not continue.

  • Page 10: Maintaining Your Bis Tradition Ce

    IMPORTANT NOTES A. Do not block the hot air vents to the fireplace as this will cause the fireplace to overheat. B. Never start or ‘freshen up’ a fire using gasoline, kerosene, charcoal lighter fluid or any other combustible liquid. Keep all such liquids well away from the fireplace while it is in use.

  • Page 11: Top Baffle Removal Prior To Cleaning The Chimney

    3.3.3 Top Baffle Removal Prior to Cleaning the Chimney Before starting to clean your chimney, we recommend that you remove the top baffle to avoid creosote dust collection at the top of the baffle. Follow these steps to set the top baffle out of the way: 1.

  • Page 12: Door Installation

    3.3.7 Refractory Replacement The intense heat of the fire will normally cause hairline cracks in the refractory. These cracks can be minimized by proper curing as described in "First fires". They will not normally diminish the effectiveness of the refractory. If large cracks develop, then the refractory should be replaced.

  • Page 13: Glass Care - Replacement

    F). If the glass breaks, it must be replaced with an identical ceramic glass. Tempered glass or ordinary glass will not withstand the high temperatures of the BIS TRADITION CE. Replacement glass should be purchased from a Security Chimneys International dealer (see “Replacement Parts”, page 34).

  • Page 14: Gasket Replacement

    3.3.12 Gasket Replacement Remove the door from the unit (see page 10) and lay them on a clean unabrasive surface. To replace the gasket, first remove all of the old gasket and gasket cement. Make sure that the surface is totally clean before applying new cement (a high temperature silicone caulking rated at 500°F, 260°C, is suitable) or adhesion problems may result.
  • Page 15 36" X 24 ½". Note the floor construction and consult your local building code to determine if additional support is needed. C. The BIS TRADITION CE may be installed directly on the floor or on a raised base (for proper guidelines, refer to "Hearth Extension Requirements") and a minimum of 6'8"...

  • Page 16: Framing, Facing And Mantel

    3.4.3 Framing, Facing and Mantel The construction of the framing, facing, and mantel must be in accordance with the standards and the following illustrations (figures 7 to 11): A. Frame the fireplace using 2" x 3" or heavier lumber. B. WARNING: Combustible materials cannot be used in the space directly above the fireplace, except for the studs above the facade that support the facing and mantel.
  • Page 17 INSULATED CHASE CONSTRUCTION Figure 11 Nailing flanges Four nailing flanges are provided to secure the fireplace on the floor (see figure beside). Bend the nailing flanges down so each flange is flush with the floor, then using nails or Nailing flange screws, secure the fireplace to the floor (2 places each side).
  • Page 18 Facing Note: The facade must be removable once installed. The facade is designed to overlap any facing material installed on the front of the fireplace. If thicker material is installed, use the facade as a template and make sure it can be easily removed for servicing. 1.
  • Page 19 Figure 13b Figure 13c 3.4.4 Fireplace Blower The fireplace comes equipped with a heat activated blower. It is located in the bottom of the fireplace, towards the back. It uses regular 120V and must be connected to the main electrical circuit by a qualified electrician. For connection, use the electrical box supplied with the unit located on the bottom right corner of the fireplace.

  • Page 20: Hot Air Ducting Installation

    HOT AIR DUCTING INSTALLATION Different hot air ducting systems can be installed with the BIS TRADITION CE : - Gravity kit - Forced air kit 3.5.1 Gravity Kit Double hot air outlet including: (See Fig.15) - 2 telescopic lengths 8" I.D. - 2 90º...
  • Page 21 When installing the double outlet system, the hot air outlets can be installed in the same room as the fireplace, or one or both of the outlets can be installed in adjacent or upper rooms. Installing the ducts at different elevations will tend to exhaust more heat out of the higher outlet (figure 16).
  • Page 22 BIS TRADITION CE fireplace hot air exhaust. 7. Use only Security Chimneys International grills and components as described in this manual. Other grills or registers, for example, may be too restrictive and may overheat the fireplace or ceiling.

  • Page 23: Central Forced Air Kit

    3.5.2 Central Forced Air Kit (Not tested under EPA certification) The knock-outs provided on the back and on the sides of the BIS TRADITION fireplace allow the connection of insulated flexible pipe which enables you to heat adjacent rooms up to 50 feet from the fireplace. The ducting system must be installed as described below : A) Fix the adaptor at the back and/or the side of the fireplace by twist-locking the adaptor to the fireplace.

  • Page 24: Outside Air Kit

    OUTSIDE AIR KIT It is mandatory to install an outside air connection to the BIS Tradition CE fireplace. The following components are required and are included with the fireplace: Outside air kit 4" adapter for fireplace connection The outside air assembly must be installed according to the following requirements : A) Duct length should be kept to a minimum.

  • Page 25: The Chimney

    2. The Security fireplace model BIS TRADITION CE fireplace is listed only with Security Chimneys International Ltd 6" diameter chimney systems. 3. A chimney venting a fireplace shall not vent any other appliance. 4. The minimum chimney height is 12 ft. (3.7 m).In altitude, add 18”(450mm) to the chimney for every 2000 feet(600mm) above sea level.

  • Page 26: Chimney Installation Instructions

    CHIMNEY INSTALLATION INSTRUCTIONS 1. Cut and frame the holes in the ceiling, floor and roof where the chimney will pass (see figure 27). Use a plumb bob to line up the center of the holes. The sizes are indicated in table 1 for the floor and ceiling holes and table 2 (page 24) for the roof holes.
  • Page 27 Figure 29 Figure 29a AC CHIMNEY INSTALLATION (AIR COOLED GALVALUME CHIMNEY) Note: Outside air kits must be installed for both fireplace and AC chimney. Figure 30...
  • Page 28 AC CHIMNEY Figure 31 Figure 32 Table 2 ROOF DOWN SLOPE HOLE SIZE SLOPE ASHT+ / HT6103+ S-2100+ / HT6000+ Roof Pitch 6" 6" 6" 12 3/8" (314 mm) 14 1/8" (359 mm) 15" (380 mm) 2/12 12 9/16" (319 mm) 14 3/8"...

  • Page 29: Offset Chimney Installation

    OFFSET CHIMNEY INSTALLATON The minimum chimney height when using elbows is: Fireplace model BIS TRADITION Chimney model ASHT+ / HT6103+ / S-2100+ / HT6000+ / AC Vertical installation 12 ft. (3.66 m) Two (2) elbows 15 ft. (4.57 m) Four (4) elbows 17 ft.
  • Page 30 TOTAL HEIGHT DEVIATION ONE LENGTH BETWEEN ELBOWS TWO LENGTHS BETWEEN ELBOWS CHIMNEY DEVIATION ELBOW 6” & HEIGHT 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48” & 48” 4 5/16"...
  • Page 31 Figure 33 Figure 34...

  • Page 32: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD (RSM+, RSMI30, RSMI45) When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled firestop or wall radiation shield must be installed. Only one is required. Note: 45º angle for Canada only In cold climate locations, we recommend that you use the insulated wall radiation shield since it will maintain the home’s thermal barrier.

  • Page 33: Chimney Supports Installation

    CHIMNEY SUPPORT INSTALLATION Universal Roof Support This support has three possible uses: 1. For ASHT+ / HT6103+ and S-2100+ / HT6000+, it must be used on a roof to support the chimney. 2. It may be used on a floor, ceiling or roof above an offset to support the chimney above the offset.

  • Page 34: Chimney Adaptor (S-2100+ / Ht6000+)

    Figure 36 CHIMNEY ADAPTOR (S-2100+ / HT6000+) The fireplace is normally supplied with a chimney adaptor suitable for the ASHT+ / HT6103+ chimney. If you want to install a S-2100+ / HT6000+ chimney, an adaptor is available (6UCA) (figure 37). A separate starter section will also be required if AC chimney is installed.

  • Page 35: Installation Instructions For Masonry Application

    INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION WARNING: Before starting the installation, the masonry chimney must be inspected by a qualified sweep. The following requirements must be respected: The chimney must be absolutely clear of any soot residue or creosote. Check for cracks, loose or missing bricks that could inhibit correct installation of the liner.

  • Page 36: Parts And Components List

    PARTS AND COMPONENTS LIST (AC Chimney) Description Part No. Lengths 6" dia. 12" length AC 6L12 18" length AC 6L18 36" length AC 6L36 48" length AC 6L48 15º elbow AC 6E15 30º elbow AC 6E30 Rain cap AC 6CPR Spark arrester screen Supports Offset support...

  • Page 37: Options

    OPTIONS Part No.: Gravity kit: Complete double ducting system including: 2 elbows 90º, 7B30ZK-1 2 telescopic lengths, 2 grill supports and 2 black grills Black grill with support 7B30ZO Brass grill for 7B30ZK 7B30ZGB Elbow 90º, 8" dia. 7B26ZE90 Elbow 45º, 8" dia. 7B26ZE45 Telescopic length, 8"...

  • Page 38: Appendix (Specifications, Clearances, Replacement Parts)

    APPENDIX SPECIFICATIONS Weight 300 lbs Height 36" Width 36" Depth 24 1/2" Chimney weight ASHT+ (6" dia.) : 6.25 lb/ft. Chimney weight S-2100+ (6" dia.) : 10.8 lb/ft. CLEARANCE TO COMBUSTIBLES The following clearances meet the minimum requirements for a safe installation Side wall: 17"...
